PR 30-HVS Quick Guide – Slopes

Setting Slopes

1. Use the target
to aim & align
tool to the
desired slope
Optional (for accurate direction):
Slope e-Targeting
1. Set Slope as
shown above
2. Press e-
Targeting key
Determining Slopes
1. Use the target
to aim & align
tool to the slope
* Read the operating instructions before the tool is used for the first time
www.hilti.com.au
3. Press Slope
Mode key
2. Press
ON/OFF
3. Position PRA 30
3. Press Slope
Mode key
2. Press
ON/OFF
4. Use + / - keys
to set the desired
inclination
Turn tool according to LED arrow
Move PRA 30 on leveling
staff to reference level next
to rotator & fix it.
Position the leveling staff
to desired end point of
slope and double click the
auto-align key on PRA 30.
(2x)
When tool is aligned,
press e-Targeting key to
exit and start working
with set slope.
PR 30-HVS I Quick Guide I 2014
3
