SYSTEM SPECIFICATIONS

Lower cut-off frequency (-6 dB)
Upper cut-off frequency (-6 dB)
Main channels / LFE
Driver, magnetically shielded
Harmonic distortion at 90 dB SPL
at 1 m on axis in half space 30...85 Hz
2nd
3rd
Maximum short term sine wave SPL
output averaged from 30 to 85 Hz,
measured in half space at 1 meter
Self generated noise level in half space
at 1 m on axis (A-weighted)
Weight
Dimensions
Height
Width
Depth

AMPLIFIER SECTION

Amplifier short term output power
(Long term output power is limited by
driver unit protection circuitry)
Amplifier system THD at nominal output
Mains voltage
Power consumption (average)
Standby (ISS active)
Idle
Full output
7050C
24 Hz
85 Hz / 120 Hz
205 mm (8 in)
≤ 4 %
≤ 1 %
103 dB
≤ 5 dB
17.3 kg (38.1 lb)
410 mm (16 1/8 in)
350 mm (13 3/4 in)
319 mm (12 9/16 in)
7050C
130 W
≤ 0.05 %
100 - 240 V 50/60 Hz
universal
≤ 0.5 W
11 W
150 W

CROSSOVER SECTION

Subsonic filter (18 dB/octave) below
Input channels
Low pass frequency for inputs 1-5
Low pass frequency for LFE IN input
Input connectors XLR female
pin 1
pin 2
pin 3
Input impedance
Midband rejection >400 Hz
High pass frequency for outputs 1-5
Output connectors XLR male
pin 1
pin 2
pin 3
Output gain
Bass Roll-Off control in 4 dB steps
Phase matching control in 90° steps
Input sensitivity control
LFE input sensitivity control
7050C
24 Hz
5 + LFE
85 Hz
120 Hz
gnd
+
-
10 kOhm balanced
≥ 50 dB
85 Hz
gnd
+
-
0 dB
0 to -12 dB @ 26 Hz
0 to -270°
+12 to -6 dBu
0 or +10 dB selectable
