2.7 AT/ATX Mode Selection (ATMODE)

ATOMODE
Close 1-2
Close 2-3

2.8 Clear COMS (CLRTC)

CLRTC
Close 1-2
Close 2-3

2.9 COM2 External Power Selection (DIGITALREFENCE)

DIGITALREFENCE
Close 15-16
Close 17-18
Close 19-20

2.10 LVDS Panel Power Selection (LVDS_VDD_SEL)

LVDS_VDD_SEL
Close 1-2
Close 2-3
2.11 LVDS Brightness Control Type Selection (L_BRIGHTNESS)

L_BRIGHTNESS

Close 1-2
Close 2-3
Chapter 2 Quick Installation Guide
Function
AT
ATX Mode (Default)
Function
Protected (Default)
Clear
Function
+12V
RI# (Default)
+5V
Function
+3.3V (Default)
+5V
Function
Voltage Control (Default)
PWM Control
2 - 10
