#6: Configurable parameters
1. Color of LED ring
This parameter allows to choose color of LeD ring when device is On.
Available settings: 0 – color dependent on measured active power*
Default setting:
2. Measured power for blue LED ring color
This parameter allows to set power value for blue backlight of LeD ring.
Available settings: 1-2500W – power consumption in Watts
Default setting:
3. Measured power for green LED ring color
This parameter allows to set power value for green backlight of LeD ring.
Available settings: 1-2500W – power consumption in Watts
Default setting:
4. Measured power for yellow LED ring color
This parameter allows to set power value for yellow backlight of LeD ring.
Available settings: 1-2500W – power consumption in Watts
Default setting:
5. Measured power for orange LED ring color
This parameter allows to set power value for orange backlight of LeD ring.
Available settings: 1-2500W – power consumption in Watts
Default setting:
6. Measured power for red LED ring color
This parameter allows to set power value for red backlight of LeD ring.
Available settings: 1-2500W – power consumption in Watts
Default setting:
7. Measured power for violet LED ring color
This parameter allows to set power value for violet backlight of LeD ring.
Available settings: 1-2500W – power consumption in Watts
Default setting:
1 – color dependent on active power measure-
ments with smooth transition between colors*
2 – white, 3 – red, 4 – green, 5 – blue, 6 – yellow,
7 – cyan, 8 – magenta
9 - LeD ring disabled
1 (color dependent on measured active power
with smooth transition between colors)
100W
200W
400W
1000W
1800W
2300W
i
NOTE
* Colors depending on
the measured value:
0W - white
100W - blue
200W - green
400W - yellow
1000W - orange
1800W - red
2300W - violet
i
NOTE
The value of parameter
2 must be lower than
value of parameter 3.
i
NOTE
The value of parame-
ter 3 must be between
values of parameters 2
and 4.
i
NOTE
The value of parame-
ter 4 must be between
values of parameters 3
and 5.
i
NOTE
The value of parame-
ter 5 must be between
values of parameters 4
and 6.
i
NOTE
The value of parame-
ter 6 must be between
values of parameters 5
and 7.
i
NOTE
The value of parameter
7 must be higher than
value of parameter 6.
COnFiGuRABLe PARAMeTeRS
9
