Section 8: Rechargeable battery measurements
The following figures show the results of this test application.
8-10
Figure 40: Model 2450 USER swipe screen showing test results
1 Measured load current
2 Measured battery voltage
3 Source value and elapsed test time
Figure 41: Results of battery charge and discharge test
