Linear Technology DC1281A Demo Manual page 5

PARTS LIST
ITEM QTY REFERENCE
14 1 R37
15 19 R13, R16-R23, R30-R35, R38-R41
16 4 R6-8, R14
17 1 R24
18 2 R1, R2
19 0 R3 (OPTION)
20 4 R11-R12,R46-R47
21 3 R25, R26, R29
22 2 R27-R28
23 2 R4-R5
24 1 T3 Put Bal.905 in 1058 987 854D
25 4 TP1-2, TP4-5
26 1 U1
27 2 U3, U4
28 1 U5
29 4 Z (STAND-OFF)
30 5
31 2
32 1
DC1281A-A
1 1 DC1281A
2 1 C8
3 2 C9-C10
4 1 L1
5 2 R36, R44
6 1 R45
7 1 T1
8 1 T2
9 1 U2
DC1281A-B
1 1 DC1281A
2 1 C8
3 2 C9-10
4 1 L1
5 2 R36,R44
6 1 R45
7 1 T1
8 1 T2
9 1 U2
DEMO MANUAL DC1281A
PART DESCRIPTION
RES~100Ω~1%~1/16W~0603
RES~100Ω~5%~1/20~0201
RES~1k~1%~1/16W~0603
RES~100k~1%~1/16~0402
RES~49.9Ω~1%~1/16~0402
RES~100Ω~1%~1/16W~0603
RES~68.1Ω~1%~1/16~0402
RES~4990Ω~1%~1/16~0402
RES~10Ω~5%~1/20~0201
RES~5.11Ω~1%~1/16~0402
XFRM~RF~SMT~1:1BALUN
TURRET
IC~SERIAL_EEPROM~TSSOP8
BUFFER~LVDS~OCTAL
BUFFER~LVDS~SINGLE
STAND-OFF , NYLON 0.25" tall
SHUNT, 0.079" CENTER
STENCIL, 20 × 20
FAB., PCB
GENERAL BOM
CAP~NPO~4.7pF~50V~0.25pF~0402
CAP~NPO~8.2pF~50V~0.25pF~0402
IND~56nH~5%~0603
RES~86.6~1%~1/16W~0603
RES~86.6~1%~1/16~0402
BALUN~RF~SMT~1:1
XFRM~RF~SMT~1:1CT
ADC~16BIT~160MSPS
GENERAL BOM
CAP~NPO~1.8pF~50V~0.25pF~0402
CAP~NPO~3.9pF~50V~0.25pF~0402
IND~18nH~5%~0603
RES~43.2Ω~1%~1/16W~0603
RES~182Ω_JUMPER~0402
BALUN~RF~SMT~1:1
TRANSFORMER, WBC1-1L
ADC~16-BIT~160MSPS
MANUFACTURER/PART NUMBER
VISHAY, CRCW0603100RFKEA
ACC/CR20-101JM
VISHAY, CRCW06031K00FKEA
VISHAY, CRCW0402100KFKED
VISHAY, CRCW040249R9FKED
AAC/CR16-1000FM
VISHAY, CRCW040268R1FKED
VISHAY, CRCW04024K99FKED
VISHAY, CRCW020110R0JNTD
AAC/CR05-5R11FM
M/A-COM, MABA-007159-000000 (PbF)
MILL_MAX/2308-2
MICROCHIP/24LC025-I /ST
FAIRCHILD/FIN1108MTD
FAIRCHILD/FIN1101K8X
KEYSTONE, 8831(SNAP ON)
SAMTEC, 2SN-BK-G
STENCIL 1281A, 20 × 20
DEMO CIRCUIT 1281A
AVX/04025A4R7CAT2A
AVX/04025A8R2CAT2A
MURATA/LQP18MN56NG02D
VISHAY, CRCW060386R6FKEA
VISHAY, CRCW040286R6FKED
M/A-COM, MABA-007159-000000 (PbF)
M/A-COM, MABAES0060 (PbF)
LINEAR/LTC2209CUP#PBF
AVX/04025A1R8CAT2A
AVX/04025A3R9CAT2A
MURATA/LQP18MN18NG02D
VISHAY, CRCW060343R2FKEA
VISHAY, CRCW0402182RFKED
M/A-COM, MABA-007159-000000 (PbF)
Coilcraft, WBC1-1L
LINEAR/LTC2209CUP#PBF
dc1281af
5
