2.5 List of Connectors

The board has a number of connectors that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's connectors:
Label
DC_PWR
CON2
CHA_FAN
COM3
COM4
COM5
CON1
CPU_FAN
DIGITALREFENCE
F_PANEL
KB/Ms
LCD_POWER
LPT
LVDS
PCIEX1_1
SATA_PWR1
SATA3G_1
SATA3G_2
Function
+12V Power connector
+12V AUX Power Connector
System FAN Connector
COM 3 Connector
COM 4 Connector
COM 5 Connector
SIM Card Socket
CPU FAN Connector
GPIO/SM BUS/COM2/ COM2 External Power
Selection
Front Panel Pin Header
PS/2 Keyboard / Mouse Connector
LVDS Panel Power Connector
Parallel Port Connector
LVDS Panel Connector
PCI-E [x1] Slot
Serial ATA Power Connector
SATA 0 Connector
SATA 1 Connector
