INSTALLATION
MANUAL
Split Type Wall Mounted
R32
Air-conditioner
MODELS
ASW-09/DIQE
ASW-09/DIQE
ASW-18/DIQE
ASW-24/DIQE
ASW-09/DIMA
ASW-13/DMA
ASW-18/DIMA
ASW-24/DIMA
ASW-09/DICA
ASW-13/DICA
ASW-18/DICA
ASW-24/DICA
ASW-09/DIMA-3S
ASW-13/DIMA-3S
ASW-18/DIMA-3S
ASW-24/DIMA-3S
ASW-09/DICA-3S
ASW-13/DICA-3S
ASW-18/DICA-3S
ASW-24/DICA-3S
※
Please read this installation manual carefully and thoroughly before installing the unit.
※
Take care of this manual for future reference.
AUX CLOUD COMMERCE (THAILAND) COMPANY LIMITED
7/527 M.6 T. Mapyangphon, A.Pluakdaeng, Rayong 21140 (Head Office)
Advertisement
Related Manuals for AUX ASW-09/DIQE
Summary of Contents for AUX ASW-09/DIQE
- Page 1 ASW-13/DIMA-3S ASW-18/DIMA-3S ASW-24/DIMA-3S ASW-09/DICA-3S ASW-13/DICA-3S ASW-18/DICA-3S ASW-24/DICA-3S ※ Please read this installation manual carefully and thoroughly before installing the unit. ※ Take care of this manual for future reference. AUX CLOUD COMMERCE (THAILAND) COMPANY LIMITED 7/527 M.6 T. Mapyangphon, A.Pluakdaeng, Rayong 21140 (Head Office)
- Page 2 CONTENTS WARNING SAFETY PRECAUTION NOTICES FOR USAGE NOTICES FOR INSTALLATION INSTALLATION DIAGRAM INSTALLATION FOR INDOOR UNIT INSTALLATION FOR OUTDOOR UNIT TESTING AND INSPECTION CLEAN AND CARE TROUBLESHOOTING MAINTENANCE NOTICE Note: All the illustrations in this manual are for explanation purpose only. ●...
- Page 3 Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
- Page 4 WARNING NOTE: The Air conditioner with R32 refrigerant, if roughly Room Space and Maximum Refrigerant Charge Requirements treated, may cause serious harm to the human body or surrounding things. Allowable Refrigerant Min. Floor Area For Refrigerant Type ● The room space and maximum refrigerant charge Charge Amount, (kg) Installation, (m²) requirements are shown in the table to the right.
- Page 5 SAFETY PRECAUTIONS ！ WARNING ● Don't attempt to repair the air conditioner by yourself. Incorrect repairs may cause fire or explosion. ● Contact a qualified service technician for all service requirements. ● Don't operate the air conditioner during a lightning storm. The power supply should be switched off to prevent danger or injury. ●...
- Page 6 NOTICES FOR USAGE Operating Range ● Operating the unit outside the recommended temperature range may have an impact on the system performance. ● When the temperature is too high, the air conditioner may Range Indoor Outdoor trip the circuit breaker causing the air conditioner to shut down. ●...
- Page 7 NOTICES FOR INSTALLATION Important Notices ● This unit must be installed by a certified contractor to avoid: ● Damage to the unit ● Refrigerant leaking int the atmosphere ● Electrical shock ● Burns from refrigerant ● Other serious injury to include death ●...
- Page 8 NOTICES FOR INSTALLATION Requirements of the Mounting Structure ● The mounting rack must meet the relevant national or industrial standards ● It is recommended that the mounting rack and its load carry surface shall be able to withstand 4 times or above the weight of the unit.
- Page 9 INSTALLATION DIAGRAM Accessories Read these Safety Considerations carefully before installing the drain pan heater. After completing the installation, check if the unit operates properly during the start-up operation. Packing list Name Quantity Unit Outdoor Unit Field-supplied Parts Indoor Unit Unit Name Quantity Remote Controller...
- Page 10 INSTALLATION DIAGRAM Unit Parts Power cable Air inlet Force switch Front Panel Indoor unit Pipe protection ring Air filter Horizontal vane Left-right swing blade Slip buckle Air outlet Air filter Remote Controller Holder Remote Controller Air inlet Outdoor unit Inter-connection wire Air outlet grille Connecting pipe Drain hose...
- Page 11 INDOOR UNIT INSTALLATION Dimension Drawing of Indoor Unit Installation Space to the ceiling 20cm above 20cm above Space to the wall Space to the wall 2.5m above Space to the floor NOTE: 1.For safety requirements, the unit must be installed at least 8.2ft above the floor. 2.If installing the unit over a bookshelf or a shelf mounted to the wall, the unit must have 14in from the bottom of the unit to the top of the shelf.
- Page 12 INDOOR UNIT INSTALLATION Mounting Installation Plate installation plate 36 Unit: mm Through the wall hole 1250 Wall-through Hole Wall Unit:mm 1. Once a suitable location has been determined, drill hole with an outwardly slant of Inside Outside 5°-10° to ensure proper drainage. Pipe protection ring 2.
- Page 13 INDOOR UNIT INSTALLATION Mount the Indoor Unit 1.Mount the unit onto the installation plate Hook the indoor unit onto the upper portion of the installation plate (Engage the two hooks at the rear top of the indoor unit with the upper edge of the installation plate). Ensure that the hooks are properly seated on the installation plate by moving it to the left and right.
- Page 14 INDOOR UNIT INSTALLATION Water Drainage Piping The indoor drain pipe must be in a downward gradient for smooth drainage. Avoid situations that are likely to cause water to leak. √ Water retention 2° Drain Water leaking Water leaking Water leaking End dipped into the water Refrigerant Piping Allowable Piping Length...
- Page 15 4.The power cable may be routed separately from the piping. Cut off the outlet cutting stock and then run the power cable Wiring cover through the hole, keeping the remaining part as a protection from rodents. MODELS ASW-09/DIQE ASW-09/DIQE ASW-18/DIQE ASW-24/DIQE ASW-09/DIMA ASW-13/DMA...
- Page 16 INDOOR UNIT INSTALLATION Electrical Wiring Connection Note: ※This manual usually includes the wiring mode for the When stripping the ends of interconnecting wires in different kind of air conditioner. We cannot exclude advance, bind right ends of the possibility that some special type of wiring wires with insulating tape.
- Page 17 OUTDOOR UNIT INSTALLATION Installation Guide at the Seaside 1. Air conditioners should not be installed in areas where corrosive gases, such as acid alkaline gas, are produced. 2.Do not install the product where it could be exposed to direct salt air. Sea air exposure can result in corrosion on the unit.
- Page 18 OUTDOOR UNIT INSTALLATION Dimension Drawing of Outdoor Unit Installation Air in side Space to the obstruction Space to the Space to the 50cm Above obstruction 30cm Above obstruction Air out side Installation outdoor unit bolt Outdoor Unit Size of Shape A, mm B, mm W1 (W2)*H*D), mm...
- Page 19 OUTDOOR UNIT INSTALLATION Wiring Connection 1.Loosen the screws and remove the cover of pass wire from the unit. Cover of Pass Wire 2.Connect the cables respectively to the corresponding terminals of the terminal board of the outdoor unit (see the wiring diagram), using ring connectors.
- Page 20 TESTING AND INSPECTION Check After Installation ●Electrical Safety Check 1. If the supply voltage is within tolerance. 2. If the indoor and outdoor units are properly wired. 3. If the grounding wire of the air conditioner is securely grounded. ● Installation Safety Check 1.
- Page 21 CARE AND CLEANING Clean the Panel When the panel of the indoor unit is dirty, clean it with soft dry cloth or a cloth that is slightly dampened with water. Clean the Air Filter ■ Remove the air filter 1. Use both hands to open the front panel to gain access to the filters.
- Page 22 TROUBLESHOOTING CAUTION Do not attempt to repair the air conditioner by yourself as wrong maintenance may cause electric shock, fire, or explode. Please contact a authorized contractor and let the professionals conduct the maintenance and repairs. Checking the below items prior to contacting a contractor can help identify a potential problem. Phenomenon Troubleshooting ●Excessive accumulation of dust on filter, blocking the air inlet or outlet →...
- Page 23 TROUBLESHOOTING Phenomenon Troubleshooting ● When the indoor temperature and humidity are high, it happens sometimes. During the cooling operation, →This is because the indoor air is cooled rapidly. After it runs for some the indoor unit outlet time, the indoor temperature and humidity will be reduced and the mist will sometimes will blow out mist.
- Page 24 MAINTENANCE NOTICE Attention： For maintenance or scrap, please contact a authorized contractor. Maintenance by unqualified person may cause injury or damage to the unit. Charge air conditioner with R32 refrigerant only, and maintain the air conditioner in a strict accordance with manufacturer's requirements.
- Page 25 MAINTENANCE NOTICE Operating Procedures 7. Checks to electrical devices: Repair and maintenance to electrical components shall include initial safety checks and component inspection procedures. If a fault exists that could compromise safety, then no electrical supply shall be connected to the circuit until it is satisfactorily dealt with.
- Page 26 MAINTENANCE NOTICE Procedures of Charging Refrigerants As a supplement to the general procedure, the following requirements need to be added: - Make sure that there is no contamination among different refrigerants when using a refrigerant charging device. The pipeline for charging refrigerants should be as short as possible to reduce the residual of refrigerants in it. - Storage tanks should remain vertically up.
- Page 28 DE-COMMISSIONING,DISMANTLING&DISPOSAL This product contains refrigerant under pressure, rotating parts, and electrical connections which may be a danger & cause injur. All work must only be carried out by competent persons using suitable protective clothing and safety precautions. Unit is Remotely controlled Read the Manual Risk of Electric Shock &...
