Technical data
Safety instructions
Technical data:
Rated voltage
Frequency:
On-site fuse protection:
Breaking capacity:
Contactor:
Protection class:
Motor and control cable:
Housing dimensions:
Important safety instructions!
Observe the following instructions.
Risk of injury due to electrocution.
Warning!
• The connections to the 230/400 V mains must be made by authorised specialist personnel.
• The controller must be unplugged from the mains during connection work.
• Connect controller in clockwise rotating field.
• Swap 2 phases of the mains cable in case of incorrect rotation.
• Check the system regularly for wear or damage.
• The mains isolation unit must be secured against any unintentional and unauthorised reconnection and
must always be accessible.
• Keep people away from the system until it is at standstill.
• When working on the system (e.g. maintenance) always disconnect the system from the mains.
• Externally connected components must as a minimum fulfil the basic insulation requirements for 230 volts.
• Do not use motor and control cables outdoors!
2 | EN
Version 3~230 V
3~230 V/PE (1~230 V/PE)
3 kW
3~400 V
3~400 V/PE
50/60 Hz
10 A
4 kW
mech. locked
IP 65
1 m long
H 180 x B 182 x T 85
