The PCM-C15-10-INCH is a 10-inch, 15-pin cable assembly for use with 15-pin
PCMCIA cards. It has a connector on one end and no terminations at the other end
for customer field wiring. Table 7-1 contains color coding for the 15 pins.
PIN
1
2
3
4
5
6
7
8

7 PCM-C15-10-INCH CABLE

Table 7-1. PCM-C15-10-INCH Color Coding
COLOR
Black
White
Red
Green
Brown
Blue
Orange
Yellow
PIN
9
10
11
12
13
14
15
SHIELD
13
COLOR
Purple
Gray
Lt. Brown
Pink
White/Blue
Blue/White
Green/Yellow
Bare
