ATEN CS533 Quick Start Manual

CS533
Tap
(USB to Bluetooth KM Switch)
Quick Start Guide
Simply Better Connections
© Copyright 2013 ATEN ® International Co., Ltd.
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved.
All other trademarks are the property of their respective owners.
This product is RoHS compliant.
Part No. PAPE-1285-462G Printing Date: 01/2013
CS533 Tap (USB to Bluetooth KM Switch) Quick Start Guide
Connecting Bluetooth
1. From the Home Screen
of the iPad/iPhone, go
to: Settings:
2. Select General, then
Bluetooth (iOS4/5):
Select Bluetooth
(iOS6)Turn Bluetooth
On.
3. Your iPad/iPhone
searches for devices.
4. When the CS533 is
discovered, it appears
on the iPad/iPhone
screen.
5. Select CS533.
Adaptateur CS533 (Commutateur USB > Bluetooth) – Guide de démarrage rapide
Connexion Bluetooth
1. Depuis l'écran d'accueil
de l'iPad/iPhone,
accédez à : Réglages :
2. Sélectionnez Général,
puis Bluetooth
(iOS4/5) : Sélectionnez
Bluetooth (iOS6)
Activez le Bluetooth.
3. Votre iPad/iPhone
recherche les appareils
à sa portée.
4. Lorsque le CS533 est
détecté, il apparaît
sur l'écran de l'iPad/
iPhone.
5. Sélectionnez CS533.
Package Contents
1 CS533 Tap (USB to Bluetooth KM Switch)
1 Hotkey Stickers
1 User Instructions
3
1
2
6. A message appears
on the iPad/iPhone
screen: From the USB
keyboard, type the PIN
code that appears on
the screen, and press
Enter.
7. CS533 appears as
Connected, and the
keyboard will work on
the iPad/iPhone.
8. To switch the keyboard
to your Computer,
press:
9. If you want to
F12
disconnect Bluetooth,
press
6. Une message apparaît
sur l'écran de l'iPad/
iPhone : En utilisant
le clavier USB,
renseignez le code
PIN qui apparaît sur
l'écran puis appuyez
sur Entrée.
7. Le CS533 apparaît
comme Connecté, et
le clavier peut alors
être utilisé avec l'iPad/
iPhone.
8. Pour faire basculer
le clavier vers votre
ordinateur, appuyez
sur:
9. Si vous souhaitez
F12
désactiver le Bluetooth,
appuyez sur
4
Note: Bluetooth keyboard and mouse will not work with the
CS533. Mouse will not function with iOS and some
Bluetooth devices.
Change the language using Input Method Editor – (IME)
To toggle the IME on or off, from the USB keyboard, press the hotkey:
USB Keyboard Type PC Apple
Hotkey
iOS Media Key
When using the CS533 on the iPad/iPhone, the keys on your USB keyboard will
function on the iPad/iPhone as follows:
F1
F2
Esc Home/Siri* Brightness Down Brightness Up
Screen off /Photo On/Off On-Screen
F3 F4 F5
Search
mode** Keyboard
F7 F8 F9
Rewind Play/Pause Fast Forward
F10 F11 F12
Mute Volume Down Volume Up
*For devices that support Siri.
Modifi cation de la langue de saisie du clavier (IME)
Pour activer ou désactiver l'IME (Input Method Editor), utilisez le raccourci clavier
suivant sur le clavier USB :
Type de clavier USB PC Apple
Raccourci clavier
Touches multimédia iOS
En cas d'utilisation du CS533 avec l'iPad/iPhone, les touches de votre clavier USB
auront les fonctions suivantes sur votre iPad/iPhone :
F1 Réduire la Augmenter la
F2
Esc Accueil/Siri*
luminosité luminosité
Désactiver
Activer/Désactiver
F3 F4 F5
Rechercher l'écran/Mode
le clavier virtuel
photo**
Retour
F7 F8 F9
Lecture/Pause Avance rapide
rapide
Augmenter le
F10 F11 F12
Sourdine Baisser le volume
volume
FCC Information
Online Registration
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 http://eservice.aten.com
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
Technical Phone Support
residential installation. This equipment generates, uses
International:
and can radiate radio frequency energy, and if not installed
and used in accordance with the instruction manual, may 886-2-86926959
cause interference to radio communications. However,
there is no guarantee that interference will not occur in a
North America:
particular installation. If this equipment does cause harmful
1-888-999-ATEN Ext: 4988
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
United Kingdom:
encouraged to try to correct the interference by one or more
44-8-4481-58923
of the following measures:
• Reorient or relocate the receiving antenna;
• Increase the separation between the equipment and
receiver;
• Connect the equipment into an outlet on a circuit different
All information, documentation,
from that which the receiver is connected;
firmware, software utilities, and
• Consult the dealer/an experienced radio/television
specifications contained in this
technician for help.
package are subject to change without
This device complies with Part 15 of the FCC Rules.
prior notifi cation by the manufacturer.
Operation is subject to the following two condition: (1) this
Please visit our website http://www.
device may not cause harmful interference and 92) this
aten.com/download/?cid=dds for the
device must accept any interference received, including
most up-to-date versions.
interference that may cause undesired operation.
FCC ID: JYX-CS533
**Depends on the default iOS behavior
For more information on how to use the CS533, download the full user manual
from ATEN's website (www.aten.com).
*Pour les appareils qui prennent en charge Siri.
**Dépend du comportement du système d'exploitation iOS par défaut
Pour plus d'informations sur l'utilisation du CS533, téléchargez le manuel
d'utilisation complet sur le site Internet ATEN (www.aten.com).
