Model 19 MICRO R METER
9
Section
Model 19
Micro R Meter
Main Board,
Drawing 367 × 166
CAPACITORS
Ludlum Measurements, Inc.
Technical Manual
Parts List
Reference Description
UNIT Completely Assembled
Model 19 Micro R Meter
BOARD Completely Assembled
Circuit Board
C1 47pF, 100V
C2 0.0022µF, 50V
C3 0.001µF, 100V
C4 10pF, 100V
C5 0.01µF, 50V
C6 100pF, 3KV
C7 0.022µF, 50V
C8 1µF, 16V
C9 10µF, 25V
C10 100pF, 100V
C11 68µF, 10V
C12 10µF, 25V
C14 470pF, 100V
C17 47µF, 10V
C18-C27 0.01µF, 500V
C28 0.001µF, 2KV
C29 68µF, 10V
C30-C31 1µF, 16V
C32 270pF, 100V
C33 0.01µF, 50V
Page 9-1
Section 9
Part Number
48-1615
5367-166
04-5660
04-5676
04-5659
04-5673
04-5664
04-5735
04-5667
04-5701
04-5655
04-5661
04-5654
04-5728
04-5668
04-5666
04-5696
04-5703
04-5654
04-5701
04-5679
04-5664
February 2012
