Teradek PRISM User Manual

Hide thumbs Also See for PRISM:
Table of Contents

Advertisement

Quick Links

Download this manual
P
RISM
© 2024 Teradek, LLC. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRISM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Teradek PRISM

Summary of Contents for Teradek PRISM

  • Page 1 RISM © 2024 Teradek, LLC. All rights reserved.

  • Page 2: Table Of Contents

    Prism Mobile Quick Start Guide ......................31 Prism Mobile Backpack Quick Start Guide ..................45 Guia de instalação rápida Prism Mobile .................... 60 Prism Flex Mk II Quick Start Guide (2024) ..................74 Physical Properties Prism 1RU Chassis ..........................87 Prism 2RU Chassis ..........................
  • Page 3 Other Platforms ..........................169 Network/System Configuration Network Configuration ........................181 System Configuration ........................183 Technical Specifications Prism 4K 1RU/2RU ..........................183 Prism HD+ 1RU/2RU ......................... 186 Prism Flex ............................189 Prism Mobile ............................. 192 Regulatory Information Support Resources ..........................194 Disclaimer ............................

  • Page 4: Prism Flex Quick Start Guide

    Flex is perfect for placement on a table top, camera-top, or wedged between your video switcher and audio mixer. Prism Flex can encode or decode up to 4Kp60 video with stunning 10-bit 4:2:2 image fidelity. The Prism platform supports many common streaming protocols such as MPEG-TS, RTSP/RTP, RTMPS, and SRT, and can be connected to Teradek’s Core Cloud Platform for even more...
  • Page 5 Teradek User Manual TABLE OF CONTENTS...
  • Page 6 OTHER RESOURCES PHYSICAL PROPERTIES - ENCODER OR DECODER WHAT'S INCLUDED • 1x Prism Flex Encoder/Decoder • 1x 12G-SDI BNC to BNC - 18in Cable • 1x 2pin Connector to 30W AC Adapter (Int) - 6ft Cable • 2x Antenna 2dBi WIFI 2.4/5.8GHz POWER AND CONNECT 1.
  • Page 7 Teradek User Manual Decoder: Turn your monitor on, then connect the HDMI or SDI output (K) from your Prism Flex to the monitor’s input connector. 2. Attach the two Wi-Fi antennas to the RP-SMA connectors (C). 3. Connect power to Prism Flex using the included A/C adapter.
  • Page 8 Connect via Node II or USB Modem 1. Attach a Node II or USB modem to one or both to Prism’s USB-C ports (G) using a 4-pin to USB-C connector cable, and/or a USB to USB-C adapter. The front panel will indicate that the modem has been detected and connected to the carrier.
  • Page 9 Teradek User Manual Configure Node II 1. Navigate to the Network menu and select the corresponding USB (Node II) modem. 2. Select the slot with the SIM you will be using (Slot 1 or Slot 2). NOTE: Node II supports most provider's SIM card and can operate on most LTE/4G/3G data ...
  • Page 10 Teradek User Manual 3. Enter altanwifi (for Telna SIM cards intended for use in the United States) or internet (for Telna SIM cards intended for use in Europe) into the selected slot's APN field (Slot 1 or 2). Prism Page 10...
  • Page 11 Teradek User Manual 4. Ensure that both Configuration mode and Authentication method are set to Auto. ENCODER/DECODER CONFIGURATION Configure your Prism Flex decoder to receive streams from a Prism Flex encoder. Prism Page 11...
  • Page 12 1. Connect to the Prism Flex encoder (see previous section) and open the encoder’s web UI. 2. Open the Streaming menu, then select MPEG-TS as the streaming mode. 3. Select a protocol, then ensure the Prism decoder is configured to receive the stream using the correct protocol: ◦...
  • Page 13 Decoder Web UI PRISM APP The Prism App allows you to remotely configure all of Prism Flex’s settings while monitoring your stream’s destination, bitrate, bonding status, and resolution to ensure you maintain a stable stream. The Prism App is available for iOS devices.
  • Page 14 • Link/Unlink iOS Device - Tap the Link/Unlink iOS tab to enable/disable the use of your cellular phone’s data as an Internet connection. STATS Tap the Stats button at the top of the screen to display Prism’s serial number, current audio and video bitrates, runtime, recording status, IP address, and network. SETTINGS Tap the Settings button to configure the following options: •...
  • Page 15 Teradek User Manual RECORDING Prism Flex encoders support recording to an SD card, USB drive, or NFS. Each recording is saved with the same resolution and bitrate set in Prism Flex. 1. Insert a compatible SD card into the corresponding slot.
  • Page 16 1. From the web UI, select Cloud Services then click the Link this Device tab. 2. Log in to Core: Enter your credentials to link Prism to your Core account, then click Next. Link with Code: Copy the authorization code generated for your Prism, then follow the instructions provided.
  • Page 17 Teradek User Manual 3. Once a connection is established, you can configure Prism from either the Prism UI or Core dashboard. OTHER RESOURCES • USER GUIDE ARTICLES: https://guide.teradek.com/m/109577 • PRISM FLEX QUICK START GUIDE PDF: https://teradek.com/pages/downloads#prism • PRISM REFERENCE GUIDE PDF: https://teradek.com/pages/downloads#prism...

  • Page 18: Prism Quick Start Guide

    Pro AV applications. With room for up to nine codec cards in a 2U chassis (up to three codec cards in 1U chassis), Prism can encode or decode up to 4Kp60 video (1080p60 video for Prism HD+) with stunning 10-bit 4:2:2 image fidelity. Prism supports many common streaming protocols such as MPEG-TS, RTP, RTMPS, and SRT.
  • Page 19 Teradek User Manual TABLE OF CONTENTS...
  • Page 20 Teradek User Manual PHYSICAL PROPERTIES WHAT'S INCLUDED POWER AND CONNECT GET ONLINE ENCODER/DECODER CONFIGURATION PRISM APP CORE OTHER RESOURCES PHYSICAL PROPERTIES RACK SYSTEM 2RU Prism Page 20...
  • Page 21 DUAL GIGABIT ETHERNET PORTS  Prism features two independent Ethernet ports (Wired 1, Wired 2). These two Ethernet ports connect to an internal switch inside the chassis (one per Ethernet port), allowing an encoder/ decoder card to have two addressable ports as well as two different networks. For example, one port can connect to an internal network for configuration while the other port can connect to a separate network for streaming.
  • Page 22 1. Connect SD/HD-SDI video sources to the BNC inputs that correspond to the installed encoder or decoder cards. 2. Connect SD/HD-SDI outputs via BNC cable to your monitor/switcher/router. 3. Connect one or both of Prism’s 10/100/1000 Ethernet ports to a network switch or router using an Ethernet cable. Prism...
  • Page 23 6. Using the menu joystick, navigate to the Network Settings menu on the front panel. Select a Wired interface, then verify that the IP Mode is set to DHCP. Once Prism is connected to a network, the front panel will display the current assigned or configured IP address for both Ethernet ports.
  • Page 24 1. Using the menu joystick, navigate to the Network Settings menu on the front panel. Select a Wired interface, then verify that the IP Mode is set to DHCP. 2. Once Prism is connected to a network, the front panel will display the current assigned or configured IP address for both Ethernet ports.
  • Page 25 1. Connect to the Prism encoder (see previous section) and open the encoder’s web UI. 2. Open the Streaming menu, then select MPEG-TS as the streaming mode. 3. Select a protocol, then ensure the Prism decoder is configured to receive the stream using the correct protocol: ◦...
  • Page 26 Decoder Web UI PRISM APP The Prism App allows you to remotely configure all of Prism’s settings while monitoring your stream’s destination, bitrate, bonding status, and resolution to ensure you maintain a stable stream. The Prism App is available for iOS devices.
  • Page 27 • Link/Unlink iOS Device - Tap the Link/Unlink iOS tab to enable/disable the use of your cellular phone’s data as an Internet connection. STATS Tap the Stats button at the top of the screen to display Prism’s serial number, current audio and video bitrates, runtime, recording status, IP address, and network. SETTINGS Tap the Settings button to configure the following options: •...
  • Page 28 Prism can be remotely accessed, configured, and controlled using Teradek’s Core Cloud management and routing service. With Core, you can: • Bond multiple Internet connections, increasing your broadcast’s bandwidth and reliability. • Remotely control Teradek encoders, decoders and bonded systems from anywhere in the world. • Stream to multiple destinations. Visit https://corecloud.tv...
  • Page 29 1. From the web UI, select Cloud Services then click the Link this Device tab. 2. Log in to Core: Enter your credentials to link Prism to your Core account, then click Next. Link with Code: Copy the authorization code generated for your Prism, then follow the instructions provided.
  • Page 30 Teradek User Manual OTHER RESOURCES • USER GUIDE ARTICLES: https://guide.teradek.com/m/109577 • PRISM QUICK START GUIDE PDF: https://teradek.com/pages/downloads#prism • PRISM REFERENCE GUIDE PDF: https://teradek.com/pages/downloads#prism Prism Page 30...

  • Page 31: Prism Mobile Quick Start Guide

    Prism Mobile is designed to seamlessly fit onto the back of your ENG or professional camera or placed directly on a table top. Prism Mobile can encode up to 4Kp60 video with stunning 10-bit 4:2:2 image fidelity paired with Stereo or 5.1 surround sound. The Prism platform supports many common streaming protocols such as MPEG-TS, RTSP/RTP, RTMPS, and SRT, and can be connected to Teradek’s Core Cloud Platform for even more flexibility.
  • Page 32 Teradek User Manual TABLE OF CONTENTS...
  • Page 33 • 4x SMA Antennas (Male) • 4x High-performance SMA Antennas (Male) • 2x SIM Card Holder POWER AND CONNECT 1. Turn your video source on, then connect the HDMI or SDI video input to Prism Mobile’s input connector (J). Prism Page 33...
  • Page 34 4. Turn the Power switch (L) to the ON position. 5. Insert a SIM card (two per Node II) into one of the Prism Mobile SIM card slots. NOTE: Prism Mobile is equipped with two internal modems (A and B). Each modem supports two SIM cards (A1/A2, B1/ B2).
  • Page 35 IP address. Connect via Ethernet 1. Connect one or both of Prism Mobile’s Ethernet ports to an Ethernet switch or router. 2. Press the menu button or navigation joystick to navigate to the Ethernet 1 or 2 screen and obtain the IP address.
  • Page 36 1. From the web UI, select Cloud Services then click the Link this Device tab in the Core section. 2. Log in to Core: Enter your credentials to link Prism to your Core account, then click Next. Link with Code: Copy the authorization code generated for your Prism, then follow the instructions provided.
  • Page 37 Teradek User Manual 3. Once a connection is established and your Prism Mobile is listed under Sources, you can connect Prism Mobile to a server using the Core dashboard. Connect to a Server 1. From the Sources tab, select your Prism Mobile by clicking on the name of the device.
  • Page 38 Teradek User Manual 3. Select a server, then click Connect to a server. 4. Under Connected Stream in the Encoder Details, click + Link Destination to connect channels or decoders to stream to. Prism Page 38...
  • Page 39 Connect via Cellular Modem 1. Insert a SIM card (two per Node II) into one of the Prism Mobile SIM card slots. Additionally, you can connect an external modem to either Prism Mobile USB port (G) using a 5-pin to USB connector cable.
  • Page 40 Teradek User Manual 2. Select the slot with the SIM you'll use (Slot 1 or Slot 2). NOTE: Most carriers' SIMs will auto-connect, requiring no additional configuration. Additional configuration is only required when entering an APN, PIN, or authentication type.
  • Page 41 (for Telna SIM cards intended for use in Europe) in the selected slot's APN field (Slot 1 or 2). Ensure that the Authentication method is set to Auto. If using Teradek Data SIM cards: Click the Teradek Data checkbox, then select either Native or Multi- Carrier. For Multi-Carrier, select one of the available networks.
  • Page 42 STATS Tap the Stats button at the top of the screen to display Prism’s serial number, current audio and video bitrates, runtime, recording status, IP address, and network.
  • Page 43 • System - View your device's model and serial number, or rename the Prism. RECORDING Prism Mobile encoders support recording to an SD card or external USB hard drive. Each recording is saved with the same resolution and bitrate set in the Input / Encoding menu.
  • Page 44 Teradek User Manual OTHER RESOURCES • USER GUIDE ARTICLES: https://guide.teradek.com/m/109577 • PRISM MOBILE FIRMWARE AND GUIDE PDFs: https://teradek.com/pages/downloads#prism- mobile • PRISM REFERENCE GUIDE PDF: https://teradek.com/pages/downloads#prism Prism Page 44...

  • Page 45: Prism Mobile Backpack Quick Start Guide

    Teradek User Manual Prism Mobile Backpack Quick Start Guide Supercharge your Prism Mobile with the Prism Mobile Backpack, our latest accessory that packs up to 4 additional high-performance Node 5G modems for unbeatable cellular connectivity in the field. That means you can stream over 6 cellular connections simultaneously for the ultimate on-the-go streaming experience.
  • Page 46 Teradek User Manual TABLE OF CONTENTS...
  • Page 47 Teradek User Manual PHYSICAL PROPERTIES WHAT'S INCLUDED POWER AND CONNECT GET ONLINE PRISM APP RECORDING OTHER RESOURCES PHYSICAL PROPERTIES Prism Mobile Backpack Prism Page 47...
  • Page 48 Teradek User Manual Prism Mobile Encoder Node 5G WHAT'S INCLUDED • 1x Prism Mobile Encoder • 4x Node 5G Q 5G/LTE - Quectel Assembly • 1x PSU D-Type Charger with D Tap Cable for V and Gold Mount Battery Prism...
  • Page 49 7. Turn the Power switch (L) to the ON position. 8. Insert a SIM card (two per Node II) into one of the two Prism Mobile SIM card slots. NOTE: Prism Mobile is equipped with two internal modems (A and B). Each modem supports two SIM cards (A1/ A2, B1/B2).
  • Page 50 GET ONLINE Connect to a Wi-Fi Network Prism Mobile supports two wireless (Wi-Fi) modes: Access Point (AP) Mode (default mode for bonding multiple cellular devices for increased bandwidth, and connecting directly to Prism Mobile) and Client Mode (for normal Wi-Fi operating and connecting to your local router). Use the front panel's menu button and navigation joystick to switch to either Wi-Fi mode or a different network.
  • Page 51 IP address. Connect via Ethernet 1. Connect one or both of Prism Mobile’s Ethernet ports to an Ethernet switch or router. 2. Press the menu button or navigation joystick to navigate to the Ethernet 1 or 2 screen and obtain the IP address.
  • Page 52 Teradek User Manual 2. Log in to Core: Enter your credentials to link Prism to your Core account, then click Next. Link with Code: Copy the authorization code generated for your Prism, then follow the instructions provided. 3. Once a connection is established and your Prism Mobile is listed under Sources, you can connect Prism Mobile to a server using the Core dashboard.
  • Page 53 Teradek User Manual 2. Click the Connect video to Core tab, then select Streaming Server (Helios). If you haven't configured a server to your Core account, review this tutorial for steps on how to launch a new server. 3. Select a server, then click Connect to a server.
  • Page 54 Connect via Cellular Modem 1. Insert a SIM card (two per Node II) into one of the Prism Mobile SIM card slots. Additionally, you can connect an external modem to either Prism Mobile USB port (G) using a 5-pin to USB connector cable.
  • Page 55 Teradek User Manual 2. Select the slot with the SIM you will be using (Slot 1 or Slot 2). NOTE: Most carriers' SIMs will auto- connect, requiring no additional configuration. Additional configuration is only required when you need to enter an APN, PIN, or authentication type.
  • Page 56 (for Telna SIM cards intended for use in Europe) in the selected slot's APN field (Slot 1 or 2). Ensure that the Authentication method is set to Auto. If using Teradek Data SIM cards: Click the Teradek Data checkbox, then select either Native or Multi- Carrier. For Multi-Carrier, select one of the available networks.
  • Page 57 STATS Tap the Stats button at the top of the screen to display Prism’s serial number, current audio and video bitrates, runtime, recording status, IP address, and network.
  • Page 58 • System - View your device's model and serial number, or rename the Prism. RECORDING Prism Mobile encoders support recording to an SD card or external USB hard drive. Each recording is saved with the same resolution and bitrate set in the Input / Encoding menu.
  • Page 59 Teradek User Manual OTHER RESOURCES • USER GUIDE ARTICLES: https://guide.teradek.com/m/109577 • PRISM MOBILE FIRMWARE AND GUIDE PDFs: https://teradek.com/pages/downloads#prism- mobile • PRISM REFERENCE GUIDE PDF: https://teradek.com/pages/downloads#prism Prism Page 59...

  • Page 60: Guia De Instalação Rápida Prism Mobile

    Teradek User Manual Guia de instalação rápida Prism Mobile O Prism Mobile é o codificador de vídeo de câmera traseira habilitado para LTE mais leve do mercado. Com um I/O flexível e compacto e um design low-SWAP, o Prism Mobile facilmente se encaixa em qualquer fluxo de trabalho.
  • Page 61 Teradek User Manual ÍNDICE...
  • Page 62 1. Ligue a sua fonte de vídeo, e em seguida conecte a entrada de vídeo HDMI ou SDI ao conector de entrada do Prism Mobile (J). 2. Conecte quatro antenas aos conectores SMA (C). NOTA: O Prism Mobile usa apenas antenas SMA. As antenas Wi-Fi padrão (RP-SMA) não são compatíveis e não funcionarão com o Prism Mobile.
  • Page 63 4. Coloque o botão on/off (L) na posição ON. 5. Insira um cartão SIM (dois por Node II) em um dos slots de cartão SIM do Prism Mobile. NOTE: O Prism Mobile está equipado com dois modems internos (A e B). Cada modem suporta dois cartões SIM (A1/A2, B1/B2).
  • Page 64 FICAR ONLINE Conectar à rede Wi-Fi O Prism Mobile oferece suporte para dois modos sem fio (Wi-Fi): Modo Ponto de Acesso (AP) (modo padrão para conectar vários dispositivos celulares para aumentar a largura de banda e conectar-se diretamente ao Prism Mobile) e Modo Cliente (para operação Wi-Fi normal e conexão com seu roteador local).
  • Page 65 1. Na interface do usuário da web, selecione “Cloud Services” e clique na aba “Link this Device” na seção “Core”. 2. Logar no Core: insira suas credenciais para vincular o Prism à sua conta do Core e clique em Avançar (Next).
  • Page 66 Teradek User Manual 3. Depois que uma conexão for estabelecida e seu Prism Mobile estiver listado em “Sources”, você poderá conectar o Prism Mobile a um servidor usando o painel do Core. Conectar a um servidor 1. Na aba Sources, selecione seu Prism Mobile clicando no nome do dispositivo.
  • Page 67 Teradek User Manual 3. Selecione um servidor e clique em Connect to a server. 4. Em Connected Stream em Encoder Details, clique em + Link Destination para conectar canais ou decodificadores para quais transmitir. Prism Page 67...
  • Page 68 Conectar via Modem de Celular 1. Insira um cartão SIM (dois por Node II) em um dos slots de cartão SIM do Prism Mobile. Além disso, você pode conectar um modem externo à porta Prism Mobile USB (G) usando um cabo conector de 5 pinos para USB.
  • Page 69 Teradek User Manual 2. Selecione o slot com o SIM que você usará (Slot 1 ou Slot 2). NOTA: Os SIMs da maioria das operadoras se conectarão automaticamente, sem necessidade de configuração adicional. A configuração adicional só é necessária quando você precisa inserir um APN, PIN ou algum tipo de autenticação.
  • Page 70 (Slot 1 ou 2). Certifique-se de que o método de autenticação esteja definido como Automático. Se estiver usando cartões SIM Teradek Data: Clique na caixa de seleção Teradek Data e selecione Native ou Multi- Carrier. Para Multi-Carrier, selecione uma das redes disponíveis.
  • Page 71 Configurações, a gravação deve ser habilitada e uma opção de armazenamento de mídia deve ser selecionada. ESTATÍSTICAS Toque no botão Stats na parte superior da tela para exibir o número de série do Prism, taxas de bits de áudio e vídeo atuais, tempo de execução, status de gravação, endereço IP e rede. CONFIGURAÇÕES Toque no botão Configurações (Settings) para configurar as seguintes opções:...
  • Page 72 Ci) para fazer login. • Rede (Network) - Escolha um método de conexão com a Internet. • Sistema (System) - Visualize o modelo e o número de série do seu dispositivo ou renomeie o Prism. GRAVAÇÃO Os codificadores Prism Mobile suportam a gravação em um cartão SD ou disco rígido USB externo.
  • Page 73 • Novas gravações são automaticamente iniciadas depois que o limite de tamanho de arquivo é alcançado. OUTROS RECURSOS • ARTIGOS DE GUIA DO USÁRIO: https://guide.teradek.com/m/109577 • PRISM MOBILE FIRMWARE E GUIA EM PDF: https://teradek.com/pages/downloads#prism-mobile • GUIA DE REFERÊNCIA DO PRISM EM PDF: https://teradek.com/pages/downloads#prism Prism Page 73...

  • Page 74: Prism Flex Mk Ii Quick Start Guide (2024)

    With a flexible I/O and compact, low-SWaP design, Prism Flex Mk II easily fits into any workflow. Prism Flex Mk II is perfect for placement on a table top, camera-top, or wedged between your video switcher and audio mixer. Prism Flex Mk II can encode or decode up to 4Kp60 video with stunning 10-bit 4:2:2 image fidelity.
  • Page 75 Teradek User Manual TABLE OF CONTENTS...

  • Page 76: Physical Properties

    1. Encoder: Turn your video source on, then connect the HDMI (I) or SDI input (M) from your video source to Prism Flex’s input connector. Decoder: Turn your monitor on, then connect connect the HDMI (I) or SDI output (L) from your Prism Flex to the monitor’s input connector.
  • Page 77 Teradek User Manual 2. Attach the two Wi-Fi antennas to the RP-SMA connectors (D). 3. Connect power to Prism Flex using the included A/C adapter. 4. Turn the Power switch on the back (N) to the ON position. MENU BUTTON OPERATION (A) ...
  • Page 78 NOTE: Use the Menu Navigation buttons on the front panel to navigate to the Ethernet screen (1 or 2) and switch from DHCP to Static Mode or a different network. 1. Connect your phone or laptop to Prism Flex’s network, Prism-855 XXXXX (XXXXX represents the last five digits of Prism’s serial number).
  • Page 79 Connect via Node 5G or Node II 1. Attach a Node 5G or Node II to Prism’s USB port (G) using a 5-pin to USB connector cable, and/or attach another Node to Prism's 5-pin USB input (H) using a 5-pin to 5-pin connector. The front panel will indicate that the modem has been detected and connected to the carrier.
  • Page 80 LTE/4G/3G data bands. With dual SIM slots, you can switch from one provider to another without unplugging the Node II. Only one SIM card can be used at a time. 3. Select Teradek Data Priority or Teradek Data Standard (depending on your SIM and plan) from the Configuration drop-down menu.
  • Page 81 Teradek User Manual 4. Set the Teradek Carrier Mode to Auto Carrier. For Carrier Locking mode, click here. 5. Click Save when you're done. ENCODER/DECODER CONFIGURATION Configure your Prism Flex decoder to receive streams from a Prism Flex encoder. Prism...
  • Page 82 1. Connect to the Prism Flex encoder (see previous section) and open the encoder’s web UI. 2. Open the Streaming menu, then select MPEG-TS as the streaming mode. 3. Select a protocol, then ensure the Prism decoder is configured to receive the stream using the correct protocol: ◦...
  • Page 83 Decoder Web UI PRISM APP The Prism App allows you to remotely configure all of Prism Flex’s settings while monitoring your stream’s destination, bitrate, bonding status, and resolution to ensure you maintain a stable stream. The Prism App is available for iOS devices.
  • Page 84 • Link/Unlink iOS Device - Tap the Link/Unlink iOS tab to enable/disable the use of your cellular phone’s data as an Internet connection. STATS Tap the Stats button at the top of the screen to display Prism’s serial number, current audio and video bitrates, runtime, recording status, IP address, and network. SETTINGS Tap the Settings button to configure the following options: •...
  • Page 85 • New recordings are automatically started after the file size limit is reached. CORE Prism Flex can be remotely accessed, configured, and controlled using Teradek’s Core Cloud management and routing service. With Core, you can: • Bond multiple Internet connections, increasing your broadcast’s bandwidth and reliability.
  • Page 86 1. From the web UI, select Cloud Services then click the Link this Device tab. 2. Log in to Core: Enter your credentials to link Prism to your Core account, then click Next. Link with Code: Copy the authorization code generated for your Prism, then follow the instructions provided.

  • Page 87: Prism 1Ru Chassis

    DUAL ETHERNET PORTS  Prism chassis features two independent Ethernet ports (Wired 1, Wired 2). These two Ethernet ports connect to an internal switch inside the chassis (one per Ethernet port), allowing an encoder/decoder card to have two addressable ports as well as two different networks. For example, one port can connect to an internal network for configuration while the other port can connect to a separate network for streaming.

  • Page 88: Prism 2Ru Chassis

    DUAL ETHERNET PORTS  Prism chassis features two independent Ethernet ports (Wired 1, Wired 2). These two Ethernet ports connect to an internal switch inside the chassis (one per Ethernet port), allowing an encoder/decoder card to have two addressable ports as well as two different networks. For example, one port can connect to an internal network for configuration while the other port can connect to a separate network for streaming.

  • Page 89: Card Operation

    Teradek User Manual Card Operation Use the Menu joystick to navigate the front panel interface and the Reboot button to restart Prism. MENU NAVIGATION BUTTON Use Prism Menu Navigation button to navigate the status screens, go live, switch your ...
  • Page 90 Teradek User Manual WARNING:  Prism contains sensitive electronic components that can be damaged by electrostatic discharge (ESD). When handling, care must be taken so that the device is not damaged. Damage due to inappropriate handling is not covered by the warranty.

  • Page 91: Prism Flex

    Teradek User Manual Prism Flex MENU BUTTON OPERATION Use Prism Flex’s Menu button to navigate the status screens, go live, switch your configurable  settings, and perform a factory reset. PRESS BUTTON: Cycle through the status screens Prism Page 91...
  • Page 92 Teradek User Manual LONG-PRESS BUTTON: • System screen - Perform factory reset • WiFi screen - Switch from AP to Client mode • Wired screen - Switch from DHCP to Static mode • Stream mode screen - Go Live/Begin Streaming •...

  • Page 93: Prism Mobile

    Prism Mobile MENU BUTTON/NAVIGATION JOYSTICK OPERATION MENU BUTTON OPERATION (A) Use Prism Mobile’s Menu button to navigate the status screens. Press Button: Cycle through the status screens NAVIGATION JOYSTICK OPERATION (C) Use the Navigation Joystick to cycle back and forth through the status screens and/or switch your configurable settings.
  • Page 94 Teradek User Manual Press Up or Down: Cycle through status screens and navigate menus Press Forward: Edit Prism Mobile's configurable settings • Main screen - Displays the current stream settings and resolution • WiFi screen - Displays the current WiFi network and allows you to switch from AP to Client mode •...
  • Page 95 Teradek User Manual FUNCTIONS • CORE: Core • Dotted line: Not Linked to Core • Solid line: Linked to Core • Solid white: Streaming to Core • WiFi: Wireless • Dotted line: • Client Mode: Disabled • Access Point Mode: Disabled •...

  • Page 96: Debonding Decoder License

    The Debonding Decoder license allows users to receive a stream via a built-in Hyperion server (used for Teradek Bonding Protocol), decode that stream to SDI or HDMI, and re-stream further on. It can also ingest generic streaming protocols to decode and send on.
  • Page 97 Supported Input Protocols The Debonding Decoder supports the following ingest types which will be passed onto the decoder • Teradek Bonding Protocol (Most used) • RTSP • MPEG TS •...
  • Page 98 1. Navigate to the IP address of the Prism Flex or Prism RU decoder to open the decoder web UI. 2. From the decoder’s web UI, open Licenses and click the Enter License Key tab to enter the Debonding Decoder license key.
  • Page 99 Teradek User Manual 3. Open the Ingest tab above and set the Ingest Mode to Hyperion. 4. Scroll down and click + Add Ingest, then choose Teradek Bonding from the Stream Ingest options. Next, configure the Prism Encoder to transmit to the Debonding Decoder (see below).
  • Page 100  • Teradek Bonding - Select this mode to stream to Core or another Hyperion Server (uncommon) • MPEG Transport Stream - Prism sends video via a TCP or UDP protocol to a specified unicast or multicast address. Prism Page 100...
  • Page 101 IP address on a specific port. A port number and a passphrase (if encryption is enabled) are needed. • RTSP - Prism sends video via a TCP or UDP protocol to a specified IP address. Ensure you have the correct port and stream name (stream1 is the default).
  • Page 102 Teradek User Manual Setup the Encoder to Stream to the Debonding Decoder 1. From the encoder’s web UI, open the Input/Encoding tab and set the Stream Mode to Teradek Cloud. 2. Enter the details • Host: Public IP (whether port forwarded or not) •...

  • Page 103: Card Installation (Prism1Ru/2Ru)

    Teradek User Manual 3. Click Save and the encoder will start to stream video. Card Installation (Prism1RU/2RU) 1. Attach the card’s Video/Audio backplate to the back of any of the rack unit’s card slots. Secure it in place with the included screws, but do not tighten.

  • Page 104: Power And Connect

    4. Turn the Power switch (L) to the ON position. 5. Insert a SIM card (two per Node II) into one of the Prism Mobile SIM card slots. NOTE: Prism Mobile is equipped with two internal modems (A and B). Each modem supports two SIM cards (A1/A2, B1/ B2).
  • Page 105 Once Prism is connected to a network, you can access the web UI and configure stream destinations, encoder parameters, and other settings for each card. 1. Prism 1RU/2RU: Press ▼ on the card’s menu joystick to display Prism’s IP address on the front panel.

  • Page 106: Connect To A Network

    2. PRISM 1RU/2RU: Press ▼ on the card’s menu joystick to display Prism’s IP address on the front panel. PRISM FLEX: Press the menu button to navigate to the Ethernet 1 or 2 screen and obtain the IP address. 3. Enter the IP address in your web browser’s navigation bar to access the web UI.
  • Page 107 Prism Flex 1. Attach a Node II or USB modem to one or both to Prism’s USB-C ports using a 4-pin to USB-C connector cable, and/or a USB to USB-C adapter. The front panel will indicate that the modem has been detected and connected to the carrier.
  • Page 108 Teradek User Manual 2. If the SIM card is not detected, connect your computer to Prism’s AP network (see WIRELESS NETWORK), then enter the default IP address 172.16.1.1 in the navigation bar to access the web UI and configure the internal modem from the Network menu.
  • Page 109 Teradek User Manual Node II supports most provider's SIM cards and can operate on most LTE/4G/3G data bands.  With dual SIM slots, you can swap from one provider to another without needing to unplug the Node II. Only one SIM card can be used at a time.
  • Page 110 Teradek User Manual If using Teradek Data SIM cards: Click the Teradek Data checkbox, then select either Native or Multi- Carrier. For Multi-Carrier, select one of the available networks. Prism Page 110...

  • Page 111: Encoder/Decoder Configuration

    1. Connect to the Prism encoder and open the encoder’s web UI. 2. Open the Streaming menu, then select MPEG-TS as the streaming mode. 3. Select a protocol, then ensure the Prism decoder is configured to receive the stream using the correct protocol: •TCP →...
  • Page 112 Teradek User Manual 8. Enter the protocol, ensuring the selected protocol matches the Encoder’s protocol configuration (see step 3). Confirm the port is set to 9710 (default). 9. Click Save. Prism Page 112...

  • Page 113: Prism App

    Link/Unlink iOS Device - Tap the Link/Unlink iOS tab to enable/disable the use of your cellular phone’s data as an Internet connection. STATS Tap the Stats button at the top of the screen to display Prism’s serial number, current audio and video bitrates, runtime, recording status, IP address, and network. SETTINGS...

  • Page 114: Card/Device Configuration

    • System - View the model and serial number of your device, or rename your Prism. Card/Device Configuration Prism has a number of options available to suit your IT and video workflow requirements. Each Prism encoder and decoder card can be configured using its own built-in web interface, which is accessible over your Ethernet network.
  • Page 115 Teradek User Manual Prism Page 115...

  • Page 116: Streaming - Encoder/Decoder

    Teradek User Manual Streaming - Encoder/Decoder Prism encoders are capable of encoding and streaming video to Prism decoders using several different protocols by configuring your decoder card to receive streams from the encoder. Choose the Stream Mode and Stream Output that are best for your application. Depending on the video’s destination, you can pick from a variety of different stream modes, each with its own set of configurable settings described here.
  • Page 117 H.264 and HEVC encoders. MPEG TRANSPORT STREAM (MPEG-TS) In MPEG Transport Stream Mode, Prism sends video via a TCP or UDP protocol to a specified unicast or multicast address. TCP is recommended when streaming over the Internet, while UDP is recommended when streaming over a local network to avoid the additional network overhead of TCP.
  • Page 118 Teradek User Manual CONFIGURABLE SETTINGS • Protocol (UDP/TCP/TCP Server/Multicast) • TCP Server Port • Server Queue • Max Clients • Local Stream Settings - Password SRT is used to transmit high-quality, low-latency video over unreliable networks. SRT has two connection types: Listener and Caller.
  • Page 119 • Send Audio Independently RTMP (H.264 only) RTMP mode allows Prism to stream to other video platforms, CDNs, and streaming servers that are not one of the available Internet Streaming platforms (see below). RTMP is supported by most video streaming platforms, but you must first obtain a URL and stream key/name from the service you choose to stream to.
  • Page 120 - Username - Password STREAMING PLATFORMS Prism features native integration with some of the most popular streaming platforms. Select a Stream Mode (Facebook, YouTube Live, Vimeo Livestream, or Wowza), then follow the prompts to link your account. NOTE: Your device must be set to H.264 in order to stream to any streaming platform.
  • Page 121 2. From your computer, log into your Wowza account and select your live stream. 3. Click the Video Source and Transcoder tab, then select Teradek as your encoder. 4. Scroll down and click Regenerate Connection Code. You will be returned to your livestream’s home page where your connection code is displayed.
  • Page 122 STREAM OUTPUTS MPEG TRANSPORT STREAM (MPEG-TS) In MPEG Transport Stream Mode, Prism sends video via a TCP or UDP protocol to a specified unicast or multicast address. TCP is recommended when streaming over the Internet, while UDP is recommended when streaming over a local network to avoid the additional network overhead of TCP. Select the protocol best suited for your application needs, and ensure the Prism encoder is configured to stream to the Prism decoders corresponding IP address and port.
  • Page 123 Teradek User Manual specific port for a direct connection. A source or listening port number and a passphrase (if encryption is enabled) are needed for either mode. CONFIGURABLE SETTINGS • Buffer Length • Max Buffer Length • Name • Connection Mode ◦...
  • Page 124 Teradek User Manual RTSP When RTSP mode is enabled, the decoder communicates whether to use the TCP or UDP protocol for the stream. Ensure you have the correct port and stream name (stream1 is the default). To view your stream on VLC, copy the IP address from the Host field, launch VLC and open File>Open Network. Paste the IP address in the URL field, then click Open.

  • Page 125: Input/Encoding

    Teradek User Manual Input/Encoding In addition to configuring your stream type, Prism allows you to control various characteristics of the network video stream. The Encoder settings can be found by clicking Input/Encoding at the top of the web UI. VIDEO SETTINGS •...
  • Page 126 Teradek User Manual • CHROMA SUBSAMPLING - Chroma Subsampling is a compression method that reduces the color information and file size in a signal in favor of luminance data and decreased bandwidth. • CLOSED CAPTIONS - Turn closed captions on and off VIDEO SETTINGS ADVANCED OPTIONS •...
  • Page 127 Prism's Color Management menu lets you manage and apply different looks to incoming video signals using 3D LUT and CDL files saved to your Prism from your computer. You can also link Prism to your LiveGrade account using the web UI.
  • Page 128 Prism from your computer by clicking Select file, then Upload CDL. To delete a file, click Delete CDL. ◦ 3D LUT MODE - Enable or Disable a 3D LUT preset. Enabling 3D LUT mode allows Prism to apply the preset to your preview.
  • Page 129 Teradek User Manual OVERLAY SETTINGS The Overlay settings allow you to place graphics and other media over your live stream. You can create several different overlays. CREATE AN OVERLAY 1. To create an overlay, click the + Add Overlay tab.
  • Page 130 Teradek User Manual 2. From the Overlay editing screen, tap Image on the top right corner to select an image as your overlay, or use the tools to create an overlay. 3. To preview how your Overlay will appear on the live stream, click Preview stream. To return to a transparent background, click Transparent.
  • Page 131 Teradek User Manual 5. From the Overlay settings, click Enabled, then select the overlay you want displayed on your live stream. Click Save when you're done. NOTE: Overlays will not appear unless you click Enabled. The Overlay is now visible on your live stream...
  • Page 132 Teradek User Manual Prism Page 132...

  • Page 133: Output/Decoding

    Teradek User Manual Output/Decoding The Video/Audio Output menu contains several output source configuration options. • OUTPUT FORMAT - Use this option to configure the video output format. The output resolution can be set independently of the video stream resolution. • AUDIO OUTPUT - Configure the audio output. Audio can be enabled or disabled (Mute Audio), and...

  • Page 134: Recording

    Prism, Prism Flex, and Prism Mobile support recording. Prism allows you to configure a network file system (NFS) to store your recorded footage on or record directly to Core. Prism Flex and Prism Mobile allow you to record your broadcasts directly to an SD Card, configure a network file system (NFS) to store your recorded footage or record directly to Core.
  • Page 135 Teradek User Manual RECORD TO SD CARD/USB 1. Insert a compatible SD card or USB drive into the corresponding slot in the back of the unit. 2. Enter the Recording menu, and select Enabled. 3. Create a name for the recording, select a format, then enable Auto-Record (optional).

  • Page 136: Core

    1. From the web UI, select Cloud Services then click the Link this Device tab. 2. Log in to Core: Enter your credentials to link Prism to your Core account, then click Next. Link with Code: Copy the authorization code generated for your Prism, then follow the instructions.
  • Page 137 4. Once a connection is established, you can configure and control Prism from the Core dashboard. CONNECT TO A SERVER 1. From the Sources tab, select your Prism unit by clicking on the name of the device. Prism Page 137...
  • Page 138 Teradek User Manual 2. Click the Connect video to Core tab, then select Streaming Server (Helios). If you haven't configured a server to your Core account, review this tutorial for steps on how to launch a new server. 3. Select a server, then click Connect to a server.
  • Page 139 Teradek User Manual 4. Under Connected Stream in the Encoder Details, click + Link Destination to connect channels or decoders to stream to. Prism Page 139...

  • Page 140: Core Comms

    1. From the web UI, select Cloud Services then click the Link this Device tab. 2. Log in to Core: Enter your credentials to link Prism to your Core account, then click Next. Link with Code: Copy the authorization code generated for your Prism, then follow the instructions.
  • Page 141 Teradek User Manual SHARE A WORKSPACE 1. Click Core Share from the sidebar menu, then select the workspace you will share. 2. Tap the workspace’s Share button to open the Comms Sharing window. 3. Select how you want to share the workspace (email, SMS, or link). To generate a share code Via Email or Via SMS, enter the email address or phone number, then click Send Invitation.
  • Page 142 Teradek User Manual LINK YOUR DEVICE 1. Return to the Prism UI and select Core Comms. 2. Tap Link this Device and enter your email and the code you received. Click Next. Prism Page 142...
  • Page 143 Teradek User Manual 3. Select an Organization (if applicable), then click Connect. Your device is now connected. VIA TEXT (SMS) 1. Copy the share code, and open the URL provided via text. 2. Tap the drop-down menu and select Via Phone Number.
  • Page 144 3. Enter your phone number and the share code provided in the text, then tap login. COMMUNICATE VIA CORE COMMS COMMUNICATE VIA DEVICE 1. Once the device is connected, return to the Prism web UI and select Core Comms. 2. Tap the My Workspaces tab and select a workspace. Prism...
  • Page 145 Teradek User Manual 3. Connect your headphones/microphone to your device. 4. Select the Microphone Input type (USB, Analog Mic, or Analog Line In). 5. Tap the Join Call tab. Prism Page 145...
  • Page 146 Teradek User Manual COMMUNICATE VIA SHARED LINK 1. Click on the shared link you received to open the workspace in your web browser. 2. Click the View stream tab to open the Stream Details. 3. Click Text Chat to communicate via text, then type in your message and press the enter/return button on your keyboard to send the message.
  • Page 147 Teradek User Manual 4. For Voice Chat, click the Voice Chat tab, then click the green phone icon. NOTE: Ensure your headphones/microphone are connected to your computer. You are now able to communicate with other users who have access to the workspace once the other user(s) joins the call.

  • Page 148: Core Share

    Teradek User Manual Core Share Core Share allows anyone to view live video from your Core workspace on any web browser or mobile device running the Core Share app, even if they don't have a Core account. Prism Page 148...
  • Page 149 Teradek User Manual Table of Contents Connect Your Device Share a Workspace • Via Email • Via SMS Unshare a Workspace View a Workspace • Via Email • Via SMS Core Share App • Voice Chat • Text Chat...
  • Page 150 1. From the web UI, select Cloud Services then click the Link this Device tab. 2. Log in to Core: Enter your credentials to link Prism to your Core account, then click Next. Link with Code: Copy the authorization code generated for your Prism, then follow the instructions.
  • Page 151 Teradek User Manual Sharing Via Email 1. Click the Via Email tab. 2. Enter the email address(es) in the Share via email field. 3. Click Sharing Expiration to enter a sharing period (Never or Custom date), then choose whether or not you want to display the watermark.
  • Page 152 Teradek User Manual The people you have shared the workspace with will receive an e-mail like the one pictured below that contains their share code. Sharing Via SMS 1. Click the Via SMS tab. 2. Select the country code, then enter the phone number you wish to share your workspace with.
  • Page 153 Teradek User Manual 3. Click Sharing Expiration to enter a sharing period (Never or enter a Custom date). 4. Click Send Invitation. Core will send an SMS to the phone number you entered containing the share code. Unshare a Workspace To unshare your workspace, return to the Workspaces page and click on any of the icons listed under the name of the workspace.
  • Page 154 Teradek User Manual Click the trash icon to remove the user. View a Workspace View in your Web Browser 1. To view the shared workspace, open the email you received from Core, copy the share code, and then click Open in Core Share app.
  • Page 155 Download here for iOS Download here for Android Core Share on the Teradek Downloads Page 1. Download the Core Share App (iOS /Android). See links above. 2. Ensure the admin has shared a workspace with you. You will receive a share code via either e-mail or SMS.
  • Page 156 Teradek User Manual After logging in, you can see information about the shared workspaces and associated organization. To enter the workspace, simply tap the listing. Once inside the workspace, you can either select the individual sources or if multiple cameras are connected, tap one of the multiview layouts to view 2, 3, or 4 videos at once.
  • Page 157 Teradek User Manual Voice Chat Core Share enables voice and text chat for connected viewers. This permission must be enabled when the workspace is shared. This works for both connected apps, and devices with Core Comms enabled. Visit the Core Comms article for More information on how to enable and use Core Comms with your encoders and decoders: https://guide.teradek.com/a/1744234-core-comms...
  • Page 158 Teradek User Manual Text Chat You can text with other people in a workspace by tapping the text chat icon. Text messages are only visible for currently connected users, messages are not saved for later viewing. Prism Page 158...

  • Page 159: Teradek Tv

    Teradek User Manual Teradek TV Teradek TV is an all-in-one live feed and instant recordings review platform that provides real-time visibility into all stages of production, connecting creatives, producers, executives, and other remote collaborators. • Get Started • Create a Project •...
  • Page 160 Projects list. Connect to Teradek TV To connect your Prism device to Teradek TV, select a project by clicking on the title, then follow the steps to create a Camera (source) to link your device to. Prism...
  • Page 161 Teradek User Manual Create a Camera (Source) 1. From the Prism web UI, select Cloud Services, select Teradek TV, then click the Link this Device tab. 2. Copy the authorization code generated for your Prism device by clicking the Copy tab.
  • Page 162 Teradek User Manual 2. Choose a default name (A Cam, B Cam, C Cam, etc.) or create a name for your camera, then click Next. 3. Select a unit (group) to add your camera to, then click Next. NOTE: Units consist of multiple cameras that can be used for the same project.
  • Page 163 Click Next when done. 6. Confirm how your device is connected to the Internet, then click Next. Your Prism encoder is now connected to the camera and ready to be added to a Space. Click Finish.
  • Page 164 Teradek User Manual Create Spaces 1. Click the settings tab on the top left corner and click Space or the + sign next to the Spaces tab on your dashboard. 2. Enter a name for the space and enable Collaboration.
  • Page 165 Teradek User Manual The Space is now visible in your Dashboard. You can add Cameras and Users to your Space. Add Cameras to a Space To add the Camera, simply drag and drop the Camera's thumbnail into the Space. Prism...
  • Page 166 Teradek User Manual Add Users to a Space 1. To invite Users to collaborate, click the settings tab on the top left corner and select User, or click the + sign next to the Users tab on your dashboard. 2. Enter the user's email address, and select what level of permissions they will granted. Click Add Users when done.
  • Page 167 Teradek User Manual • Administrator: Full access to billing, project settings, cameras, live feeds, recordings, devices, the Sharing Dashboard, and your fellow collaborators. • Coordinator: Full access to the Sharing Dashboard, where you can create Spaces, collections of cameras, live feeds, and recordings shared with various Viewers.
  • Page 168 Teradek User Manual Prism Page 168...

  • Page 169: Other Platforms

    3. Log in to your Frame.io account, then create a project by tapping the + sign next to your account name (see image). 4. Enter a project name, then toggle the C2C Connections switch to enable your Prism device to upload video. Click the Create Project tab.
  • Page 170 Teradek User Manual 5. Click the C2C Connections tab above, then click the Add new device tab (see image). 6. Click the Device ready to connect tab. Prism Page 170...
  • Page 171 Teradek User Manual 7. Enter the authorization code you copied, click Authorize, and then Finish. 8. Once successful, Prism will be listed under the C2C Connections tab (see image). All future recordings will be listed under the Media tab. Prism...
  • Page 172 Connect to PIX 1. From the web UI, select Cloud Services then click the Link this Device tab under PIX. 2. Copy the authorization code generated for your Prism device, then click on the link provided. Prism Page 172...
  • Page 173 4. Click Confirm to authorize your Prism device, then click Allow on the following screen. 5. Return to the PIX section in the Prism web UI and click PIX Device Manager. Click the link icon that corresponds to your device.
  • Page 174 Teradek User Manual 6. Select the project name, then select the folder to which you want your files to be delivered. Click Confirm. Prism Page 174...
  • Page 175 Teradek User Manual 7. Return to the PIX UI and click the Browse Files icon in the upper left corner. Double-click the folder name to view the files. 8. Double-click the file name to view or play the file. Prism...
  • Page 176 Teradek User Manual Sony Ci Upload 4K HDR files automatically and deliver frame-accurate proxies instantly without waiting for dailies or any additional apps. Review, clip, reformat, and share files in minutes without leaving the cloud. With Sony Ci, you can unlock numerous opportunities, such as: •...
  • Page 177 Teradek User Manual 3. Create a name for your encoder/camera, and enter a time frame or expiration date. 4. Click the Create File Request tab. Prism Page 177...
  • Page 178 Teradek User Manual 5. Click Show File Request Code, then click the Copy tab. 6. Return to the Prism web UI Cloud Services section, scroll down to Sony Ci, then click the Link this Device tab. Prism Page 178...
  • Page 179 Teradek User Manual 7. Paste the File Request Code in the corresponding field. 8. In the Recordings tab, set Auto-Record to On Camera Event and the Camera SDI Metadata to the camera you plan to use. Then click Save. NOTE: Ensure that there is an SD card installed.
  • Page 180 Teradek User Manual 9. Turn on Sync with Sony Ci. 10. Click Start Recording at the top of the web UI Prism Page 180...

  • Page 181: Network Configuration

    Teradek User Manual 11. Once the recording has stopped, refresh the Sony Ci web UI to display your newly recorded files. The new clip will also appear in the Recorded Files section of your Prism's web UI. Network Configuration Configure Prism’s network interface and encryption options by opening the Network menu from the web UI.
  • Page 182 CONFIGURABLE OPTIONS • WIFI Mode (WiFi only) - ◦ Access Point (AP): Prism acts as its own dual-band access point, allowing you to connect your device directly to Prism’s AP network, and for bonding multiple cellular devices for increased bandwidth.

  • Page 183: System Configuration

    ◦ Reboot: Restart Prism ◦ Factory Reset: Restore Prism cards to their original settings • FIRMWARE - Check for new updates and upgrade Prism’s firmware to the latest version. If an update is available, simply follow the prompts to complete the firmware update.
  • Page 184 Teradek User Manual VIDEO SD/HD/3G/6G/12G-SDI Video Inputs (75 Ω BNC) SD/HD/3G/6G/12G-SDI 2x SD/HD/3G/6G/12G-SDI (75 Ω Video Outputs (75 Ω BNC loop out) BNC) 4Kp 23.98/29.97/59.94 4Kp 23.98/29.97/59.94 1080p 23.98/29.97/59.94 1080p 23.98/29.97/59.94 1080i 59.94 1080i 59.94 Supported Resolutions 1080PsF 23.98/29.97 1080PsF 23.98/29.97 720p 59.94...
  • Page 185 Teradek User Manual 1”W x 10.9”D x 3.56”H 1”W x 10.9”D x 3.56”H Dimensions [26.1 x 276.5 x 90.5mm] [26.1 x 276.5 x 90.5mm] Weight 12.4oz [352g] 12.4oz [352g] Construction Milled aluminum Milled aluminum INTERFACES Feature-rich web UI for configuration...

  • Page 186: Prism Hd+ 1Ru/2Ru

    Teradek User Manual Prism HD+ 1RU/2RU Prism HD+ Cards ENCODER CARD DECODER CARD VIDEO Video Inputs SD/HD/3G-SDI (75 Ω BNC) Video Outputs SD/HD/3G-SDI (75 Ω BNC loop out) 2x SD/HD/3G-SDI (75 Ω BNC) 1080p23.98/24/25/29.97/30/ 1080p23.98/24/25/29.97/30/ 50/59.94/60 50/59.94/60 Supported 1080psf23.98/24/25/29.97/30 1080psf23.98/24/25/29.97/30 Resolutions 1080i50/59.94/60...
  • Page 187 Teradek User Manual Embedded over SDI, 3.5mm TRRS Audio Input Stereo Line Level Analog or Microphone in, adjustable gain Embedded over SDI, 3.5mm Stereo Audio Output Embedded SDI loop output Headphone (TRRS) output PHYSICAL ATTRIBUTES 1”W x 10.9”D x 3.56”H [26.1 x 276.5 1”W x 10.9”D x 3.56”H...
  • Page 188 Teradek User Manual Remote Teradek Core Teradek Core Prism Chassis (2RU/1RU) PHYSICAL ATTRIBUTES 2U: 17”W x 12.1”D x 3.5”H [431.8 x 307.3 x 88.9 mm] Dimensions 1U: 17”W x 12.1”D x 1.75”H [431.8 x 307.3 x 44.5 mm] Weight 2U: 143oz [4040g], 1U: 87oz [2474g]...

  • Page 189: Prism Flex

    Teradek User Manual Prism Flex ENCODER DECODER VIDEO 1x SD/HD/3G/6G/12G-SDI (75 Ω BNC) Video Inputs 1x HDMI 2.0 Type-A receptacle 2x SD/HD/3G/6G/12G-SDI (75 Ω BNC) Video Outputs 1x SD/HD/3G/6G/12G-SDI (75 Ω BNC) 1x HDMI 2.0 Type-A receptacle 4K DCI p23.98/24/25/29.97/30/59.94 4K DCI p23.98/24/25/29.97/30/59.94...
  • Page 190 Teradek Core, Frame.IO Sony Ci, PIX Integrations Remote Teradek Core Teradek Core Management Ethernet, Wi-Fi, USB modems, Prism Bonding Ethernet, Wi-Fi, USB modems, Prism App AUDIO Audio Support Stereo, 5.1 surround sound Stereo, 5.1 surround sound Audio AAC-LC AAC-LC Compression...
  • Page 191 Teradek User Manual PHYSICAL ATTRIBUTES 6.25”W x 3.6”D x 1.4”H 6.25”W x 3.6”D x 1.4”H Dimensions [162 x 92 x 35mm] [162 x 92 x 35mm] Weight 11.6oz [328.9g] 11.6oz [328.9g] Construction Milled aluminum Milled aluminum Mounting Can be mounted with 1/4-20 mounting...

  • Page 192: Prism Mobile

    Teradek User Manual Prism Mobile VIDEO 1x 12G/6G/3G/HD/SD-SDI (75 Ω BNC) Video Inputs 1x HDMI 2.0 Type-A receptacle Video Outputs 12G/6G/3G/HD/SD-SDI (75 Ω BNC) 4K DCI p23.98/24/25/29.97/30/50/59.94/60 4K UHD UHD p23.98/24/25/29.97/30/50/59.94/60 1080p 23.98/24/25/29.97/30/50/59.94/60 1080i 50/59.94/60 Supported Resolutions 1080PsF 23/24/25/29/30 720p 50/59.94/60...
  • Page 193 Can be mounted using the 1/4” 20 mounting holes INTERFACES Feature-rich Web UI for local device management, configuration, and control, Configuration Intuitive iOS configuration app (Prism App), Interface OLED Status Display w/ Nav control buttons, Core for cloud-based device management Prism...

  • Page 194: Support Resources

    20W Nominal, 36W Max Support Resources In addition to this Reference Guide, you can find more information on Prism's features and operation by visiting www.teradek.com. If you are unable to find what you need online, please contact Teradek’s support staff.

  • Page 195: Disclaimer

    This manual is intended for user information only. Every effort has been made to ensure that the contents within are accurate at the time of printing, and that updates are made in a timely manner. Teradek cannot be held responsible for inaccuracies, typographical errors, or out-of-date information contained within this manual.

  • Page 196: Warning

    Teradek User Manual Warning Prism devices contain sensitive electronic components that can be damaged by electrostatic discharge (ESD). When handling, care must be taken so that the device is not damaged. Damage due to inappropriate handling is not covered by the warranty. For complete warranty information, please see the warranty card that arrived with the device, or visit www.teradek.com/pages/warranty-information.

  • Page 197: Fcc Statement

    Teradek User Manual FCC Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 198: Ec Declaration Of Conformity

    This equipment may be operated in all EU countries with the following restrictions: • 5.15-5.35GHz frequencies for indoor use only Teradek hereby declares that this Radio Transmitter is in compliance with the essential requirements and other relevant provisions of Directives 2014/53/EU and 2011/65/EU. The full text of the EU DoC is located at: https://support.teradek.com/hc/en-us/articles/233429747-EC-Declaration-of-Conformity-...

Table of Contents

Save PDF
