Kensington - 3 Door Mirror Robe

Assembly Instructions -

Dimensions

Width - 125.6cm

Depth - 49.5cm

Height - 198.8cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, please visit www.argos-support.co.uk

or email: Help@ClickSpares.co.uk (quoting your original order number)

Alternatively, call the Spares Helpline on: 0370 112 1928.

For any other queries please contact the Customer Helpline on: 0345 640 2020

Please keep for future reference

411/7542

413/6949

MADE IN

BRITAIN

Issue 1 - 16/06/15

Need help?

Do you have a question about the Kensington 411/7542 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Kensington 411/7542

Page 1 Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928.
Page 2: Care And Maintenance
Take to your local authority waste disposal centre. Components - Panels If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928.
Page 3 Components - Panels If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020...
Page 4 Components - Fittings If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly.
Page 5 Assembly Instructions Step 1 Prepare the divider 10mm Screw 2 metal dowels into the divider Note: Tighten the metal dowels up fully against the panels. Insert 2 large locking nuts into the divider Note: The arrow on the locking nut must point towards the hole in the Finished edge of the panel.
Page 6 Assembly Instructions Step 2 Important: The inner top is very similar to the base but, Prepare the inner top the inner top will only have holes on one surface. Screw 2 metal dowels into the inner top Insert 4 large locking nuts into the inner top Finished...
Page 7 Assembly Instructions Step 5 Fit the wide shelf Push the wide shelf onto the divider Use a screwdriver to tighten the 2 large locking nuts fitted to the wide shelf Finished front edge Step 6 Prepare the base Insert 4 large locking nuts into the base Tap 4 wooden dowels...
Page 8 Assembly Instructions Step 8 Prepare the right side Screw 6 metal dowels into the right side Insert 2 large locking nuts into the right side Finished front edge Tap 2 wooden dowels into the right side Fit 4 hinge plates onto the right side , making...
Page 9 Assembly Instructions Step 10 Prepare the left side Insert 2 large locking Finished nuts into the front edge left side Tap 2 wooden dowels into the left side Fit 4 hinge plates onto the left side , making sure that the slot is facing towards the finished front edge.
Page 10 Assembly Instructions Step 12 Fit the 2 rails Push the 2 rails onto the assembly. Use a screwdriver to tighten the 2 large locking nuts fitted to the 2 rails Note: Support this rail until the left side has been fitted in the next step.
Page 11 Assembly Instructions Step 14 Prepare the top Screw 4 metal dowels into the top Warning: The unit is heavy. Lift with care. Step 15 Polystyrene block Fit the top Note: To make it easier to fit the top and plinths, Polystyrene block place polystyrene blocks...
Page 12 Assembly Instructions Step 16 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the 2 back panels Square up the unit by making sure that measurement x:x equals y:y.
Page 13 Assembly Instructions Step 17 Fit the 6 plastic nails Tap 2 plastic nails into the bottom edge of each of the sides Tap 2 plastic nails into the bottom edge of the front rail . Step 18 Finished Prepare a side plinth top edge Insert a large locking into 1 of the side...
Page 14 Assembly Instructions Step 20 Prepare the front plinth Screw 2 metal dowels Profiled into the front plinth top edge Step 21 Finished Fit the plinths together top edge Push the 2 side plinths onto the front plinth Profiled Use a screwdriver to Finished top edge tighten the large locking...
Page 15 Assembly Instructions Step 23 Warning: The unit is heavy. Lift with care. Fit the narrow shelves Carefully stand the unit up. For each of the 4 narrow shelves , insert 4 shelf studs Lower the 4 narrow shelves down onto the shelf studs Step 24 Fit the hanging rail...
Page 16 Assembly Instructions Step 25 Prepare the 2 plain doors Push fit 4 hinges into each of the 2 plain doors Secure each hinge with 2 screws Note: Before securing with the screws, make sure that the hinges are positioned at 90 degrees with the edge of the door.
Page 17 Assembly Instructions Step 27 Fit doors and handles Note: The easiest way to attach each door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
Page 18 Assembly Instructions Step 28 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
Page 19 Assembly Instructions Step 29 Screw Fit the overbalance Washer protector Wall fixing Strap (not supplied) Strap To prevent possible Washer overbalancing we recommend that this unit Screw is secured to a suitable (not supplied) wall by fitting of the overbalance protector kit to the unit, or an alternative fixing method of your choice.
Page 20 If stated in the instruction leaflet, it is essential that this unit is fixed to a wall. KEEP THESE INSTRUCTIONS FOR FUTURE USE If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928.

This manual is also suitable for:

Kensington 413/6949
