PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 5 C2, C3, C4, C7, C8
3 1 C5
4 1 C6
5 1 L1
6 1 R1
7 1 R2
8 1 R3
9 1 R4
10 1 R5
11 1 R6
12 1 U1
Optional Demo Circuit Components
1 1 C13
2 0 C11, C19, C27 (OPT)
3 0 C9, C10, C12, C15-C18, C22-C26 (OPT)
4 1 C14
5 0 C21 (OPT)
6 1 D1
7 0 L2 (OPT)
8 0 M1 (OPT)
9 0 Q1 (OPT)
10 1 RS1
11 0 RS2 (OPT)
12 1 R7
13 1 R8
14 1 R9
15 0 R10, R12-R15, R18, R19, R21-R27, R30 (OPT) RES, 0603
16 1 R11
17 1 R16
18 0 R20 (OPT)
19 3 R17, R28, R29
Hardware
1 19 E1-E19
2 1 JP1
3 1 XJP1
DEMO MANUAL DC2257A
PART DESCRIPTION
CAP ., X7R, 1μF, 50V, 10%, 0805
CAP ., X7R, 4.7μF, 50V, 10%, 1210
CAP ., X7R, 0.022μF, 16V, 10%, 0603
CAP ., X7R, 0.1μF, 25V, 10%, 0603
INDUCTOR, 10μH
RES, CHIP , 23.2k, 1/10W, 1%, 0603
RES, CHIP , 12.4k, 1/10W, 1%, 0603
RES, CHIP , 1.5k, 1/10W, 5%, 0603
RES, CHIP , 374k, 1/10W, 1%, 0603
RES, CHIP , 100k, 1/10W, 1%, 0603
RES, CHIP , 73.2k, 1/10W, 1%, 0603
I.C., μMODULE LED DRIVER, 80-BGA
CAP ., X7R, 0.1μF, 25V, 10%, 0603
CAP ., 0603
CAP ., 1210
CAP ., X7R, 6.8nF, 16V, 10%, 0603
CAP ., ALUM, OPT, 10mm DIA.
DIODE, SMA
INDUCTOR, OPT, 8mm × 8mm
MOSFET, SOT23
TRANS, SOT23
RES, CHIP , .008Ω, 1W, 1%, 2512
RES, 2010
RES, CHIP , 19.1k, 1/10W, 1%, 0603
RES, CHIP , 1M, 1/10W, 1%, 0603
RES, CHIP , 93.1k, 1/10W, 1%, 0603
RES, CHIP , 0, 1/10W, 1%, 0603
RES, CHIP , 0, 1/4W, 1%, 1206
RES, 1206
RES, CHIP , 100k, 1/10W, 5%, 0603
TESTPOINT, TURRET, .094" PBF
HEADER 3-PIN 0.079 SINGLE ROW
SHUNT, .079" CENTER
MANUFACTURER/PART NUMBER
MURATA, GRM21BR71H105KA12L
MURATA, GRM32ER71H475KA88L
MURATA, GRM188R71C223KA01D
AVX, 06033C104KAT2A
COILCRAFT, XAL8080-103ME
VISHAY, CRCW060323K2FKEA
VISHAY, CRCW060312K4FKEA
VISHAY, CRCW06031K50JNEA
VISHAY, CRCW0603374KFKEA
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW060373K2FKEA
LINEAR TECH, LTM8005EY#PBF
AVX, 06033C104KAT2A
AVX, 0603YC682KAT2A
FAIRCHILD SEMI.,ES1A
VISHAY, WSL25128L000FEA
VISHAY, CRCW060319K1FKEA
VISHAY, CRCW06031M00FKEA
VISHAY, CRCW060393K1FKEA
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW12060000Z0EAHP
VISHAY, CRCW0603100KJNEA
MILL-MAX, 2501-2-00-80-00-00-07-0
WURTH, 620 003 111 21
WURTH, 608 002 134 21
