Maintenance and Care Instructions

Recharging the internal batteries

Battery cables routed
5. Route the battery cables.
• While positioning
its green connector, and feed it through one of the rubber grommets. Take the other connector and feed it
through the other grommet. Carefully route the wires under the cover so that they will not be pinched (see
Figure 4)
6. Replace cover and screws.
• Position and
7. Connect the Batteries.
• Connect the two
RED fuses. These two connectors are the only connectors that may be used for the batteries.
Maintenance and Care Instructions
Recharging the internal batteries
1. Open the case and leave it open for the duration of the charging. See the WARNING:
at beginning of this manual. Keeping the case open also allows the charger to stay cool.
2. You may leave the master On/Off switch in either position. If you leave the master On, you may also leave the
meter connected, but doing that will increase the charging time by about 10%.
3. Before the first use of the charger, verify that the input voltage selector on the charger module is set to the
appropriate line voltage. The selector is a small red slide switch near the power inlet that is moved into the correct
position using a small screwdriver. In the USA, it is 115 Volts (the UP position). With the European cord you will use
230 Volts (the Down position). When it is in its proper location, you will see your line voltage displayed.
4. Connect your line cord to the charger power inlet.
5. Connect the cord to a power outlet.
6. There is a status lamp on the charger that is located on the opposite end from the power inlet. The lamp has three
states.
• Yellow: Indicates Charging.
• Green: Indicates Finished Charging.
• Blinking: Indicates Charging Problem.
Figure 4: Connecting two SoundPro outdoor battery assemblies
the battery cover over the batteries in the correct orientation, take one of the battery wires and
secure the cover in place with the six (6) screws you removed in Step (3).
battery cables into the Power Distribution Panel (see Figure 4) at the two connectors near the
Installed SoundPro outdoor
battery assembly (see 13 in
Table 1 for part details)
"Risk of FIRE or
SoundPro ® Sound Level Meter Outdoor Measuring System
EXPLOSION"
