Genelec 7060A Quick Setup Manual

Subwoofer placement

B
A
C
D
Distance from front wall
110 cm (43’’)
60 cm (24’’)
Aligning the subwoofer
Genelec Document BBAQSLSE001. Copyright Genelec Oy 2.2003. All data subject to change.
Note:
C
1) Positions A and B are recommended.
2) Position C causes a significant bass
boost and may cause asymmetrical
spatial imaging if only one subwoofer is
used.
D
3) Recommended position for two linked
subwoofers is A+B. Positions C and D
may also work, but may cause loss of LF
when off room center axis.
4) LF mutual coupling causes a 6 dB
bass level increase when using two, 9.5
dB with three and 12 dB with four sub-
woofers.
Main
speaker
10 cm (4’’)
Quick setup guide
7060A-7070A-7071A
Suggested Tone Control
settings for a single subwoofer
Position
A, B and D:
-2 dB
Position C:
-6 dB
Positioning too far from the wall may
cause a loss in low frequency response
60 cm (24’’)
10 cm (4’’)
Bass
Input
Roll-Off
sensitivity
ROLL-OFF PHASE
+3 0
-2 dB 0/-90 DEG
-3
-4 dB 0/-180 DEG
+6
-4
ON
-6
+12
1 1 2 2 3 3 4 4
ROLL-OFF PHASE
+3 0
-2 dB 0/-90 DEG -3
+6
-4 dB 0/-180 DEG
-4
ON
+12 -6
1 1 2 2 3 3 4 4
10 cm (4’’)
