  • Page 1 CAM6.6X-S1/S2 System 6-Zone, 6-Source XM Receiver and UNO Smart Keypads INSTRUCTION MANUAL...

  • Page 2: Important Safeguards

    Select the plug for your area at one end and a IEC320 con- nector at the other. It is not necessary to make any other changes. If you have any questions please call Russound Inc. at 1-800-638-8055 or 603-659-5170 Safety Instructions: 1.

  • Page 3: Table Of Contents

    USER SECTION Product Introduction ...6 Component Guide CAM6.6 Controller...7 UNO-S1 Keypad ...8 UNO-S2 Keypad ...9 UNO-LRC1 Remote Control ...10 UNO-S1 Keypad Operation ...11 UNO-S1 User Menu ...12 UNO-S2 Keypad Operation ...13 UNO-S2 User Menu ...14 Internal Source - XM Tuner XM Radio Activation...15 XM Radio Display ...15 XM Radio Modes ...16-19...
  • Page 4 TABLE OF CONTENTS Making Connections UNO Keypad Port Connections...36 Source Audio Input Connections ...37 Source IR Input Connections ...37 Common IR Input Connection ...38 Speaker Connections ...39 Zone Fixed/Variable Audio Output ...40 12VDC Home Theater Trigger In/Out ...41 12VDC Mute Trigger In/Out...42 RNET Link In/Out...43 RS-232 Interface ...44 Optional Internal Source...

  • Page 5: User Section

    Component Guides Explains front panel features of the CAM6.6 controller, UNO-S1 keypad, UNO-S2 keypad and UNO-LRC1 remote control. Operation Step-by-step outline of the system's normal operation, plus a look at adjustable features available through the User Menu. USER SECTION...

  • Page 6: Product Introduction

    Master. If the party moves to the sunroom and porch, that room’s keypad can be set to Master instead. Here at Russound we are proud to continue providing innovative and intuitive audio product solutions to the world. When you link the industry-leading CAM6.6X-S1/S2 system with Russound’s commitment...

  • Page 7: Component Guide Cam6.6 Controller

    MAIN POWER SWITCH - Supplies power to the CAM6.6 ROOM LED ON/OFF INDICATORS - Indicates when a room is on (green) or off (red) Main Power and Zone Status The power switch for the CAM6.6 controller is "on" in the up position. Any active room is indicated on the front of the controller by a green LED, which shows red when the room is inactive.

  • Page 8: Uno-S1 Keypad-Front Panel

    USER COMPONENT GUIDE UNO-S1 Keypad-Front Panel LCD PANEL - 5-character backlit display shows status of the room, source, volume, and more SOURCE SELECT BUTTON - Scrolls through the sources directly connected to the CAM6.6. Press and hold brings up the USER MENU for loudness, bass, treble, etc. VOLUME UP/DOWN BUTTONS - Raises and lowers the volume for the room IR RECEIVER - Receives IR signals and passes them to the controller and source equip- ment.

  • Page 9: Uno-S2 Keypad

    CD PLAYER 1 LCD PANEL - 12-character backlit display shows status of the room, source, volume, and more SOURCE SELECT BUTTON - Scrolls through the sources directly connected to the CAM6.6. Press and hold brings up the USER MENU for loudness, bass, treble, etc. VOLUME UP/DOWN BUTTONS - Raises and lowers the volume for the room IR RECEIVER - Receives IR signals and passes them to the controller and source equip- ment.

  • Page 10: Uno-Lrc1 Remote Control

    USER COMPONENT GUIDE UNO-LRC1 Remote Control LOCAL DEVICE BUTTONS - Select local source to be controlled by UNO-LRC1. SETUP - Use for programming UNO-LRC1 using the built-in library or by learning-in codes. UNO SOURCE BUTTON - Selects UNO Keypad for control by UNO-LRC1. ROOM ON/OFF - Turns room on and off while in the UNO mode.

  • Page 11: Uno-S1 Keypad Operation

    Zone On/Off Press and release to turn on the UNO System Keypad. This also turns on the corre- sponding CAM6.6’s room, and any presets previ- ously assigned will be activated, including set- tings for bass, volume, last source selected, etc. Press and release to turn off the UNO System Keypad.

  • Page 12: User Menu Settings

    USER USER MENU SETTINGS UNO-S1 User Menu Operation The User Menu allows the user to adjust the audio properties and control functions of a par- ticular room. To enter or exit the User Menu, press and hold during normal operation. The following keys are used to navigate and make changes while using the User Menu: Press and hold to adjust feature setting...

  • Page 13: Uno-S2 Keypad Operation

    Zone On/Off Press and release to turn on the UNO System Keypad. This also turns on the corre- sponding CAM6.6’s room, and any presets previ- ously assigned will be activated, including set- tings for bass, volume, last source selected, etc. Press and release to turn off the UNO System Keypad.

  • Page 14: Uno-S2 User Menu

    USER USER MENU SETTINGS UNO-S2 User Menu Operation The User Menu allows the user to adjust the audio properties and control functions of a par- ticular room. The following keys are used to navigate and make changes while using the User Menu: To enter the User Menu, press and hold during normal operation.

  • Page 15: Xm Radio Activation

    1. Turn on the power, select the XM Tuner source, and select channel 0. The tuner’s eight-character XM satellite Radio ID number will appear on the display. Write the number down to have it available when contacting XM Radio for activation. The number is also shown on the back of the unit and on the product box.

  • Page 16: Xm Radio Modes

    USER INTERNAL SOURCE - XM TUNER XM Radio Modes XM Radio Modes There are four user “modes” for selecting music on the XM Tuner: Preset (default or normal) Category Search Now Playing Display Preferences. These modes are accessed through certain button and key presses from the tuner panel, remote controls and keypads.
  • Page 17 Preset (default) Mode This is the normal operating mode of the XM tuner for channel up and down, bank selection and memory presets. Next Preset This button press accesses the next saved preset (6 presets for each bank) in the chosen bank. Previous Preset This button press accesses the previous saved preset in the chosen bank Next Bank...
  • Page 18 USER INTERNAL SOURCE - XM TUNER XM Radio Modes Category Search Mode (1 1 . . C C A A T T S S E E A A R R C C H H ) XM Radio is organized by Channel Category (e.g., Rock, Country, News). Within each category is a series of channels (e.g., Top Tracks, Bluegrass Junction, XM Classics).
  • Page 19 Now Playing Mode (2 2 . . N N O O W W P P L L A A Y Y N N G G ) This mode displays information about the current XM selection. Appropriate button presses access the next or previous information item. N N A A M M E E : : Displays the artist’s name, feature name or program name (news, talk, sports).

  • Page 20: Uno-S1 Keypad Control

    USER INTERNAL SOURCE - XM TUNER UNO-S1 Keypad Control UNO-S1 Keypad Control of Tuner Selecting the tuner On the UNO-S2 keypad, press XM Tuner by choosing the tuner’s preassigned source number (1). Selecting the desired channel Press and hold Blues channel selection.

  • Page 21: Uno-S2 Keypad Control

    UNO-S2 Keypad Control of Tuner Selecting the tuner On the UNO-S2 keypad, press XM Tuner by choosing the tuner’s preassigned source number (1). Selecting a Mode Push to toggle between XM modes. Exiting a Mode Press to exit XM mode selection menu. Selecting the desired channel for manual channel selection.
  • Page 22 USER INTERNAL SOURCE - XM TUNER UNO-S2 Keypad Control TUNER SELECTION - Select source number assigned to XM TUNER (1) TUNE UP/DOWN - Used for manual channel selection SELECT - XM operating mode toggle SEEK - (press) Exit current XM mode XM Classics SCAN - (press and hold) XM Signal Strength mode toggle...

  • Page 23: Uno-Lrc1 Remote Control

    UNO-LRC1 Remote Control of Tuner Selecting the tuner To select the XM tuner, push the source number preassigned to the XM Tuner (1), or use the UNO numeric source inputs at the bottom of the UNO-LRC1. Selecting a Mode Push to toggle between XM operating modes.
  • Page 24 USER INTERNAL SOURCE - XM TUNER UNO-LRC1 Remote Control UNO SELECTION - UNO must be the selected source for control of the CAM6.6 and any connected compo- nents. Select UNO before sending UNO-LRC1 remote commands. POWER - Power managed by CAM6.6 NUMERIC INPUT - Number buttons for direct input of channel, preset, bank (press).

  • Page 25: Installer Section

    INSTALLER SECTION Getting Started Includes an installation overview, including tools needed and wiring instructions. Component Guides Reviews front and back panel features of the CAM6.6 controller and the UNO-S1 and UNO-S2 keypads. Keypad Installation Explains UNO-S1 and UNO-S2 keypad installation and wiring. Making Connections Details front and back panel connections of the controller and the keypad.

  • Page 26: Getting Started

    • Check for any visible signs of damage. If you encounter any concealed damage, consult your Russound dealer before proceeding to install the unit. • Retain the sales receipt as it establishes the duration of the limited warranty and provides information for insurance purposes.

  • Page 27: Keypad Wiring

    Do not connect the controller's main power feed until all other connections have been made and verified. Live connection or removal of the keypad wiring or other wiring when the system is powered can cause communication problems in the network. Double-check terminations during each phase of the installation to prevent accidental damage.

  • Page 28: Component Guide

    INSTALLER COMPONENT GUIDE CAM6.6 Controller-Rear Panel RNET LINK IN AND LINK OUT - Links multiple CAM6.6’s, also links future Russound components that are RNET compatible RS-232 INTERFACE - The RS-232 Interface allows the zones to be controlled by PC or other devices that have an RS-232 Interface. The RS-232 Interface also allows for firmware updates and programming.

  • Page 29: Cam6.6 Controller Rear Panel

    OPTIONAL INTERNAL SOURCE - Factory installed optional internal source, XM radio module AC 240V-AC 110V Switch - Switches A/C input voltage between 110VAC and 240VAC AC 120/240 INPUT - Grounded 3-terminal plug detachable power cord connection for the CAM6.6 FUSE HOLDER - Holds a replaceable fuse for A/C input connection 110VAC operation-F 3A H 250V, 240VAC operation-F 1.25A H 250V SPEAKER OUTPUTS - Connect 8 Ohm speakers for each zone by using detachable color-coded modular snap connectors...

  • Page 30: Uno-S1 Keypad Front Panel

    OS Update Port - Used to update the UNO-S1 keypad operating system firmware. If an update is released, it will be available online through the Document Center on www.russound.com. Look for it in the “Firmware and Downloads” section under Multi-Zone product type. The Advanced Programming Cable is available from Russound, Part #2500-521065.

  • Page 31: Uno-S1 Keypad Rear Panel

    110 PUNCHDOWN CONNECTOR - Termination for CAT-5 connection between the UNO-S1 Keypad and the CAM6.6 controller. CAT-5 Connection The UNO-S1 Keypad uses a 110-punchdown termi- nal to provide a simple installation and strong connec- tion for CAT-5 cable’s eight conductors. Punchdown terminals require the use of a punchdown tool which has been provided with the keypad kit.

  • Page 32: Uno-S2 Keypad Front Panel

    OS UPDATE PORT - The OS Update Port is used to update the UNO-S2 Keypad oper- ating system software in the future. If an update is released, it will be available online through the Document Center on www.russound.com. Look for it in the “Firmware and Downloads” section under Multi-Zone product type. The Programming Cable is available from Russound, Part #2500-120633.

  • Page 33: Uno-S2 Keypad Rear Panel

    EXTERNAL IR RECEIVER IN CONNECTOR - Connection for an external IR Receiver. OS UPDATE JUMPER - Selects “Run” or “OS Update” mode. RESET BUTTON - Reset whenever changing from RUN to OS update 110 PUNCHDOWN CONNECTOR - Termination for CAT-5 connection between the UNO-S2 Keypad and the CAM6.6 controller.

  • Page 34: Keypad Installation

    INSTALLER UNO-S1 KEYPAD-INSTALLATION Keypad Location The best infrared remote performance is achieved with the keypad away from any direct sunlight, plasma TV, and low voltage lighting controls. Also consider convenience when choosing a location. Choose a place that is easily seen from the posi- tion where a person is most likely to be located.

  • Page 35: Uno-S2 Keypad Location And Installation

    Keypad Installation To install a double-gang keypad, you will need to use a UL/CSA approved plastic double-gang electrical box. Route CAT-5 wire to the junction box from the CAM6.6. Use the supplied 110 punchdown tool to con- nect each wire to its corresponding color labeled on the punchdown terminal.

  • Page 36: Making Connections

    INSTALLER MAKING CONNECTIONS UNO Keypad Port Connection The UNO System Keypad Ports are located on the back of the CAM6.6 in the top left of center. Connections made at the UNO Keypad Ports are made using CAT-5 T568A RJ-45 wire configura- tion.

  • Page 37: Source Audio Input Connections

    Each source component has a designated IR port on the back of the CAM6.6. This IR port is directly above the Source Audio Input Connections. 1. Using an IR emitter (the Russound 845.1 is recommended), attach the end of the emitter ” with the 1/8 the source input.

  • Page 38: Common Ir Input Connection

    COM IR jack is made using an Alternate configuration using 857 IR connecting block IR emitter with a 1/8’’ plug. The Russound 845.1 single IR emitter is recommended, or use an IR connecting block such as the Russound 857 which allows multiple units to be controlled through the COM IR Port.

  • Page 39: Speaker Connections

    The speakers are connected to the CAM6.6 using modular snap connectors. Each of these color-coded connectors is designated for the speaker set of a particular amplified zone. To avoid confusion, connect one zone speaker set at a time starting with Zone 1, taking care to keep zone and speaker wire identities straight.

  • Page 40: Zone Fixed/Variable Audio Output

    In the Fixed position, keypad volume level will not change the output level. The fixed or variable audio outputs can be used if additional amplification is desired (e.g., Russound DPA-1.2 two-channel amplifier). Use quality RCA signal cables to ensure a constant quality audio signal. NTENNA...

  • Page 41: 12Vdc Home Theater Trigger In/Out

    12VDC 100mA Trigger Out The 12VDC 100mA trigger out can be used to engage any 12VDC trigger device or component such as the Russound ACT-1 triggered outlet. The connections for the trigger out are made using a two-conductor cable with 1/8” male mini-plug jacks at each end.

  • Page 42: 12Vdc Mute Trigger In/Out

    INSTALLER MAKING CONNECTIONS 12VDC Mute Trigger In/Out 12VDC Mute Trigger In When 12VDC is applied to the Mute Trigger In, the system will fully mute any source connected to the Source Audio Input. The connections for the trigger are made using a two-conductor cable with 1/8”...

  • Page 43: Rnet Link In/Out

    MAKING CONNECTIONS RNET Link In and Link Out The RNET Link In and Link Out is also used to connect the CAM6.6 to other Russound prod- ucts with RNET. Note: If two or more CAM6.6 or CAV6.6 con- trollers will be connected using the RNET Link In...

  • Page 44: Rs-232 Interface

    232 com port is located on the back of the CAM6.6 and uses a DB-9 cable connection. For DB-9 Cable RS-232 protocol and the backup PC application, see the Document Center at www.russound.com. Look for the Technical Documents under Multi-source/Multi-room products. NTENNA CAM6.6...

  • Page 45: Optional Internal Source

    XM Antenna Connect the included XM antenna for XM recep- tion to the back panel of the XM module. The antenna comes with 20 feet of cable. If this length is not sufficient, there are aftermarket antenna kits available for custom lengths. Position the antenna near a south-facing window to receive the best signal from a satellite or ter- restrial signal.

  • Page 46: Initial Install Test

    4. Check to see that the keypad is connected to the Zone #3 Keypad Port and verify the CAT-5 is properly terminated at both ends. If none of these steps produce successful results, call Russound Tech Support for further assistance.

  • Page 47: System Programming Overview

    INSTALLER SYSTEM PROGRAMMING OVERVIEW This manual includes items that are designed to assist in the programming process. Forms (Pages 49-51) Three blank reproducible forms are included as planning tools when determining sources, settings and zone preferences. The Source and Zone Information forms and the Macro Editor form should be completed before programming, and referred to during the Installation Menu process.
  • Page 48 INSTALLER SYSTEM PROGRAMMING OVERVIEW 3. Basic Setup (SOURCE SETUP) (Pages 55-56) This procedure is mandatory to set up each source for keypad source control and is the cornerstone of the programming process. 4. Peripheral Setup (Pages 53-55) (FOR OPTIONAL INTERNAL SOURCE) This procedure provides setup and naming procedures for the XM tuner.

  • Page 49: Setup Forms

    INSTALLER SETUP FORMS...

  • Page 50: Zone Information Form

    INSTALLER SETUP FORMS...

  • Page 51: Macro Editor Form

    INSTALLER SETUP FORMS...

  • Page 52: Installation Menu Overview

    INSTALLER INSTALLATION MENU OVERVIEW There are three item types in the installation menu: Menu Item (m) – Acts as a folder that holds procedures and/or feature parameters. Procedure (p) – A sequence of feature parameters to perform a guided operation, such as configuring an UNO key.

  • Page 53: Peripheral Setup

    The following items make up the Installation Menu: PERIPH SETUP (PerSu) SOURCE SETUP (SrcSu) CTRLR SETUP (CtlSu) POWER MGT (PwMgt) MACRO EDITOR (MacEd) SYSTEM INFO (SInfo) PERIPH SETUP (PerSu) Peripheral Setup allows the CAM6.6’s optional internal source to be configured. The following items can be found in the PERIPH SETUP menu: MEM NAME (MemNm) BANK NAME (BnkNm)
  • Page 54 INSTALLER INSTALLATION MENU 2. BANK NAME – (BnkNm) CONTROLLR ID (CtlId) This procedure is used to identify the controller(s) that the tuner will respond to. See Periph Setup - Flow Chart page 68 1. Controller:# – (CtlId) 2. All controllers – (All) DIAGNOSTICS (Diags) This procedure is for factory use only.

  • Page 55: Source Setup

    1. BUILD TIME (BTime) 2. BUILD DATE (BDate) 3. VERSION (Ver) SOURCE SETUP (SrcSu) Source Setup allows the system’s sources to be configured. The following items can be found in the SOURCE SETUP menu: BASIC SETUP (BasSu) KEY CONFIG (KeyCf) SRC VOL TRIM (SrcVT) NUMERIC IR (NumIR) # OF SOURCES (#Srcs)

  • Page 56: Device Code

    INSTALLER INSTALLATION MENU a. Selected: Learned IR (LrnIR) i. LEARNED SRC – (LnSrc) ii. TEMPLATE TYP – (TType) b. Selected: Unassigned (Unasg) c. All Other Selections: 4. DEVICE CODE – (DevCd) 5. TEST IR? – (TstIR) 6. SUCCESS? – (OK?) 7.
  • Page 57 KEY CONFIG (KeyCf) Key Configuration defines zone-specific key functions for each source. See Key Config. - Flow Chart page 70 1. ZONE NUM – (Zone#) 2. SOURCE NUM – (Src #) 3. SELECT A KEY – (SelKy) 4. KEY TYPE – (KeyTp) 5.
  • Page 58 INSTALLER INSTALLATION MENU 9. SAVE CHANGES? – (Save?) SOURCE NAMES (SrcNm) This procedure allows the installer to customize the source names for the sources attached to the CAM6.6. See Source Names/Vol Trim - Flow Chart page 71 1. SOURCE NUM – (Src #) 2.
  • Page 59 4. NUMERIC TEXT – (NmTxt) 5. PREFIX CMD – (Prefx) 6. COMMAND TYPE – (CmdTp) a. Selected: Learned IR (LrnIR) i. LEARNED SRC – (LnSrc) b. Selected: Unassigned (Unasg) c. Selected: Default (Deflt) d. Selected: Macro: i. MACRO - (Macro) ii.
  • Page 60 INSTALLER INSTALLATION MENU i. LEARNED SRC – (LnSrc) b. Selected: Unassigned (Unasg) c. Selected: Default (Deflt) d. Selected: Macro: i. MACRO - (Macro) ii. MACRO ID – (MacID) e. All Other Selections: 11. DEVICE CODE – (DevCd) 12. KEY FUNCTION – (KeyFn) 13.

  • Page 61: Zone Setup

    c. Selected: Default (Deflt) d. Selected: Macro: i. MACRO - (Macro) ii. MACRO ID – (MacID) e. All Other Selections: 3. DEVICE CODE – (DevCd) 4. KEY FUNCTION – (KeyFn) 5. SAVE CHANGES? – (Save?) # OF SOURCES (#Srcs) At this field it is necessary to enter the number of sources used in the CAM6.6 system (1 to 6). This limits the sources displayed on the keypad in the normal running mode when the source button is pressed, but also limits source selections in the configuration menus.

  • Page 62: Controller Setup

    INSTALLER INSTALLATION MENU 3. PARTY ENABLE - (PtyEn) 4. MASTER ENABLE - (MstEn) 5. MUTE ENABLE - (MutEn) CTRLR SETUP (CtlId) Controller Setup is the basic configuration of the controller. This setup menu selects the options for Controller ID and Factory Initialization. See Controller Setup - Flow Chart page 75 1.
  • Page 63 All sources that have power management enabled are initialized by a “POWER ON” command/ macro. Power management is initialized when the first keypad is turned on or when the home theater trigger input has 12VDC present. The 12VDC trigger output is turned on when the first zone is turned on. All sources that have power management enabled are turned off by the “POWER OFF”...

  • Page 64: Learn Ir

    INSTALLER INSTALLATION MENU 6. POWER OFF CMD – (OfCmd) 7. COMMAND TYPE – (CmdTp) a. Selected: Learned IR (LrnIR) i. LEARNED SRC – (LnSrc) b. Selected: Unassigned (Unasg) c. Selected: Default (Deflt) d. Selected: Macro: i. MACRO – (Macro) ii. MACRO ID – (MacID) e.

  • Page 65: Learn Ir

    2. KEY FUNCTION – (KeyFn) 3. LEARN/DELETE – (Ln/Dl) 4. TEST IR? – (TstIR) 5. SUCCESS? - (OK?) MACRO EDITOR (MacEd) This procedure is used to create a sequence of commands that are launched with one key touch or other event. Up to 132 macros can be created for the system, and each macro can contain up to 10 commands including other macros and delays.

  • Page 66: System Info

    INSTALLER INSTALLATION MENU b. Selected: Unassigned (Unasg) c. Selected: Default (Deflt) d. Selected: Macro: i. MACRO - (Macro) ii. MACRO ID – (MacID) e.Selected: Delay (Delay) f. All Other Selections: 5. DEVICE CODE – (DevCd) 6. KEY FUNCTION – (KeyFn) SYSTEM INFO (SInfo) System Info allows the installer to view the controller’s manufacturing build properties.

  • Page 67: Setup Menu Flow Charts

    INSTALLER SETUP MENU FLOW CHARTS...
  • Page 68 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 69 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 70 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 71 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 72 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 73 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 74 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 75 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 76 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 77 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 78 INSTALLER SETUP MENU FLOW CHARTS...
  • Page 79 INSTALLER SETUP MENU FLOW CHARTS...

  • Page 80: Reference Section Ir Device Code List

    INSTALLER IR CODES Device Codes for TVs: 0030, 0019 Admiral 0093, 0463 Advent 0761 Aiko 0092 Aiwa 0701 Akai 0030 Alaron 0179 America Action 0180 Ampro 0751 Anam 0180 Apex Digital 0748, 0765, 0767 Audiovox 0451, 0180, 0092, 0623 Baysonic 0180 Belcor 0019...
  • Page 81 Philips 1818, 1061 Pioneer 1010 Princeton 0113, 0295 Samsung 1190, 1204 Sensory Science 1126 Sharp 1010 Sony 0850 Device Codes for SAT/DSS: AlphaStar 0772 Chaparral 0216 Crossdigital 1109 Echostar 0775, 1005 Expressvu 0775 0566 0775 General Instrument 0869 0775 Hitachi 0819 Hughes Net.
  • Page 82 0240 Gewa 0095 Holmes 1215 Hunter Douglas 0433 Lightolier 0184, 1204, 1205, 1206 LiteTouch 0084 Lutron 0597, 0318, 1239, 1597 One For All 0167 RadioShack 0240 Russound 1232, 1233 Sanyo 0336 Security System 0167 Somfy 0780 Universal X10 0167 0167...

  • Page 83: Ir Keycode List

    KEY FUNCTION UNO-S1 TV (HDTV) Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 Digit 6 Digit 7 Digit 8 Digit 9 Digit 0 Volume Up VolUp Volume Up Volume Down VolDn Volume Down Mute Mute Mute Channel Up Ch Up Channel Up Channel Dn...
  • Page 84 INSTALLER KEY CODES TV (HDTV) KEY FUNCTION UNO-S1 TV (HDTV) Off, Power On/Off Learned Only Learned Only Learned Only Learned Only Learned Only Learned Only Bright Brght Learned Only Learned Only Close Close Learned Only Open Open Learned Only Halt Halt Learned Only AM/FM...
  • Page 85 KEY FUNCTION UNO-S1 CABLE Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 Digit 6 Digit 7 Digit 8 Digit 9 Digit 0 Volume Up VolUp Volume Up Volume Down VolDn Volume Down Mute Mute Mute Channel Up Ch Up Channel Up Channel Dn Ch Dn...
  • Page 86 INSTALLER KEY CODES CABLE KEY FUNCTION UNO-S1 CABLE Off, Power On/Off Learned Only Learned Only Learned Only Learned Only Learned Only Learned Only Bright Brght Learned Only Learned Only Close Close Learned Only Open Open Learned Only Halt Halt Learned Only AM/FM AM/FM Learned Only Learned Only...
  • Page 87 KEY FUNCTION UNO-S1 VIDEO ACC Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 Digit 6 Digit 7 Digit 8 Digit 9 Digit 0 Volume Up VolUp Volume Up Volume Down VolDn Volume Down Mute Mute Mute Channel Up Ch Up Channel Up Channel Dn...
  • Page 88 INSTALLER KEY CODES VIDEO ACC KEY FUNCTION UNO-S1 VIDEO ACC Bright Brght Close Close Open Open Halt Halt AM/FM AM/FM Disk Up DiskU Disk Down DiskD Info Info External Src ExtSr Live/Intro Intro Menu Menu Back Back Fav Channel FavCh Display Fmt DFrmt Slow...
  • Page 89 KEY FUNCTION UNO-S1 SAT/DSS Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 Digit 6 Digit 7 Digit 8 Digit 9 Digit 0 Volume Up VolUp Volume Up Volume Down VolDn Volume Down Mute Mute Mute Channel Up Ch Up Channel Up Channel Dn Ch Dn...
  • Page 90 INSTALLER KEY CODES SAT/DSS KEY FUNCTION UNO-S1 SAT/DSS Bright Brght Close Close Open Open Halt Halt AM/FM AM/FM Learned Only Disk Up DiskU Disk Down DiskD Info Info External Src ExtSr Live/Intro Intro Menu Menu Back Back Fav Channel FavCh Display Fmt DFrmt Slow...

  • Page 91: Key Codes

    KEY FUNCTION UNO-S1 VCR Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 Digit 6 Digit 7 Digit 8 Digit 9 Digit 0 Volume Up VolUp Volume Up Volume Down VolDn Volume Down Mute Mutte Mute Channel Up Ch Up Channel Up Channel Dn Ch Dn...
  • Page 92 INSTALLER KEY CODES KEY FUNCTION UNO-S1 VCR Bright Brght Close Close Open Open Halt Halt AM/FM AM/FM Disk Up DiskU Disk Down DiskD Info Info External Src ExtSr Live/Intro Intro Menu Menu Back Back Fav Channel FavCh Display Fmt DFrmt Slow Slow PIP On...
  • Page 93 KEY FUNCTION UNO-S1 LASER DISC Digit 1 Digit 2 Digit 3 Digit 4 5Digit 5 6Digit 6 Digit 7 Digit 8 Digit 9 Digit 0 Volume Up VolUp Volume Up Volume Down VolDn Volume Down Mute Mute Mute Channel Up Ch Up Learned Only Channel Dn...
  • Page 94 INSTALLER KEY CODES LASER DISC KEY FUNCTION UNO-S1 LASER DISC Bright Brght Close Close Open Open Halt Halt AM/FM AM/FM Disk Up DiskU Disk Down DiskD Info Info External Src ExtSr Live/Intro Intro Menu Menu Back Back Fav Channel FavCh Display Fmt DFrmt Slow...
  • Page 95 KEY FUNCTION UNO-S1 DVD Digit 1, Traack 1 Digit 2, Track 2 Digit 3, Track 3 Digit 4, Track 4 Digit 5, Track 5 Digit 6, Track 6 Digit 7, Track 7 Digit 8,Track 8 Digit 9, Track 9 Digit 0, Track 10 Volume Up VolUp Volume Up...
  • Page 96 INSTALLER KEY CODES KEY FUNCTION UNO-S1 DVD Bright Brght Close Close Open Open Halt Halt AM/FM AM/FM Disk Up DiskU Disk Down DiskD Info Info External Src ExtSr Live/Intro Intro Menu Menu Back Back Fav Channel FavCh Display Fmt DFrmt Slow Slow PIP On...
  • Page 97 KEY FUNCTION UNO-S1 RECEIVER Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 Digit 6 Digit 7 Digit 8 Digit 9 Digit 0 Volume Up VolUp Volume Up Volume Down VolDn Volume Down Mute Mute Mute Channel Up Ch Up Preset Up Channel Dn Ch Dn...
  • Page 98 INSTALLER KEY CODES RECEIVER KEY FUNCTION UNO-S1 RECEIVER Bright Brght Close Close Open Open Halt Halt AM/FM AM/FM Disk Up DiskU Disk Down DiskD Info Info External Src ExtSr Live/Intro Intro Menu Menu Back Back Fav Channel FavCh Display Fmt DFrmt Slow Slow...
  • Page 99 KEY FUNCTION UNO-S1 AMP/MISC AUDIO Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 Digit 6 Digit 7 Digit 8 Digit 9 Digit 0 Volume Up VolUp Volume Up Volume Down VolDn Volume Down Mute Mute Mute Channel Up Ch Up Preset Up Channel Dn...
  • Page 100 INSTALLER KEY CODES AMP/MISC AUDIO KEY FUNCTION UNO-S1 AMP/MISC AUDIO Bright Brght Close Close Open Open Halt Halt AM/FM AM/FM Disk Up DiskU Disk Down DiskD Info Info External Src ExtSr Live/Intro Intro Menu Menu Back Back Fav Channel FavCh Display Fmt DFrmt Slow...
  • Page 101 KEY FUNCTION UNO-S1 CD Digit 1, Track 1,Dsc1 Digit 2, Track 2,Dsc2 Digit 3, Track 3,Dsc3 Digit 4, Track 4,Dsc4 Digit 5, Track 5,Dsc5 Digit 6, Track 6,Dsc6 Digit 7, Track 7,Dsc7 Digit 8,Track 8,Dsc8 Digit 9, Track 9,Dsc9 Digit 0, Trck10,Dsc10 Volume Up VolUp Volume Up...
  • Page 102 INSTALLER KEY CODES KEY FUNCTION UNO-S1 Bright Brght Close Close Open Open Halt Halt AM/FM AM/FM Disk Up DiskU Disk Down DiskD Info Info External Src ExtSr Live/Intro Intro Menu Menu Back Back Fav Channel FavCh Display Fmt DFrmt Slow Slow PIP On PIPOn...
  • Page 103 KEY FUNCTION UNO-S1 HOME CONTROL Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 Digit 6 Digit 7 Digit 8 Digit 9 Digit 0 Volume Up VolUp Volume Up Volume Down VolDn Volume Down Mute Mute Mute Channel Up Ch Up Bright,Raise Up Channel Dn...
  • Page 104 INSTALLER KEY CODES HOME CONTROL KEY FUNCTION UNO-S1 HOME CONTROL Bright Brght Close Close Open Open Halt Halt AM/FM AM/FM Disk Up DiskU Disk Down DiskD Info Info External Src ExtSr Live/Intro Intro Menu Menu Back Back Fav Channel FavCh Display Fmt DFrmt Slow...

  • Page 105: Source Names

    UNO-S1 UNO-S2 Aux 1 AUX 1 Aux 2 AUX 2 Blues Blues Cable Cable Cbl 1 Cable 1 Cbl 2 Cable 2 Cbl 3 Cable 3 CDCh CD Changer CDCh1 CD Changer 1 CDCh2 CD Changer 2 CDCh3 CD Changer 3 CD Player CD 1 CD Player 1...

  • Page 106: Source Names

    INSTALLER SOURCE NAMES UNO-S1 UNO-S2 RepTV Replay TV Rock Rock Satellite Sat 1 Satellite 1 Sat 2 Satellite 2 Sat 3 Satellite 3 SatRd Sat Radio Src 1 Source 1 Src 2 Source 2 Src 3 Source 3 Src 4 Source 4 Src 5 Source 5...

  • Page 107: Sample Configurations

    Sharing a single CAM6.6X (internal tuner) with multiple controllers This arrangement can support up to six CAM6.6 units for up to 36 zones/6 sources. Each additional CAM6.6 must have an incremental Controller ID # and RNET link. Audio from the source tuner can be split if used for all controllers.
  • Page 108 SAMPLE CONFIGURATIONS MULTIPLE CONTROLLERS WITH TWO TUNERS System with two CAM6.6X (internal tuner) controllers The configuration below is suitable for 7-12 zones that will have access to the tuner in the controller to which its keypad is connected only. Built-in tuners are always Source 1 and cannot be changed.
  • Page 109 Sharing an ST2 Dual Tuner with multiple CAM6.6 con- trollers (with and without tuners) The configuration below is suitable for 7 to 12 zones that can access the ST2 Dual Tuner and the CAM6.6X tuner. This configuration uses RCA “Y” cables from the ST2 Tuner source outputs to connect to both CAM6.6 source inputs.

  • Page 110: Sample Configurations

    SAMPLE CONFIGURATIONS MULTIPLE CONTROLLERS WITH ST2 DUAL TUNER Sharing an ST2 Dual Tuner with multiple CAM6.6 con- trollers (no built-in tuners) This configuration is suitable for 7 to 12 zones that can all access the ST2 Dual Tuner. This configuration uses RCA “Y”...

  • Page 111: Technical Specifications

    XM Antenna: It is prohibited to copy, decompile, disassemble, reverse engineer, or manipulate any technology incorporated in receivers compatible with the XM Satellite Radio system. Furthermore, the AMBE® voice compression software included in this product is protected by intellectual property rights including patent rights, copyrights, and trade secrets of Digital Voice Systems, Inc.

  • Page 112: Warranty

    In these cases, repairs will be made on the basis of the retail value of the parts and labor. To return for repairs, the unit must be shipped to Russound at the owner's expense, along with a note explaining the nature of service required. Be sure to pack the unit in a corrugated container with at least three (3) inches of resilient material to protect the unit from damage in transit.
  • Page 113 NOTES...
  • Page 114 NOTES...
  • Page 115 NOTES...
  • Page 116 Russound 5 Forbes Road, Newmarket, NH 03857 28-0112 10/07/04 tel 603.659.5170 • fax 603.659.5388 e-mail: tech@russound.com Copyright © 2004 Russound ® . All rights reserved. www.russound.com...
