I n d u s t r i a l M o t h e r b o a r d

2.22 LVDS Panel Power Connector (LCD_POWER)

Pin
Signal
1
Panel Power
3
GND
5
Panel backlight control

2.23 Parallel Port Connector (LPT)

Pin
Signal
1
STB#
3
DATA 0
5
DATA 1
7
DATA 2
9
DATA 3
11
DATA 4
13
DATA 5
15
DATA 6
17
DATA 7
19
ACK#
21
BUSY
23
PE
25
SLCT
Chapter 2 Quick Installation Guide
Pin
2
4
Pin
2
4
6
8
10
12
14
16
18
20
22
24
2 - 14
E M B - C V 1 s e r i e s
Signal
Panel brightness control
GND
Signal
AFD#
ERROR#
INIT#
SLIN#
GND
GND
GND
GND
GND
GND
GND
GND
