USB to Bluetooth KM Switch
USER MANUAL
CS533

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS533 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ATEN CS533

Summary of Contents for ATEN CS533

  • Page 1 USB to Bluetooth KM Switch USER MANUAL CS533...

  • Page 2: Fcc Information

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: JYX-CS533 RoHS This product is RoHS compliant.
  • Page 3 SJ/T 11364-2006 The following contains information that relates to China. - 3 -...

  • Page 4: Online Registration

    CS533 User Manual Online Registration International http://support.aten.com North America http://www.aten-usa.com/product_registration Telephone Support International 886-2-8692-6959 China 86-10-5255-0110 Japan 81-3-5615-5811 Korea 82-2-467-6789 North America 1-888-999-ATEN ext 4988 United Kingdom 44-8448-158923 Technical Support For international online technical support – including troubleshooting, documentation, and software updates: http://support.aten.com...

  • Page 5: Package Contents

    ® Copyright © 2012 ATEN International Co., Ltd. Manual Date: 2012-04-11 ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. - 5 -...
  • Page 6 Overview The CS533 Tap is a control unit that allows access to one computer and two Bluetooth devices from a USB keyboard and mouse. The CS533 eliminates the need to purchase a Bluetooth keyboard or mouse for your mobile device, saving you valuable work space, allowing you to use your favorite multimedia keyboard with all your Bluetooth devices.
  • Page 7 Features Links use of a USB keyboard and mouse* between a PC and 2 Bluetooth devices Quick switch access to the computer and two Bluetooth devices via hotkey Supports PC and Mac iOS Bluetooth media key mapping Supports keyboard drivers Supports wireless and multifunction keyboards Mac keyboard support and emulation* Supports USB hot-plugging...
  • Page 8 Requirements Keyboard/Mouse 1 USB Keyboard 1 USB Mouse *The CS533 will not work with Bluetooth keyboard or mouse devices Computer Type A USB Port Devices Up to 2 Bluetooth HID devices *USB Mouse will not function on iOS devices and some Bluetooth devices.

  • Page 9: Supported Devices

    Supported Devices Below is a table of HID devices* that support Bluetooth Human Interface Device Profiles (HID) for keyboard use. HID devices support Bluetooth Human Interface Device Profiles (HID) and will work with the CS533. Supported HID Devices Brand Product O.S.
  • Page 10 Components Front View Rear View - 10 -...

  • Page 11: Top View

    USB Mouse Port Use this port to plug in your USB mouse. USB Cable This USB cable plugs into your computer, or USB power adapter to provide power and connectivity to the CS533. Plastic Stand This plastic backing provides an adjustable stand for your Bluetooth device.
  • Page 12 Installation 1. Make sure that the power to any device that you connect to the installation has been turned off. You must unplug the power cords of any computers that have the Keyboard Power On function. 2. Make sure that all devices you will be installing are properly grounded.

  • Page 13: Hardware Setup

    Instructions To use your CS533 Tap you must first setup the hardware, and pair the Bluetooth connections. Hardware Setup To setup the hardware use the diagram below, and do the following: 1. Plug the CS533’s USB Cable into your computers USB port 2.
  • Page 14 Bluetooth Setup With the hardware setup, the CS533 Tap can establish two Bluetooth connections to share USB keyboard and mouse use with the computer. To establish a paired Bluetooth connection with the CS533, do the following: 1. From the USB keyboard use the Hotkey: [Alt]+[F2] to switch to: Port 2 Bluetooth (see Port Selection, page 15).

  • Page 15: Port Selection

    Using the CS533 Port Selection The port selected for use with the USB keyboard/mouse is indicated by the blue LED light on the front panel, and when lit has exclusive use. Each port represents a device connection to the keyboard/mouse: Port 1- USB Computer, Port 2- Bluetooth, and Port 3- Bluetooth.
  • Page 16 HotKeys Hotkeys are used from your USB keyboard to initiate CS533 functions such as; switching ports, connecting/disconnecting Bluetooth pairs, resetting default settings, and enabling keyboard mappings. The chart below lists all of the hotkeys and their related functions. HOTKEY TABLE...
  • Page 17 Custom Keyboard Settings The CS533 Tap can customize the USB keyboard to mimic the layout of different keyboards: QWERTY (standard PC), Mac (Apple computer), and iPad/iPhone for each port. To change the keyboard layout for a port use the Enable...
  • Page 18 Keyboard mapping Tables PC Keyboard Mapping iPad iPhone USB Keyboard Report Report Report Left-Control Left-Control Left-Control Left- Control Left-Shift Left-Shift Left-Shift Left-Shift Left-Alt Left-Option Left-Option Left- Option Left- Left- Left- Left- Windows Command Command Command Space Bar Space Bar Space Bar Space Bar - 18 -...
  • Page 19 iPad iPhone USB Keyboard Report Report Report Right-Alt Right- Right- Right- Option Option Option Right-Shift Right-Shift Right-Shift Right-Shift Right- Right- Right- Right- Control Control Control Control Escape Escape www Home Home Brightness Brightness Brightness Down/F1 Down Down - 19 -...
  • Page 20 iPad iPhone USB Keyboard Report Report Report Brightness Brightness Brightness up/F2 Expose/F3 Spotlight Spotlight Search Search Picture Frame Mode DashBoard/ Picture (iOS5) Frame Screen Mode Lock (iOS4) On-Screen On-Screen Keyboard Keyboard - 20 -...

  • Page 21: Rewind/F7

    iPad iPhone USB Keyboard Report Report Report Rewind/F7 Rewind Rewind Play/Pause/ Play/Pause Play/ Pause Fast Fast Fast Forward/F9 Forward Forward Mute/F10 Mute Mute Volume Volume Volume Down/F11 Down Down - 21 -...

  • Page 22: Volume Up/F12

    iPad iPhone USB Keyboard Report Report Report Volume Up/ Volume Up Volume Windows CD Eject Key + E Delete Delete Delete Delete Forward Forward Forward Print Screen - 22 -...
  • Page 23 iPad iPhone USB Keyboard Report Report Report Scroll Lock Home Home Page Up Page Up Page Down Page Down - 23 -...
  • Page 24 iPad iPhone USB Keyboard Report Report Report Backspace Delete Delete Delete Backward Backward Backward Enter Return Return Return Insert Pause Num Lock Clear - 24 -...
  • Page 25 Mac Keyboard Mapping iPad iPhone MAC Keyboard PC Report Report Report Left Left Left Left Control Control Control Control Left Shift Left Shift Left Shift Left Shift Left Option Left Alt Left Option Left Option Left Left GUI Left Left Command Command Command...
  • Page 26 iPad iPhone MAC Keyboard PC Report Report Report Right Shift Right Shift Right Shift Right Shift Right Right Right Right Control Control Control Control Escape Escape www Home www Home Brightness Brightness Brightness Down/F1 Down Down Brightness Brightness Brightness Up/F2 Expose/F3 Spotlight Spotlight...

  • Page 27: Table Of Contents

    iPad iPhone MAC Keyboard PC Report Report Report On-Screen On-Screen Keyboard Keyboard Rewind/F7 Rewind Rewind Play/ Play/ Play/Pause Pause/F8 Pause/F8 Fast Fast Fast Forward/F9 Forward Forward Mute/F10 Mute Mute Volume Volume Volume Down/F11 Down Down Volume Volume Up Volume Up Up/F12 - 27 -...

  • Page 28: Pause/F8

    iPad iPhone MAC Keyboard PC Report Report Report Eject Print Screen Scroll Lock Pause - 28 -...

  • Page 29: Forward

    iPad iPhone MAC Keyboard PC Report Report Report Delete Delete Delete Delete Forward Forward Forward Delete Back Delete Delete Backward Space Backward Backward Return Enter Return Return Help/FN Insert Home Home Page Up Page Up - 29 -...
  • Page 30 iPad iPhone MAC Keyboard PC Report Report Report Page Page Down Down Clear Num Lock - 30 -...
  • Page 31 Standard Keyboard Commands Below are standard key combinations used to Copy, Paste, Cut, Restore, Select, Select All, and invoke IME Change on Apple and PC Keyboards, with respect to the operating system, when using the CS533 Tap: Apple Keyboard: Function Mac OS...

  • Page 32: Firmware Upgrade

    1. From the computer and keyboard that is connected to your CS533, go to our Internet support site (http:// eService.aten.com) and choose the CS533 to get a list of available Firmware Upgrade Packages. 2. Download the appropriate CS533 firmware upgrade package to your computer.

  • Page 33: Specifications

    Specifications Function CS533 PC / Bluetooth Connections Port Selection Hotkey Connectors Keyboard 1 x USB Type A Female (White) Mouse 1 x USB Type A Female (White) Power Supply 1 x USB Type A Male (White) Cable Length Computer 0.9 m...

  • Page 34: Limited Warranty

    Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT FROM THE DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK OR ITS DOCUMENTATION. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and specially disclaims its quality, performance, merchantability, or fitness for any particular purpose.
