AXi-CANBOX1 INSTALLATION MANUAL
PLEASE REVIEW THIS INSTALLATION MANUAL
CAREFULLY BEFORE BEGINNING ANY WORK
COMPATIBLE PLUG & PLAY WIRING HARNESSES
AXi-JAGVIM-C
AXi-GIG-C
AXi-GIGCAM-C
AXi-GIG-AV-C
AXi-GIG-CAMAV-C
AXi-QUAD-C
AXi-QUAD1-CAM-C
AXi-QUAD1-AV-C
AXi-RRVIM-C
AXi-SYNC-C
AXi-SYNCAM10-C
AXi-SYNCAM12-C
AXi-UCT22-C
AXi-UCT22-CAM-C
AXi-UNI-C
AXi-UNI-CAM-C

Advertisement

loading
Need help?

Need help?

Do you have a question about the AXi-CANBOX1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Axxess AXi-CANBOX1

  • Page 1 AXi-CANBOX1 INSTALLATION MANUAL PLEASE REVIEW THIS INSTALLATION MANUAL CAREFULLY BEFORE BEGINNING ANY WORK COMPATIBLE PLUG & PLAY WIRING HARNESSES AXi-JAGVIM-C AXi-GIG-C AXi-GIGCAM-C AXi-GIG-AV-C AXi-GIG-CAMAV-C AXi-QUAD-C AXi-QUAD1-CAM-C AXi-QUAD1-AV-C AXi-RRVIM-C AXi-SYNC-C AXi-SYNCAM10-C AXi-SYNCAM12-C AXi-UCT22-C AXi-UCT22-CAM-C AXi-UNI-C AXi-UNI-CAM-C...
  • Page 2: Table Of Contents

    Table Of Contents ………………………………….………. PRECAUTIONS.……………………………………..…...3 WIRING LEGEND AND DESCRIPTION…………4-5 ASSIGNMENT OF SWITCHES…………….………….6 FEATURE PROGRAMMING…….……….………...7-8 DEVICE SETTINGS MENU…..…………………..…...9 FAQ………………………………………………..…….10 QUICK START GUIDE ………………………...…11-12 IMPORTANT WARNING This product includes instructions for installation which must be carefully followed. The instructions are worded in such a manner to assume that the installer is capable of completing these type of electronic installations.
  • Page 3: Precautions

    Using protective blankets to cover front seats, interior of the vehicle and center console.  Always install a fuse 6-12 inches away from AXXESS.i interface, 5 amp fuse should be used.  Always secure AXXESS.i interface with Velcro or double side tape to prevent rattling of the interface.
  • Page 4: Wiring Legend And Description

    Must connect to constant power source, can usually be found at the main power plug on the back of the radio or at another source where AXi-CANBOX1 is installed. Do not connect to accessory or ignition power source. Connecting to +12V constant power will not drain battery, interface goes into sleep mode after key is removed and doors are locked.
  • Page 5: Wiring Legend And Description

    Wiring legend and description Additional connections when AXi-CANBOX1 is installed with AXi-UNI-CAM-C camera harnesses. Connections in addition to wires shown on page 4. Camera Input 1: Factory or aftermarket camera input. Camera Input 2: Front camera input. Camera Input 3: Left camera input.
  • Page 6: Assignment Of Switches

    ON positing this information will be available in AXi harness installation manual. For most installations fig.2 and fig.3 shows correct switch position. To access switches remove cover by removing two screws in each corner of AXi-CANBOX1 fig.2 ON CTS fig.3...
  • Page 7: Feature Programming

    After installation is complete go to your start menu locate folder with AXXESS.i online updater and run the program. We have built in AXXESS.i Team Viewer feature and live chat for tech support in case you have any question during update and require immediate support.
  • Page 8 Connect AXi-CANBOX1 to your PC with micro USB cable. (cable not supplied must be purchased separately) Step One: Select make model year or click search to show all vehicles. Step Two: select vehicle software for installation. Step Three: Click install.
  • Page 9: Device Settings Menu

    Right Camera-Place check mark if installing right side view camera. Video-In-Motion-Place check mark to enable video-in-motion feature. Refer to vehicle specific installation manual for camera operations and controls. If any changes are made, press ACCEPT button and all settings will register to the AXi-CANBOX1.
  • Page 10: Faq

    Q: I shift vehicle in reverse gear I get a blank screen but no camera image on the screen? A: In all installation cases of AXi-CANBOX1 camera input is already present in a vehicle from factory, AXi-CANBOX1 only activates this input. If blank screen is displayed when vehicle in reverse, check camera RCA and power connection.
  • Page 11: Quick Start Guide

    DISCLAIMER: WARNING!!! WARNING!!! AXXESS.i is designed to be used only when the vehicle is immobilized. The driver is responsible for maintaining full attention while operating a motor vehicle. The removal or bypassing of safety features in AXXESS.i products will result in termination of warranty.
