AUX ASW-H09A4/EAR1-dw Service Manual page 71

No.
1 Steel grille
2 Front panel
3 Top cover board
4 Outdoor fan
5 Outdoor fan motor
6 Motor bracket
7 Condenser assembly
8 Condenser gas inlet tube
9 Capillary assembly
10 Backside steel grille
11 Handle
12 Right-side plate
13 Capacitor clamp
14 Fan motor capacitor
15 Compressor capacitor
16 Terminal board
17 Electrical holding plate
18 Partition plate
19 Electromagnetic loop
20 Four-way valve and capillary assembly
21 Compressor connection cord
22 Compressor grounding cord
23 Compressor terminal cover
24 Over-load protector
25 Compressor
26 Liquid valve
27 Gas valve
28 Valve plate
29 Chassis
Name
- 71 -
Quantity
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
