  • Page 1: User Manual

    User Manual CN-5000 2005-09-13...

  • Page 2: Regulatory Information

    CN-5000 User Manual Regulatory Information 1. This is an FCC Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

  • Page 3: User Notice

    CN-5000 User Manual User Notice All information, documentation, and specifications contained in this manual are subject to change without prior notification by the manufacturer. The manufacturer makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties as to merchantability or fitness for any particular purpose.

  • Page 4: Safety Instructions

    CN-5000 User Manual Safety Instructions General Read all of these instructions. Save them for future reference. Follow all warnings and instructions marked on the device. Do not place the device on any unstable surface (cart, stand, table, etc.). If the device falls, serious damage will result.
  • Page 5 The device does not operate normally when the operating instructions are followed. Only adjust those controls that are covered in the operating instructions. Improper adjustment of other controls may result in damage that will require extensive work by a qualified technician to repair. CN-5000 User Manual 2005-09-13...

  • Page 6: Rack Mounting

    CN-5000 User Manual Rack Mounting Before working on the rack, make sure that the stabilizers are secured to the rack, extended to the floor, and that the full weight of the rack rests on the floor. Install front and side stabilizers on a single rack or front stabilizers for joined multiple racks before working on the rack.

  • Page 7: Package Contents

    Package Contents The complete CN-5000 package consists of: 1 CN-5000 KVM on the Net™ Control Unit 1 Custom KVM Cable Set 1 Power Adapter 1 Rack Mount Kit 1 Software CD 1 User Manual 1 Quick Start Guide Check to make sure that all the components are present and that nothing was damaged in shipping.

  • Page 8: Table Of Contents

    CN-5000 User Manual Contents Regulatory Information ..... . . ii User Notice ......iii Safety Instructions .
  • Page 9 The Connection Screen ..... 67 The File Menu ......69 CN-5000 User Manual 2005-09-13...
  • Page 10 Options ......82 The CN-5000 List Panel ..... 83 The Event List Window .

  • Page 11: About This Manual

    CN-5000 User Manual About This Manual This User Manual is provided to help you get the most from your CN-5000 system. It covers all aspects of installation, configuration and operation. An overview of the information found in the manual is provided below.

  • Page 12: Conventions

    CN-5000 User Manual Conventions This manual uses the following conventions: Indicates text that you should key in. Courier Indicates keys you should press. For example, [Enter] means to press the Enter key. If keys need to be chorded, they appear together in the same bracket with a plus sign between them: [Ctrl+Alt].

  • Page 13: Introduction

    Chapter 1. Introduction Overview The CN-5000 is a control unit that allows operators to monitor and access their computers from remote locations using a standard Internet browser or Windows-based application programs. The CN-5000 connects to the Internet, an Intranet, LAN, or WAN using industry standard Category 5 cable, then uses a KVM cable to connect to a local KVM switch or server.
  • Page 14 Once an operator successfully connects and logs in, his screen displays what is running on the remote unit attached to the CN-5000 (a KVM OSD display, a server’s desktop, or a running program, for example) and he can control it from his console just as if he were there.

  • Page 15: Features

    Features Remote access of KVM switches or servers via LAN, WAN, or the Internet; control your installation from down the hall, down the street, or half-way around the world Supports 10Base-T, 100Base-T, TCP/IP, HTTP Advanced security features include password protection and advanced encryption technologies High video resolution: up to 1280 x 1024 @ 75Hz;...

  • Page 16: System Requirements

    System Requirements For best results we recommend that the computers used to access the CN-5000 control unit have at least a P III 1 GHz processor, and that the screen resolution is set to 1024 x 768. Browsers must support 128 bit data encryption.

  • Page 17: Hardware Setup

    Pressing and holding this switch in while powering ON the Upgrade Switch CN-5000 returns it to the factory default firmware level. After the CN-5000 has been powered ON, pressing and holding this switch in for more that two seconds performs a system reset.

  • Page 18: Rear View

    The KVM cable (supplied with this package) that links the CN-5000 to your KVM switch or server plugs in here. Local Console The CN-5000 can be accessed via a local console as well Section as over the Net. The cables for the local console (keyboard, monitor, and mouse) plug in here.

  • Page 19: Before You Begin

    Keyboard Power On function. Rack Mounting For convenience and flexibility, the CN-5000 can be mounted on a system rack. To rack mount the unit do the following: 1. Using the screws provided with this package, screw the mounting bracket into the top or bottom of the unit as shown in the diagram below.

  • Page 20: Cable Information

    Phillips Type I cross, recessed type screws. Cable Information Only custom cable sets specifically designed to work with the CN-5000 may be used to link to your server or KVM switch. A 1.8 m custom cable set is provided with this package. Cable sets are also available in other lengths, as shown in the table below.

  • Page 21: Installation

    1. Plug the local administrator’s keyboard, mouse, and monitor into the unit’s Console Ports. 2. Use the KVM cable provided with this package to connect the CN-5000’s KVM Port, to the Keyboard, Video and Mouse ports of the server or KVM switch that you are installing.
  • Page 22 CN-5000 User Manual Notes: 2005-09-13...

  • Page 23: Getting Started

    Logging In To operate the CN-5000 from an Internet browser, begin by logging in: 1. Open your browser and specify the IP address of the CN-5000 you want to access in the browser’s URL location bar. Note: 1. Get the IP address from the CN-5000 administrator.
  • Page 24 3. Accept the certificate. If a second certificate appears, accept it as well. The CN-5000 login page appears: 4. Provide a valid Username and Password (set by the CN-5000 administrator), then Click Login to continue. Note: 1. If you are the administrator, and are logging in for the first time, use the default Username: administrator;...
  • Page 25 3. Getting Started After you have successfully logged in, the CN-5000 Main Page appears: 2005-09-13...

  • Page 26: Screen Elements

    (see p. 25), clicking this icon will bring up its interface. All the events that take place on the CN-5000 are recorded in a log file. If you have the proper permission (see p. 25), clicking this icon displays the contents of the log file.

  • Page 27: Administration

    Introduction The administration utilities, represented by the icons located across the top of the CN-5000 web page, are used to configure the CN-5000 for operation. This chapter discusses each of them in turn. As you make your configuration changes, Click the Apply icon at the upper left of the web page to save the changes in the CN-5000’s configuration file.

  • Page 28: General

    Device Name: To make it easier to manage installations that have more than one CN-5000, each one can be given a name. To assign a name for the CN-5000, key in one of your choosing here (15 characters max.). MAC Address: The CN-5000’s MAC Address displays here.

  • Page 29: Network

    (and set the firewall accordingly). Users must specify the port number as part of the IP address when they log in to the CN-5000. If an invalid port number (or no port number) is specified, the CN-5000 will not be found.

  • Page 30: Ip Address

    For dynamic IP address assignment, select the Obtain an IP address automatically, radio button. Note: If the CN-5000 is on a network that uses DHCP to assign network addresses, and you need to ascertain its IP address, see IP Address Determination, p.

  • Page 31: Security

    Security The Security page is used to control access to the CN-5000. IP and MAC Filters permit or deny access to the CN-5000 for specific IP and MAC addresses attempting to access the system. As a security feature, the Default Java program name lets the...

  • Page 32: Filtering

    If the include button is checked, all the addresses within the filter range are allowed access to the CN-5000; all other addresses are denied access. If the exclude button is checked, all the addresses within the filter range are denied access to the CN-5000;...
  • Page 33 4. To filter a single IP address, key in the same address as the start IP. To filter a continuous range of addresses, key in the end number of the range. After filling in the address, click OK. 5. Repeat these steps for any additional IP addresses you want to filter. To delete a filter, select it and Click Remove.

  • Page 34: Radius

    2. Fill in the IP addresses and Service Ports for the Primary and Alternate RADIUS servers. 3. Set the time in seconds that the CN-5000 waits for a RADIUS server reply before it times out in the Timeout field. 4. Set the number of RADIUS retries allowed in the Retries field.
  • Page 35 Note: 1. The characters are not case sensitive. Capitals or lower case work equally well. 2. Characters are comma delimited. 3. An invalid character in the in the configuration string will prohibit access to the CN-5000 for the user. Examples: String c,w,p User has administrator priveleges;...

  • Page 36: User Manager

    CN-5000 User Manual User Manager This configuration dialog is used to manage user profiles. A maximum of 64 user profiles can be created. To add a user, fill in the information asked for in the User Info dialog box and Click Add.
  • Page 37 Permissions Click to place/remove a check mark next to an item to grant/withhold access to that aspect of the CN-5000’s operation that the time governs Configure: Checking Configure gives a User Administrator priveleges, and allows the user to set up and modify the CN-5000’s operating environment.

  • Page 38: Customization

    Working Mode If Stealth Mode is enabled, the CN-5000 cannot be pinged. If Echo Mode is disabled, the CN-5000 will not show up in the list of local CN-5000 units when accessing it with the AP program. See p. for details.

  • Page 39: Firmware

    Firmware New versions of the CN-5000 firmware can be downloaded from our website: www.aten.com.tw as they become available. To upgrade the firmware, do the following: 1. After downloading the new firmware file to your computer, click the Firmware icon to open the Firmware configuration dialog: 2.
  • Page 40 CN-5000 User Manual Notes: 2005-09-13...

  • Page 41: The Windows Client

    3. When a connection to the CN-5000 has been established, a screen similar to the one below appears: Chapter 5.
  • Page 42 4. If Keep Screen Size is not enabled (there is no checkmark in the box), the remote screen is resized to fit the resolution of your local monitor. 4. Click Switch to take over console control of the unit that the CN-5000 is connected to. 2005-09-13...

  • Page 43: Operation

    Operation Once the Switch to the CN-5000 has been accomplished, the remote system’s video output is captured and displayed on your monitor. At the same time, your local keystroke and mouse input is captured and sent to the remote system.

  • Page 44: Keystrokes

    2. Move the local mouse pointer exactly on top of the remote mouse pointer and Click. If these procedures still do not help, set the mouse speed and acceleration for the computer (or computers via KVM switch) connected to the CN-5000 as follows: 2005-09-13...
  • Page 45 5. The Windows Client Windows 2000: Set the mouse speed to the middle position; set the mouse acceleration to None (Control Panel → Mouse → Mouse Properties → Motion): Windows XP/Server 2003: Set the mouse speed to the middle position; disable Enhance Pointer Precision (Control Panel →...

  • Page 46: Hotkeys

    CN-5000 User Manual WinMe: Set the mouse speed to the 5th position; disable mouse acceleration (click Advanced to get the dialog box for this). WinNT / Win98 / Win95: Set the mouse speed to the slowest position. Sun / Linux:...
  • Page 47 Substitute Alt key Although all other keyboard input is captured and sent to the CN-5000, [Alt + Tab] and [Ctrl + Alt + Del] work on your local computer. In order to implement their effects on the remote system, a function key is be substituted for the Alt key.

  • Page 48: Video Adjustment

    CN-5000 User Manual Configuring the Hotkeys: If you find the default Hotkey combinations inconvenient, you can configure them to whatever suits your taste, as follows: 1. Highlight the Action, then Click Start 2. Key in the Function keys (one at a time). The key names appear in the Key field as you press them.
  • Page 49 The meanings of the adjustment options are given in the table below: Option Screen Position Adjust the horizontal and vertical position of the remote computer window by Clicking the Arrow buttons. Auto-Sync Click Auto-Sync to have the function detect the vertical and horizontal offset values of the remote screen and automatically synchronize it with the local screen.
  • Page 50 CN-5000 User Manual Notes: 2005-09-13...

  • Page 51: The Java Client

    Introduction The Java Client makes the CN-5000 accessible to all platforms that have Java 2 installed. Java 2 is available for free download from Sun’s Java web site (http://java.sun.com). To access the CN-5000 with the Java Client software: 1. After you log in (see p. 12), Click the Java Client icon.
  • Page 52 CN-5000 User Manual Once the authentication procedure completes successfully, the remote system displays on your monitor: 2005-09-13...

  • Page 53: Operation

    Operation You can work on the remote system via the screen display on your monitor just as if it were your local system. Note: 1. You can switch between your local and remote programs with [Alt + Tab]. 2. Due to net lag, there might be a slight delay before your keystrokes show up.
  • Page 54 Keypad: Clicking the second button, brings up the Keypad. Since some locally input keyboard combinations can not be captured and sent to the CN-5000, the Keypad provides a one-click implementation of their actions on the remote system. 2005-09-13...
  • Page 55 6. The Java Client Mouse: At times the local mouse movement may lose sync with the remote mouse movement. You can try getting them back in sync with a fast mouse synchronization by moving the mouse pointer down into the Java Client toolbar. If that doesn’t help, do an Autosync (as discussed on the previous page).
  • Page 56 CN-5000 User Manual Notes: 2005-09-13...

  • Page 57: The Log File

    The Log File The Log File Screen The CN-5000 logs all the events that take place on it. Following a reset, it writes them to a log file, which is a searchable database. To view the contents of the log file, click the Log icon at the lower left of the page. A screen...
  • Page 58 CN-5000 User Manual A maximum of 512 events are kept in the log file. As new events are recorded, they are placed at the bottom of the list. When a new event is recorded after there are 512 events in the log file, the earliest event in the list is discarded.

  • Page 59: Ap Operation

    In addition to the browser based operation utilities, the CN-5000 also provides Windows-based programs that can be used in their stead. These include an administration utility, a Windows client, a Java client, and a Log Server. This chapter explains how to install and operate each of them.

  • Page 60: Starting Up

    If this is the first time that you are running the utility a dialog box appears requesting you to input your serial number. The serial number can be found on the CN-5000’s CD case. Key in the serial number - 5 characters per box - then Click OK.
  • Page 61 IP address (if one exists), to that device and attempts to connect again. 4. When the Administrator Utility searches for CN-5000 devices, if it finds a unit that was originally on a different network segment that still has a fixed IP address from its previous location, it will list the unit (showing the IP address), but you cannot connect to it.

  • Page 62: Logging In

    CN-5000 User Manual Logging In Once the Administrator Utility connects to the unit you specified, a login window appears: Only those who have Configuration privileges (see User Management; Permissions, p. 60) are allowed to log in. Provide a valid Username and Password, then Click Login to continue.
  • Page 63 8. AP Operation If you successfully log in to the CN-5000 with the default username and password, the following message appears: For security purposes, be sure to change the default Username and Password to something unique (see User Management, p. 60).

  • Page 64: The Settings Notebook

    CN-5000 User Manual The Settings Notebook After successfully logging in, the Settings notebook appears. There are five tabs, each representing a different administrative function. A description of the functions how to configure their settings is provided in the sections that follow.

  • Page 65: Uploading Changes

    Uploading Changes When the Settings have been configured to your satisfaction and you are ready to upload the changes to the CN-5000: 1. If you made changes on the Network page, or if you upgraded the firmware on the Customization page, you must enable Reset on Exit (see p.

  • Page 66: General

    (15 characters max.). Main Firmware Version: Indicates the mainboard’s current firmware version level. New versions of the CN-5000’s firmware can be downloaded from our web site as they become available (see p. 64 for upgrading details). 2005-09-13...

  • Page 67: Network

    Access Ports: As a security measure, the Administrator can set the Port numbers that the User must specify when he attempts to connect to a CN-5000’s IP address. Unless the correct Port number is given, the CN-5000 device will not be found.
  • Page 68 Log Server: Important transactions that occur on the CN-5000, such as logins and internal status messages, are kept in an automatically generated log file. Specify the MAC address and a Port number for the server you want the log file to reside on in the Log Server section.

  • Page 69: Security

    Security The Security page is used to control access to the CN-5000. User station filters permit or deny access to the CN-5000 for specific IP and MAC addresses attempting to access the system. The Default Java program name lets the Administrator specify an addition to the IP address that the user must include when he accesses the CN-5000 with the Java Client.

  • Page 70: Filtering

    CN-5000 User Manual Filtering There are a maximum of 100 filters allowed for each category (User IPs, User MACs, and Administrator MACs). To enable filtering for User Stations, Click to put a check mark in the IP and/or MAC Filter enable checkbox.
  • Page 71 § If the include button is checked, all the addresses within the filter range are allowed access to the CN-5000; all other addresses are denied access. § If the exclude button is checked, all the addresses within the filter range are denied access to the CN-5000;...

  • Page 72: User Management

    This page is used to set up and manage user profiles. It defines the access rights of each user. Up to 64 user profiles can be established. A maximum of 64 users can have access to a CN-5000. To add a user, Click Add and fill in the information asked for in the User Management dialog box that appears.
  • Page 73 View Only: Checking View Only allows the User to view the video display of the computers attached to the ports of the KVM switch connected to the CN-5000, but they are not allowed to perform any operations on the computers.

  • Page 74: Customization

    CN-5000 User Manual Customization This page allows the Administrator to upgrade the firmware and to set Timeout and Login failure parameters. 2005-09-13...
  • Page 75 Multiuser operation Placing a check here allows multiple users to access the CN-5000 at the same time. Up to 16 users can log in at the same time this way. Reset on exit Placing a check here causes the CN-5000 to reset itself and implement all the new changes when you Click OK.

  • Page 76: Upgrading The Firmware

    CN-5000 User Manual Upgrading the Firmware New versions of the Mainboard firmware files can be downloaded from our website as they become available. After downloading the new firmware file, to upgrade the firmware, do the following: 1. Go to the Customization page of the Administration configuration notebook (see p.
  • Page 77 Open. Go back and select the correct file type. 4. Enable the Reset on exit checkbox. 5. Click OK to save your settings and reset the CN-5000. Following the reset, wait approximately 30 to 60 seconds before logging back in to the Administrator Utility.

  • Page 78: The Windows Client

    CN-5000 User Manual The Windows Client The Windows-based Client software is provided on the distribution CD included with this package. Installation To install the Windows Client: 1. Open the drive and folder where the Windows Client Setup icon (CN5KClient.exe) is located and double click the icon.

  • Page 79: Starting Up

    If this is the first time that you are running the program, a dialog box appears requesting you to input your serial number: If you don’t know what it is, contact the CN-5000 administrator. Key in the serial number - 5 characters per box - then Click OK.
  • Page 80 Double Click it. CN-5000 IP: This area is used when you want to connect to a CN-5000 at a remote location. You can drop down the list box and select an IP address or key in an IP address if the one you want isn’t listed, then key in the Port number in the Port field.

  • Page 81: The File Menu

    The File Menu allows the operator to Create, Save, and Open user created Work files. A Work File consists of all the information specified in a Client session. This includes the CN-5000 and CN-5000 IP list items, as well as the Hotkey settings.

  • Page 82: The Tools Menu

    CN-5000 User Manual The Tools Menu Tools menu operations are performed after you connect, but before you switch to remote view. There are two entries on the Tools Menu: Keyboard and Config. They are explained in the sections that follow.

  • Page 83: Config

    Config When you select Config, a screen similar to the one below appears: If Full Screen Mode is enabled (there is a checkmark in the box), the remote display fills the entire screen of your local monitor. If Full Screen Mode is not enabled (there is no checkmark in the box), the remote display appears as a window on your desktop.

  • Page 84: Connecting

    3. Once contact with the CN-5000 has been established, the Switch to Remote View button becomes active. Click it to connect to the CN-5000 and take over console control of the unit that is connected to it. 2005-09-13...

  • Page 85: Operation

    8. AP Operation Operation Once the connection to the CN-5000 has been accomplished, the remote system’s video output is captured and displayed on your monitor. At the same time, your local keystroke and mouse input is captured and sent to the remote system.

  • Page 86: The Java Client

    CN-5000 User Manual The Java Client The Java Client is provided to make the CN-5000 accessible to all platforms. Systems that have Java version 1.4 or higher installed can connect. If you don’t already have Java, it is available for free download from Sun’s Java web site (http://java.sun.com).
  • Page 87 An Address Input dialog box appears: 4. Key in the IP address for the unit you want to connect to - including a forward slash followed by the name of the CN-5000’s Default Java Program Name (see p. 19). For example: 168.10.95.1/abcdefg...

  • Page 88: Operation

    CN-5000 User Manual 5. Provide a valid Username and Password and Click OK. Once the authentication procedure completes successfully, the remote system displays your monitor: Operation The look and feel of the AP Java client operation is the same as for the browser version of the Java client.

  • Page 89: The Log Server

    The Log Server The Windows-based CN5000 Log Server is an administrative utility that records all the events that take place on selected CN-5000 units. Installation 1. Insert the CN-5000 software CD into your CD-ROM drive. 2. Open the drive and folder where the Log Server Setup icon (CN5KLogServer.exe) is located and double click the icon.

  • Page 90: Starting Up

    The screen is divided into three components: A Menu Bar at the top A panel to display a list of CN-5000 units below it (see p. 83 for details). A panel to display an Events List at the bottom Each of the components is explained in the sections that follow.

  • Page 91: The Menu Bar

    CN-5000 units to the CN-5000 List; edit the information for units already on the list; or delete CN-5000s from the list. To edit or delete a listed CN-5000, first select the one you want in the CN-5000 List window, then open this menu and click Edit or Delete.

  • Page 92: Events

    A description of the fields is given in the table, below: Field Address This can either be the IP address of the CN-5000 or its DNS name (if the network administrator has assigned it a DNS name). Port The Log Server port number assigned to the CN-5000 (see p. 55).
  • Page 93 This is one of three radio buttons that define the scope of the search. If it is selected, the search is performed on all the events in the database for the selected CN-5000. Search last results This is a secondary search performed on the events that resulted from the last search.

  • Page 94: Options

    CN-5000 User Manual Maintenance: Records are not automatically erased when their time limit (set with the Limit setting of the Edit function - see p. 80), comes due. They still remain in the database even though they have exceeded their expiration time.

  • Page 95: The Cn-5000 List Panel

    Log Server to track (see Configure, p. 79). Tick information for the currently selected CN-5000 displays in the Events List panel below it. To select a CN-5000 unit in the list, simply click on it. 2005-09-13...
  • Page 96 This is the Port number assigned to the CN-5000 (see Configure, p. 79). Connection If the Log Server is connected to the CN-5000, this field displays Connected. If it is not connected, this field displays Waiting. This means that the Log Server’s MAC address has not been set properly.

  • Page 97: The Event List Window

    8. AP Operation The Event List Window This window displays tick information for the currently selected CN-5000. Note that even though any other CN-5000s aren’t currently selected, if their Recording checkbox is checked, the Log Server records their tick information and keeps it in its database. You can see the server’s tick information by selecting it.
  • Page 98 CN-5000 User Manual Notes: 2005-09-13...

  • Page 99: Appendix

    Specifications Function Connectors Console 1 x 6 pin mini-DIN F - Keyboard Ports 1 x 6 pin mini-DIN F - Mouse 1 x HDB-15 F - Video KVM Link 1 x SPHD-15 F 1 x RJ-45 Receptacle 1 x RS-232 Power 1 x DC Jack (5V;...

  • Page 100: Ip Address Determination

    If you are an administrator logging in for the first time, you need to access the CN-5000 in order to give it an IP address that users can connect to. There are three methods to choose from. In each case, your computer must be on the same network segment as the CN-5000.
  • Page 101 Method 2: (For a fixed IP address) A fixed IP address can also be assigned with the ARP command as follows: 1. If the CN-5000 is powered on, Power it off by unplugging its power adapter cable. 2. Run the ARP command with the following arguments: arp -s <desired ip address>...
  • Page 102 CN5000 Devices panel: Note: 1. If there is more than one device in the list, use the MAC address to pick the one you want. The CN-5000’s MAC address is located on its bottom panel. 2. If the list is empty, or your device doesn’t appear, click Refresh to refresh the Device List.

  • Page 103: Administrator Login Failure

    4. When the front panel LEDs flash, power off the switch. 5. Remove the jumper cap from J6. 6. Close the housing and start the CN-5000 back up. After you start back up, you can use the default Username and Password (see p.

  • Page 104: Troubleshooting

    Troubleshooting General Operation Problem Erratic Operation If the CN-5000 is connected to a KVM switch, make sure to power on the switch before powering on the CN-5000. Press and hold the Reset button (see p. 5), for longer than three seconds.

  • Page 105: Sun Systems

    Sun Systems Problem Video display problems with The display resolution should be set to 1024 x 768: HDB15 interface systems (e.g., Sun Blade 1000 Under Text Mode: servers). 1. Go to OK mode and issue the following commands: setenv output-device screen:r1024x768x60 reset-all Under XWindow: 1.

  • Page 106: The Java Client

    CN-5000 2. Make sure to include the correct name of the web page when you specify the CN-5000’s IP address. 3. Close the Java Client, reopen it, and try again. Java Client Exit the program and start again.

  • Page 107: Limited Warranty

    Appendix Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR’S LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT FROM THE DIRECT, INDIRECT, SPECIAL, INCIDEN- TAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK OR ITS DOCUMENTATION. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and specially disclaims its quality, performance, merchantability, or fitness for any particular purpose.
  • Page 108 CN-5000 User Manual Notes: 2005-09-13...

  • Page 109: Index

    Cable information ....8 CN-5000 Front view..... 5 Rear view .
  • Page 110 CN-5000 User Guide Maintenance ....82 Menu Bar ....79 Options .
