ENGLISH
GO-SOUND 8-10AMW User manual
2) 12Vcc Power Input
GO-SOUND 8 and 10AMW speakers can be powered by a 12VDC power source (such
as the battery of an automobile). Be sure to use cables with appropriate conductor
section (1.50 mm minimum) to avoid overheating.
2
Be sure to observe the correct polarity: the positive pole is red; the negative is black.
Before taking into operation for the first time, the installation has to be ap-
proved by an expert.
3) ANTENNA
It receives the RF signal from the transmitter. To increase the reception capacity, extend
the telescopic antenna as much as possible.
4) POWER Switch
Switch upside to turn the speaker on, and switch down to turn it off. Make sure MASTER
LEVEL control is down before you turn it on.
5) Battery CHARGE And Level Status
When you connect the adapter, you can check battery charge (even without switching
the unit on) basing on how many of the four LEDs are on. When charge level is below
25%, the red LED flashes and indicates that you need to re-charge the battery as soon
as possible. For further details battery and charge function, please refer to "6. RE-
CHARGEABLE BATTERY" on page 15.
6) AUX/MP3 LEVEL
This knob controls the overall signal level of AUX and MP3/Bluetooth™ player.
7) VHF Wireless MIC LEVEL
This portable PA system features a wireless microphone for maximum mobility during
your performances. This knob adjusts output level of the wireless microphone
8) MIC/LINE LEVEL
This controls MIC/LINE input level.
9) RF and POWER ON LEDs
There two LED indicators. RF LED (yellow) lights up when there is radio signal from the
handheld transmitter. POWER LED (Blue) lights up when the unit is powered on. For
further details on the handheld microphone, see "5. VHF WIRELESS MICROPHONE" on
page 14.
10) MIC/LINE Input
It accepts balanced XLR or balanced/unbalanced 1/4" Jack plugs with Mic or Line level
9
