Summary of Contents for REVELL CONCERTa M8 SP2
- Page 1 M8 SP2/SP5 Satellite Loudspeaker Packs Owner’s Manual...
-
Page 2: Table Of Contents
• High Gloss Color Finish • Space-Saving Design UNPACKING THE SPEAKERS If you suspect damage from transit, report it immediately to your dealer and/or delivery service. Keep the shipping carton and packing materials for future use. Revel Concerta M8 SP2/SP5 Owner’s Manual... -
Page 3: What's In The Box
For longer distances, 16-gauge or heavier wire is recommended. Figure 2: This example shows the M8 mounted on its bracket above a television and, alternatively, placed on its base above the television. Revel Concerta M8 SP2/SP5 Owner’s Manual... -
Page 4: Wall-Mounting
These must remain on. The larger plates are only to be removed if connecting the speaker to a floor stand (see Optional STANDM10BK Floor Stand at the end of this section for more details). Revel Concerta M8 SP2/SP5 Owner’s Manual... -
Page 5: Speaker Connections
IMPORTANT! DO NOT reverse polarities (+ to –, or – to +) when making connections. service center. Doing so will cause poor imaging and diminished bass response. Be certain that positive and negative wire strands are completely isolated to avoid short circuits that may damage your equipment. Revel Concerta M8 SP2/SP5 Owner’s Manual... -
Page 6: Specifications
M8 SATELLITE LOUDSPEAKERS 4.49in [ 114.05mm ] 4.24in [ 107.70mm ] 5.21in [ 132.34mm ] 11.45in [ 290.83mm ] WALL MOUNT BRACKETS 1.80in [ 45.72mm ] 11.13in [ 282.70mm ] 4.05in [ 102.87mm ] Revel Concerta M8 SP2/SP5 Owner’s Manual... - Page 7 Si prega di visitare REVELSPEAKERS.COM per i manuali di istruzioni in altre lingue. Jos tarvitset ylimääräistä kieleen liittyvää tukea käyttöohjeesta, käy osoitteessa REVELSPEAKERS.COM. Gå ind på REVELSPEAKERS.COM for at se betjeningsvejledningen på flere sprog. Gå till REVELSPEAKERS.COM för mer information om språk i användarmanualen. Revel Concerta M8 SP2/SP5 Owner’s Manual...
- Page 8 Торговая марка: Revel Назначение товара: Пассивная акустическая система Изготовитель: Харман Интернешнл Индастриз Инкорпорейтед, США, 06901 Коннектикут, г.Стэмфорд, Атлантик Стрит 400, офис 1500 Страна происхождения: Китай Импортер в Россию: OOO “ХАРМАН РУС СиАйЭс“, Россия, 127018, г.Москва, ул. Двинцев, д.12, к 1 Гарантийный...
