LUDLUM MODEL 19 Manual page 25

Model 19 MICRO R METER
INDUCTOR
TRANSFORMER
Wiring Diagram,
Drawing 367 × 174
AUDIO
CONNECTOR
BATTERY
MISCELLANEOUS
Ludlum Measurements, Inc.
Technical Manual
Reference Description
P2 CONN-640456-3
MTA100x3 NAME
P3 CONN-640456-2
MTA100x2 NAME
P4 CONTACT #1434 NAME
L1 22µH, CD43-220
T1 31032R
DS1 Model 19 LAMP BOARD 5367-113
DS2 UNIMORPH TEC-3526-PU
P1 MTA100x4 MAIN BOARD
5367-166
P2 MTA 100x3 MAIN BOARD
5367-166
P3 MTA 100x2 MAIN BOARD
5367-166
B1-B2 DURACELL "D"
* MODEL 19 INTERNAL DETECTOR
* TUBE/XTAL ASSY
M1 MODEL 19 METER
ASSY 987010-001 1mA
* MODEL 19 METERFACE
(202-016)
* METER BEZEL W/ GLASS
W/ SCREWS
* METER MOVEMENT (1mA)
* Model 19 BATTERY BOX
LID W/CNTCT
* DEEP PORTABLE
CAN ASSY
* MODEL 19 CASTING
* MODEL 19 MAIN HARNESS
Page 9-4
Section 9
Part Number
13-8081
13-8073
18-9124
21-9808
21-9925
5367-113
21-9251
13-8170
13-8135
13-8178
21-9313
47-3426
2004-061
4367-024
7367-023
4363-352-00
15-8030
2363-191
4363-615
7367-171
8367-170
February 2012
