4. REAR PANEL FUNCTIONS

GO-SOUND 8 and 10AMW active loudspeakers have several connectors, controls, and
indicators the use of which you should understand their use.

4.1. Mixer Controls

1) AC ADAPTER Connection
Connect the device to the supplied power adapter, and then to a mains outlet. Be sure
that mains voltage correspond to the adapter input voltage (within 110-240VAC).
NOTE: Should you need to replace or lose this adapter, be sure that the new
one's output is +15V DC, 1.5A,
