5.4 A/D PACER RATE SELECTION

The A/D pacer rate is programmable as can be seen from the list of rates in Table 5-1
above. The per channel rate is a function of both the programmed pacer and the
number of channels being sampled. Table 5-2 shows the effects of number of channels
selected on the per-channel rate.
Table 5-2. Per-Channel Rate Vs Number of Channels
Number of Channels
1
2
3
4
5
6
7
8
25 kHz 12.5 kHz
25 12.5
12.5 6.25
8.33 4.17
6.25 3.13
5.00 2.50
4.17 2.08
3.57 1.79
3.13 1.56
10
6.25 kHz 3.12 kHz
6.25 3.13
3.13 1.56
2.08 1.04
1.56 0.78
1.25 0.63
1.04 0.52
0.89 0.45
0.78 0.39
