6
FunCTiOnALiTY

#4: Functionality

Turning ON/OFF electrical devices:
The Wall Plug can turn On/OFF connected electrical device either
through iOS mobile app or button.
Multicolor LED ring:
The LeD ring of the Wall Plug glows when device is turned On and dis-
plays current active power consumption. Additionally LeD ring allows
to navigate the built-in menu.
Menu:
The Wall Plug can be operated using the built-in menu.
To enter and navigate the menu:
1. Press and hold the button.
2. Release the button, when the LeD ring glows with desired color:
VIOLET - Wi-Fi range test
RED - reset Wi-Fi settings
GREEN - reset energy counter
YELLOW - factory reset
3. immediately click the button again to confirm selection.
Disabling the LED ring backlight:
1. Press and hold the button for about 3 seconds.
2. Release the button when the LeD ring starts pulsing white.
To restore the LeD ring backlight perform above procedure again.
Active power metering:
The Wall Plug measures current active power consumption of con-
nected device and reports it to your iOS device. Measured value is
indicated with color of the LeD ring.
Active power measuring accuracy is ±1% for loads greater than 5W.
Energy metering:
The Wall Plug counts energy consumed by connected device and re-
ports accumulated value to your iOS device.
To reset energy counter:
1. Press and hold the button.
2. When the LeD glows green, release the button.
3. immediately click the button again to confirm.
