マシンコントローラ
MP3300 CPU
取扱説明書
形式：
JAPMC-CP3301-1-E
製品を安全にお使いいただくために，本書を必ずお読みください。
また，本書をお手元に保管していただくとともに，最終的に本製品をご使用になる
ユーザー様のお手元に確実に届けられるよう，お取り計らい願います。
Machine Controller MP3000 Series
MP3300 CPU Module
INSTRUCTIONS
Model: JAPMC-CP3301-1-E, -CP3301-2-E, -CP3302-1-E, -CP3302-2-E
To properly use the product, read this manual thoroughly and retain
for easy reference, inspection, and maintenance. Ensure the end user
receives this manual.
Contrôleur de Machine Série MP3000
Module CPU MP3300
INSTRUCTIONS
Modèle: JAPMC-CP3301-1-E, -CP3301-2-E, -CP3302-1-E, -CP3302-2-E
Pour utiliser correctement le produit, lisez attentivement ce manuel.
Conservez-le comme références et pour les cas d'inspections et de
maintenance. Assurez-vous que l'utilisateur final reçoive ce manuel.
MANUAL NO. TOMP C880725 23A
MP3000
シリーズ
モジュール
，
-CP3301-2-E
，
-CP3302-1-E
，
-CP3302-2-E
Advertisement
Table of Contents
Related Manuals for YASKAWA JAPMC-CP3301-1-E
Summary of Contents for YASKAWA JAPMC-CP3301-1-E
- Page 1 ユーザー様のお手元に確実に届けられるよう，お取り計らい願います。 Machine Controller MP3000 Series MP3300 CPU Module INSTRUCTIONS Model: JAPMC-CP3301-1-E, -CP3301-2-E, -CP3302-1-E, -CP3302-2-E To properly use the product, read this manual thoroughly and retain for easy reference, inspection, and maintenance. Ensure the end user receives this manual. Contrôleur de Machine Série MP3000...
- Page 2 Yaskawa. No patent liability is assumed with respect to the use of the information contained herein. Moreover, because Yaskawa is constantly striving to improve its high-quality products, the information contained in this manual is subject to change without notice.
-
Page 3: Safety Precautions
Safety Precautions Safety Information To prevent personal injury and equipment damage in advance, the following sig- nal words are used to indicate safety precautions in this document. The signal words are used to classify the hazards and the degree of damage or injury that may occur if a product is used incorrectly. - Page 4 Safety Precautions That Must Always Be Observed General Precautions WARNING • Read and understand this manual to ensure the safe usage of the product. • Keep this manual in a safe, convenient place so that it can be referred to whenever necessary.
- Page 5 Storage and Transportation Precautions CAUTION • Do not store the product in any of the following locations. • Locations that are subject to direct sunlight • Locations that are subject to ambient temperatures that exceed the storage conditions • Locations that are subject to ambient humidity that exceeds the storage conditions •...
- Page 6 Installation Precautions CAUTION • Do not install the product in any of the following locations. • Locations that are subject to direct sunlight • Locations that are subject to ambient temperatures that exceed the operating conditions • Locations that are subject to ambient humidity that exceeds the operat- ing conditions •...
- Page 7 Wiring Precautions CAUTION • Check the wiring to be sure it has been performed correctly. There is a risk of motor run-away, injury, or accidents. • Always use a power supply of the specified voltage. There is a risk of fire or accident. •...
- Page 8 CAUTION • Select the I/O signal wires for external wiring to connect the product to external devices based on the following criteria: • Mechanical strength • Noise interference • Wiring distance • Signal voltage • Separate the I/O signal cables for control circuits from the power cables both inside and outside the control panel to reduce the influ- ence of noise from the power cables.
- Page 9 • The illustrations that are presented in this manual are typical examples and may not match the product you received. • If the manual must be ordered due to loss or damage, inform your nearest Yaskawa representative or one of the offices listed on the back of this manual.
-
Page 10: Warranty
Limitations of Liability • Yaskawa shall in no event be responsible for any damage or loss of opportu- nity to the customer that arises due to failure of the delivered product. • Yaskawa shall not be responsible for any programs (including parameter set- tings) or the results of program execution of the programs provided by the user or by a third party for use with programmable Yaskawa products. - Page 11 Yaskawa product is used in combination with any other products. • The customer must confirm that the Yaskawa product is suitable for the sys- tems, machines, and equipment used by the customer. • Consult with Yaskawa to determine whether use in the following applications is acceptable.
-
Page 12: Table Of Contents
Contents Safety Precautions....... .1 Warranty ........8 Confirmations Upon Delivery . -
Page 13: Confirmations Upon Delivery
If you find any problems with the above items, contact the place of pur- chase or your Yaskawa representative immediately. 1.1 Interpreting Manufacturing Year and Month The manufacturing year and month are given as part of the serial number. -
Page 14: Accessories
1 Confirmations Upon Delivery 1.2 Accessories Name Model Number Remarks − − Front Panel Battery JZSP-BA01 To back up memory Cable Tie T18R-V0 To secure USB memory E-12... -
Page 15: Installation
2 Installation Installation Refer to the following manual for details on installing the product. MP2000/MP3000 Series Machine Controller System Setup Manual (Manual No.: SIEP C880725 00) 2.1 Precautions for the Installation Location Precautions for the installation location are given in the following table. Installation Installation Precautions Condition... -
Page 16: Control Panel Cooling Method
2 Installation 2.2 Control Panel Cooling Method The components that are used in the MP3300* require the ambient oper- ating temperature to be between 0 and 60°C. Use one of the methods described below to ensure adequate cooling in the control panel. * The MP3300 includes CPU Module and base Unit. - Page 17 2 Installation Control Panels with Forced-air Cooling For either of the following methods, install a fan near the center of and at the top or bottom of the MP3300. • Forced draft method (A fan or a similar device is used to circulate the air in the interior and the exterior of the panel.) •...
-
Page 18: Wiring
3 Wiring Wiring Refer to the following manual for details on connecting the product. MP2000/MP3000 Series Machine Controller System Setup Manual (Manual No.: SIEP C880725 00) 3.1 Wiring Precautions Wiring precautions are given below. CAUTION • Configure the circuits to turn ON the power supply to the CPU Module before the 24-V I/O power supply. - Page 19 3 Wiring <Example Circuit Configuration> Power supply MP3300 and Output Module Interlock output CPU RUN SB000004 OB000000 Power supply ON relay for output devices DC power supply DC power supply Output Module Output devices SB000004: Always ON Coil (ON while the CPU Module is operating normally.) OB000000: Interlock output Note: The MP3300 includes CPU Module and Base Unit.
- Page 20 3 Wiring Outputs Connected to Other Input and Output Devices Connect the CPU RUN output (interlock output) from the CPU Module to other input and output devices as an interlock signal, and confirm that the CPU RUN output from the CPU Module is ON before using inputs and out- puts on other devices.
- Page 21 3 Wiring <Example Circuit Configuration> MP3300 and Output Module Other Input and Output Devices Interlock output SB000004 CPU RUN OB000000 Interlock signal input Input and ∗ output signals SB000004: Always ON Coil (ON while the CPU Module is operating normally.) OB000000: Interlock output * Design the circuits so that input and output signals from other input and output devices are used only after the interlock signal turns ON.
-
Page 22: Inspections
4 Inspections Inspections Perform inspections and part replacements according to the information that is provided in this section. 4.1 Daily Inspections The daily inspection items are given in the following table. Inspection Item Description Criteria Correction Installation Loose screws All screws and covers Tighten the condition or covers... -
Page 23: Periodic Inspections
4 Inspections 4.2 Periodic Inspections Perform the following inspections at least once a year. Inspection Inspection Item Description Correction Period Ambient tempera- Measure the tem- ture* perature and humid- Remove sources Ambi- ity with a hydrometer Ambient At least 1 or 2 of contamination and thermometer humidity... -
Page 24: Replacement Guidelines For Product Parts
Yaskawa will inspect your product and determine if part replacement is required. Yaskawa will initialize the settings of all parameters to the default values in products that are returned for overhaul. Before you start operation again, make sure that you reset the parameters that are required for operation. -
Page 25: Emc Standard Compliance
5 EMC Standard Compliance EMC Standard Compliance The product complies with the following EMC standards: EN 55011 group 1 class A, EN 61000-6-2, and EN 61000-6-4. However, the product is an electric device that is used as part of a machine or manufacturing equip- ment. -
Page 26: Revision History
Revision History The revision dates and numbers of the revised manuals are given on the bot- tom of the back cover. MANUAL NO. TOMP C880725 23A <1> Revision number Published in Japan October 2014 Date of publication Date of Rev. Section Revised Contents Publication... - Page 27 Phone: +81-4-2962-5151 Fax: +81-4-2962-6138 http://www.yaskawa.co.jp YASKAWA AMERICA, INC. 2121, Norman Drive South, Waukegan, IL 60085, U.S.A. Phone: +1-800-YASKAWA (927-5292) or +1-847-887-7000 Fax: +1-847-887-7310 http://www.yaskawa.com YASKAWA ELÉTRICO DO BRASIL LTDA. 777, Avenida Piraporinha, Diadema, São Paulo, 09950-000, Brasil Phone: +55-11-3585-1100 Fax: +55-11-3585-1187 http://www.yaskawa.com.br...
- Page 28 有有害物质的信息 控制器中含 コントローラの有害物質含有情報 Information on hazardous substances in controllers 本资料根据中国 《电器电子产品有害物质限制使用管理办法》制定。 本資料は , 中国「電器電子製品有害物質使用制限管理弁法」に基づいて 記載しています。 This is based on the “Management Methods for the Restriction of the Use of Hazardous Substances in Electrical and Electronic Products.” 产品中有害物质的名称及含量 製品中の有害物質名称及び含有量 Contents of hazardous substances in products 有害物质...
- Page 29 ： 該当部品全ての均質材料による有害物質の含有量が GB/T 26572 に定め る限度量の要求以下であることを示します。 × ： 該当部品中の少なくとも1種類の均質材料における当該有害物質の含有 量が，GB/T 26572 に定める限度量を上回っていることを示します。 ： Indicates that said hazardous substance contained in all of the homogeneous materials for this part is below or equal to the limit requirement of GB/T 26572.
- Page 30 한국 전파법에 관한 주의사항 韓国電波法に関連する注意事項 Precautions for Korean Radio Waves Act 针对韩国电波法的注意事项 Précautions pour la Loi coréenne relative aux ondes radio 사용자 안내문 사용자 안내문 이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서 가정용 환경에서 사용하는 경우 전파간섭의 우려가 있습니다 . ( 주...
