Features - Lab.gruppen IPD 1200 Operation Manual

1.2. Features

• High power density with up to 2400 W in 1 U
• Two models: 2 × 600 W or 2 × 1200 W (at 4 ohms)
• Low mains current draw with proven IDEEA
• AES3 and analog inputs with redundant failover
• Link outputs for analog and AES3
• Ethernet network connection
• Fast network setup with auto-discovery and ID of amplifiers
• Networked control via IntelliDrive Controller™ software with touchscreen-friendly GUI
• Wireless control via iPad (requires connection of WiFi router)
• Four-channel input mixer
• Integrated DSP includes:
• 40 real-time, multi-slope parametric equalizers
• Adjustable high-pass and low-pass filters
• Input delay (up to 2 s)
• Output delay (up to 2 s)
• Crossover with multiple filter types
• 100 user-definable presets
• Backlit display with navigation buttons and encoder for front panel setup
• Horizontal VU meters on display in operating mode
• Front-panel mute buttons
• Software configurable limiters (SCVPL)
• Binding post and Neutrik speakON connectors
• Outputs may be connected through either one (NL-4) or both speakONs
• Universal power supply: 100 - 240 V at 50 or 60 Hz
technology
®
IPD SERIES Operation Manual rev 2.0.0
1. Introduction
7
