BYK micro-gloss Operation Manuals

Measure what you see.
micro-gloss

Operation

operate
Main menu
Mode
Geometry/Sensor
Memory
Difference
Calibration
Setup
BYK-Gardner GmbH · Lausitzer Strasse 8 · 82538 Geretsried · Germany · Tel. +49-8171-3493-0 · Fax +49-8171-3493-140 · www.byk.com/instruments
A member of
mode wheel:
• Switch on
• Show menu
• Select function
• Activate function
operate-button:
• Measure
Navigation Symbols:
¢
¢ Back to previous menu
}
} Got to sub-menu
}
3 Function activated
}
* Guide to language menu
}
}
*}

How to calibrate?

Gloss

press
press
Autodiagnosis
scroll
press
Please clean standard
Confirm ¢ [mode]
Cancel ¢ [operate]
Thickness (only micro-TRI-gloss μ)
Main menu
Calibration
Calibrate
Thickness Fe
Thickness NFe
*It is advisable, to perform the zero calibration on the uncoated
metal of the sample to be tested.
• Turn on the unit in holder
• Autodiagnosis checks standard
and calibration
• If requested, clean the standard
and start calibration by pressing
the mode wheel
• Select the desired sensor
(Fe or NFe)
}
• Put the unit on the zero
standard or original substrate*
}
• Press operate button
}
• Hold the unit free in air and
press operate
}
