- Page 1 W & WIP ALARM PANEL INSTALLATION MANUAL DOC. - REF. 230-W-WIP-AUS LAST MODIFICATION DATE : NOVEMBER 2016 FIRMWARE VERSION : XLP.07.07.15.XXX AND LATER...
-
Page 2: Introduction
Since 2002, RSI VIDEO TECHNOLOGIES provides the only wireless video verification on the market, ® thanks to the Motion Viewer™ detectors and to the Videofied product range. After 2 years of development, RSI VIDEO TECHNOLOGIES is proud to present the new W alarm panel. -
Page 3: Table Of Contents
SUMMARY Introduc tion....................2 Summary.........................3 1. W installation and setup.......................4 1.1 Panel overview............................4 1.2 Panel mounting............................4 1.3 Ethernet cable connexion........................5 1.4 SIM card installation..........................5 1.5 Powering and initialization........................5 1.6 Indicator lights............................6 1.7 Pairing the keypad..........................6 2. W panel programming..........................3. W panel features guide........................ -
Page 4: W Installation And Setup
1. W INSTALLATION AND SETUP INSTALLATION MANUAL 1.1 Panel overview Ethernet cable connection WIS100 Siren connector SIM card installation Status LEDs Mini-USB connector for power supply Battery connector COM button INIT button Locking screws 1.2 Panel mounting Fix the back casing on the wall using the three mounting holes (4 mm diameter) as shown. -
Page 5: Ethernet Cable Connexion
1. W INSTALLATION AND SETUP INSTALLATION MANUAL 1.3 Ethernet cable connection Only for WIP 720/730 models Once the panel is fixed on the wall connect a RJ45 cable between the site internet network and the panel Ethernet port. When the panel attempts a transmission via Ethernet, a red LED on the connector will flash. This will allow the installer to check whether the panel is connected to a valid network. -
Page 6: Indicator Lights
1. W INSTALLATION AND SETUP INSTALLATION MANUAL 1.6 Indicator lights Red LED blinking Red LED blinking Red LED on Red LED off (1 sec) (3 sec) Battery out of order Low voltage on Normal Green LED on (AC power detected) or not detected. -
Page 7: W Panel Programming
2. W PANEL PROGRAMMING INSTALLATION MANUAL Use the keypad to program the panel Keypad Display Actions and comments KEYPAD 1 RECORDED OK or YES The system can also be programmed in : french, italian, german, dutch, spanish, swedish, portuguese, danish, czech, turkish and <... - Page 8 2. W PANEL PROGRAMMING INSTALLATION MANUAL CODE NAME : You may name the installer code using the alphanumeric keypad. OK or YES If using automatic setting (called installer default list), enter the name of the list. ACCESS 1 Warning : If the wrong installer list name is used, it REGISTERED cannot be set later, the system must be defaulted.
- Page 9 2. W PANEL PROGRAMMING INSTALLATION MANUAL TEST (hour) : OK or YES TEST (minutes) : 04:15 OK or YES CODE / TEST MODIFICATION? OK or YES The CODE/STATE MODIF. menu is used to configure the CODE / TEST transmitted events to the monitoring station. Use the arrow MODIFICATION keys to toggle between events and to modify.
- Page 10 The 2G3G level test can last several minutes. Do not interrupt the test or remove the SIM card during the test. IMPORTANT : Videofied will require a 3/5 grade or better for reliable transmission of Video alarms. W & WIP Alarm panel...
- Page 11 2. W PANEL PROGRAMMING INSTALLATION MANUAL ETHERNET: Unavailable on the W730 DISABLED ETHERNET: ENABLED OK or YES PARAMETERS ? OK or YES DHCP : DHCP : OK or YES PANEL IP ENABLED DISABLED If the router forces a static IP...
- Page 12 2. W PANEL PROGRAMMING INSTALLATION MANUAL WLAN: DISABLED Enable the WLAN. WLAN: ENABLED OK or YES WLAN PARAMETERS? OK or YES PARAMETERS? NETWORK ? Please choose between : OK or YES AUTO: The WWB100 scans automatically every WLAN network available and displays them for selection.
- Page 13 2. W PANEL PROGRAMMING INSTALLATION MANUAL WLAN STATUS? OK or YES TEST IN PROGRESS END = OK/YES Wait PANEL IP XXX.XXX.XXX.XXX WLAN STATUS? ESC NO WLAN errors NET NOT FOUND : 389 Wrong network password. NET NOT FOUND : 396 No password entered or password too short.
- Page 14 2. W PANEL PROGRAMMING INSTALLATION MANUAL For full compatibility with EN50131 norms, press COMPATIBILITY EN 50131 NORMS ? Otherwise, press ESC NO. OK or YES Press ESC NO to default the area names. AREAS CONFIGURATION Enter the name of Area 1 and confirm with Repeat the procedure for areas 2,3 and 4.
- Page 15 2. W PANEL PROGRAMMING INSTALLATION MANUAL RF TEST OK or YES RADIO RANGE TEST? Each device is recorded in an area. Each area can be configured as delayed or immediate. Areas are used to set up special arming modes as well. AREA ALLOCATION : Please refer to the chapter 3.3 for further details about AREA 1...
- Page 16 2. W PANEL PROGRAMMING INSTALLATION MANUAL When the configuration is over, close the panel box as shown below and lock the panel. You can find screws to lock the panel inside the box (see chapter 1.1 on page 4). Then stick the provided tag to seal the panel. Locking screws location Sealing tag...
-
Page 17: W Panel Features Guide
3. W PANEL FEATURES GUIDE INSTALLATION MANUAL 3.1 Get to Access level 4 Tue 29/10 11:23 ACCESS LEVEL ACCESS LEVEL OK or YES LEVEL : 1 DISARMED LVL:1 To unlock and get access to the installer level 4, you need to successively enter TWO codes (in any order) : ACCESS LEVEL LEVEL : 4... -
Page 18: Arming And Siren Mode Configuration
3. W PANEL FEATURES GUIDE INSTALLATION MANUAL 3.3 Arming and Siren Mode Configuration • to go to menu : CONFIGURATION (LEVEL 4) > SPECIAL ARMING MODES > FULL ARM, SP1 or SP2 • There are 3 different arming modes : FULL ARM : Arming of all areas and all devices. -
Page 19: Manage Badges And Access Codes
3. W PANEL FEATURES GUIDE INSTALLATION MANUAL 3.4 Manage badges and access codes Access Level Access Level Definition & Rights LVL 1 Standby Level LVL 2 Restricted USER level, where it is only possible to arm/disarm the system. USER level, where it is possible to arm/disarm the system, check the event log, test the devices. - Page 20 3. W PANEL FEATURES GUIDE INSTALLATION MANUAL Enter a new end user Badge/Code Delete an end user Badge/Code ENTER A BADGES ACCESS CODES BADGE/CODE Press twice on the right arrow OK or YES ENTER A DELETING BADGE/CODE BADGES/CODES OK or YES OK or YES BADGE OR CODE Badges/codes list...
-
Page 21: Delete A Device From The System
3. W PANEL FEATURES GUIDE INSTALLATION MANUAL 3.5 Delete a device from the system ACCESS LEVEL CONFIGURATION OK or YES GENERAL AREAS AND PARAMETERS DEVICES OK or YES DEVICES OK or YES ADD A NEW DEVICE DEVICE CONFIGURATION OK or YES Devices list to select the device and press... -
Page 22: Read The Event Log
Scheduling: This feature arms or disarms the system automatically at a defined hour and weekday. The scheduling feature description is available in the EN- PANEL - SCHEDULING - NOTE application note (available on videofied.helpserve.com). Autoarming Delay: Defines an automatic rearming after every system disarming. Once the delay has expired, the panels arms automatically. -
Page 23: Additional Features
In case of frequent false alarms, the Swinger Swinger ® EN - PANEL - SWINGER SHUTDOWN - NOTE* Shutdown feature can inhibit a Videofied Shutdown intrusion detector for a defined period. *Application notes available on videofied.helpserve.com W & WIP Alarm panel... -
Page 24: Ethernet Parameters
4. ETHERNET PARAMETERS To configure Ethernet parameters, using the direction arrows, go to the menu : Lvl. 4 CONFIGURATION GENERAL PARAMETERS ETHERNET OK or YES OK or YES To configure or modify Ethernet Parameters, go to: • IP Parameters: If you wish to use the Ethernet transmission mode, two options are available: DHCP Enable: IP address is assigned by the DHCP service on the network. -
Page 25: Transmitter Events List
5. TRANSMITTED EVENTS LIST The W panel can be configured to enable or disable the transmission of specific events like alarms or malfunctions. The installer can modify the default sending settings for those events, although it will end the EN50131 standard compliance. These are the default transmitted events : The following events are not sent by default : DEVICE (intrusions) -
Page 26: G3G Error Codes
6. 2G3G ERROR CODES Security limitations on the SIM card must be disabled. The PIN of the SIM card has to be disabled or 0000. The following is a list of error codes that can appear after the 2G3G test. 2G3G LEVEL : In case of 2G3G errors during initial programming, we strongly suggest to continue ERROR XXX... -
Page 27: Security And Certifications Notes
7. SECURITY AND CERTIFICATION NOTES INSTALLATION MANUAL Certifications 920MHz (W730 & WIP720/730) Australia A-Tick (AS/NZS4268, AS/CHS42 and AS/NZS 60950) This symbol on the product or on its packaging indicates that this product should not be treated as household waste. It must be handed over to the applicable collection point for the recycling of electrical and electronic equipment. -
Page 28: Technical Specifications
Bidirectional RF WIS100 Wired Siren Radio type Operating frequency Video 920MHz - FHSS - W730 & WIP720/730 (Australia, South America) WMV or MPEG Video Format AES encryption algorithm Transmission security Images per second Radio jam detection 320x240 or 640x480 pixels...
