Teradek Slice Quick Start Manual

A C
B
E
A: Power button E: A/C input
B: USB ports F: SD/HD/3G−SDI input/output
C: Reset button G: HDMI input/output
D: Stream/menu control dial H: 10/100/1000 Ethernet
Stream/Menu Control dial:
: Go live, start/stop push, start/stop recordings, select characters
▲
, , : Selects options from streaming/recording prompts
▼
: Back, move to higher menu level
: Confirm selection, enter main menu, open selected menu
● (Control dial button press)
1
POWER AND CONNECT
Connect A/C power to the Power Input (E). Attach the included Wireless antennas via the threaded
1
RP-SMA connectors (L).
Connect Slice to your network via the 10/100/1000 Ethernet port (H).
2
3
Connect the SDI output from your video source to the HD-SDI (F), or the HDMI
encoder.
WiFi antennas
AC adapter
D
L
F G H I J K
I: Reset button
J: Headphone audio output
K: Mic/Line stereo input
L: RP-SMA connectors
(G) input on the Slice

NETWORK CONNECTION

Slice has a built in web user interface (web UI) for configuring stream destinations, encoder
parameters, and other settings. The interface can be accessed by connecting via Wi−Fi or Ethernet.
CONNECT VIA WI−FI
Connect to Slice's Wi−Fi network (AP mode): Teranet−XXXXX (serial number of the device). If Slice has
1
already been configured to connect to another network (Infrastructure mode), connect to that instead.
Open a web browser and navigate to http://172.16.1.1, or find Slice using Bonjour.
2
Slice's Wi−Fi can also be configured to join your network via the web UI or front panel.
3
CONNECT VIA ETHERNET
Plug an Ethernet cable into Slice's 10/100/1000 Ethernet port and connect it to an Ethernet switch
1
or router. Use the Menu joystick to navigate to the Network Setup menu, and verify that Ethernet is
enabled and set to DHCP.
Connect your computer to the same network as Slice. From the main status screen, press
2
joystick to display Slice's IP address on the front panel.
Open a web browser and navigate to Slice's IP address, or find Slice using Bonjour.
3
HEVC AND H.264
Slice 700 series encoders support 1080p, 60fps encoding using both HEVC and H.264 codecs. HEVC
provides the most efficient encoding for both low bitrate and high quality applications, while H.264
supports a wider variety of streaming platforms and is one of the most common video codecs worldwide.
The codec can be switched between HEVC and H.264 from the Encoder Settings and Video Stream Output
settings pages on the web UI, or from the Video Setup menu on the front panel.
NEED MORE HELP?
1. Support: http://support.teradek.com → Contains tips, information and all the latest firmware & software updates.
TERADEK SUPPORT STAFF: support@teradek.com or call 888−941−2111 ext2 (Mon−Fri 9am to 6pm PST)
2
on Slice's menu
▼
