2. Set the jumpers on the card to manually force the PCI-X
clock speeds between 33 MHz and 133 MHz, if necessary.
33 MHz
133 MHz
(default)
3. Install the adapter card into a PCI-X slot on the motherboard and secure the card bracket to the
computer chassis.
4. Power on the computer and load the
operating system. The PCIe card
should function as though connected
directly to the motherboard natively.

Specifications

Bus Interface
Chipset ID
Connectors
Operating
Temperature
Storage
Temperature
Dimensions
(LxWxH)
PCI-X 1.0 and PCI 3.0
(64-bit 3.3V slot connector)
PCI Express 1.0a
PLX PEX8114
x16 PCI Express slot
-40°C ~ 85°C (-40°F ~ 185°F)
-65°C ~ 150°C (-85°F ~ 302°F)
164.0mm x 40.0mm x 20.0mm
