Summary of Contents for REVELL Performa M20
- Page 1 ® ™ Revel Performa M20 Loudspeaker...
-
Page 2: Table Of Contents
CROSSOVER NETWORK ...5 CABINET ...5 UNPACKING...6 INSTALLING GRILLES (OPTIONAL)...7 INSTALLING STANDS (OPTIONAL) ...8 PLACEMENT...10 ROOM ACOUSTICS...12 ROOM TREATMENT ...12 CONNECTIONS ...14 SYSTEM OPTIMIZATION ...15 CABINET CARE ...16 LOUDSPEAKERS AND POWER ...17 SERVICE INFORMATION ...17 SPECIFICATIONS...18 REVEL PERFORMA M20 Owner’s Manual... -
Page 3: Introduction
As a result, the REVEL PERFORMA M20 loudspeaker sets a whole new standard in bookshelf loudspeaker sound quality. Its superior performance, assured by our ongoing research, will greatly contribute to the enjoyment of music or film sound in your home. -
Page 4: Description
DESCRIPTION The REVEL PERFORMA M20 loudspeaker features a transducer complement (see Figure 2) of one 6.5-inch (165 mm) woofer and a 1-inch (25 mm) tweeter. Woofer Port Tweeter Placement Compensation Woofer Connectors REVEL PERFORMA M20 Front (without grille) Combined with an individually-optimized crossover network, this transducer arrangement results in a superior off-axis response that provides a large “listening window”... -
Page 5: Tweeter
Sycamore, Rose, or Black Ash. The optional REVEL PERFORMA PEDESTAL 1 is also available from your Revel dealer. This stand is designed to optimize the acoustical performance and enhance the appearance of the REVEL PERFORMA M20 loudspeaker. It attaches securely to the loud-... -
Page 6: Unpacking
IMPORTANT! To avoid injury, please use care during unpacking. Always stand as straight as possible and use your leg muscles to lift the REVEL PERFORMA M20 loudspeaker. Do not lift it while bending from the waist. Each REVEL PERFORMA M20 loudspeaker is packed in its own carton. -
Page 7: Installing Grilles (Optional)
Keep all packing materials for future shipping. In the unlikely event a product will need repair, Revel will only accept a unit in its original shipping carton. Using any other packing materials may result in damage to the product and is not covered by the warranty. -
Page 8: Installing Stands (Optional)
Locate the parts bag (packed with the loudspeaker) that contains spikes, lock nuts, covers, and a wrench. Set all parts aside. 2. Unpack a REVEL PERFORMA PEDESTAL 1 box. Start the stand assembly by fastening three upright bars to the bottom ‘T’... - Page 9 4. Place the stand as shown in Figure 7 and install the feet (from Figure 7. Installing feet and spikes. 5. Place your REVEL PERFORMA M20 loudspeaker as shown in Figure 8. Installing the assembled REVEL PERFORMA PEDESTAL 1 onto the REVEL PERFORMA M20 loudspeaker.
-
Page 10: Placement
See “System Optimization” on page 15 for details. • For best stereo imaging, place the REVEL PERFORMA M20 loudspeakers at equal distances from the main listening position and in symmetry with the room, as shown in Figure 9. - Page 11 If possible, avoid placing the loudspeakers near large objects, which can cause unwanted reflections. • REVEL PERFORMA M20 loudspeakers can be also be placed on bookshelves or in a custom wall unit. • Ideally, the listening room should be acoustically neutral, nei- ther producing any distinct echoes nor sounding completely “dead”...
-
Page 12: Room Acoustics
Here’s where real-world experience counts. We suggest consulting your Revel dealer for help in determining the optimum loudspeak- er and listener placement for your listening room. They have been trained by Revel and have the most up-to-date information on proper loudspeaker placement. - Page 13 Where possible, also determine the treatment locations for first ceiling reflections. Your Revel dealer can recommend acoustic treatment materials, and can help determine the best plan for your room. If it is a dedi- cated listening room, qualified room treatment manufacturers or even acousticians may be consulted for optimum results.
-
Page 14: Connections
NOTE: A high loop resistance will result in mis-termination of the filter networks, and serious degradation of sound quality. Use high-quality connectors on the speaker cables. Consult your Revel dealer as to specific recommendations for your application. • Turn off all audio system power before making any connections. -
Page 15: System Optimization
Northridge, California Made in U.S.A. Serial Number xxxx SYSTEM OPTIMIZATION 1. After connecting the REVEL PERFORMA M20 loudspeakers, initially set the TWEETER LEVEL CONTROL on both rear panels to the “0” position, as shown in Figure 13. Set PLACEMENT COMPENSATION... -
Page 16: Cabinet Care
NOTE: Set the controls the same on both left and right channels. CABINET CARE Each cabinet for the REVEL PERFORMA M20 loudspeaker has a wood veneer finish and does not require any routine maintenance. Occasionally, use a soft cloth, dampened with household furniture polish, to remove any fingerprints or dust. -
Page 17: Loudspeakers And Power
Your Revel dealer can order a new set of shipping materials if you no longer have the original cartons. Since there will be a charge for this service, we strongly recommend saving all packing materials. -
Page 18: Specifications
Sensitivity provides an indication of how much amplifier power is required for the loudspeaker to play at satisfactory volume levels. This conservatively-rated specification indicates moderate sensitivity and denotes that a REVEL PERFORMA M20 loudspeaker does not require huge amplifiers to achieve realistic levels in all but the largest rooms. - Page 19 Revel, a division of Madrigal Audio Laboratories, constantly strives to update and improve existing products, as well as create new ones. Therefore the specifications and construction details in this and related Revel publications are subject to change without notice. Kapton is a registered trademark of the E.I. du Pont de Nemours Company.
- Page 20 8500 B ALBOA OULEVARD , CA 91329 ORTHRIDGE PH: (818) 830-8777 • FAX: (818) 892-4960 www.revelspeakers.com P/N 9301522-002...
