Snapmaker 3-in-1 3D Printer Quick Start Manual page 14

3-in-1 3D Printer Quick Start Guide
Assemble the 3D Printer
RJ45 Cable
x 1
RJ25 Cable
x 1
Power Adapter
x 1
The RJ25 Cable (Heated
Bed Cable) is comparatively
smaller than the RJ45 Cable
(Module Cable).
10
Connect the Modules to the Controller and Power On
1(RJ 45)
3
1
Power
2
3
5
6
Screen
6
(RJ 25)
5
2
!
Caution
Make sure all the cables are
correctly and properly connected
before you power on the machine.
Do NOT connect or disconnect the
cables or microSD card when the
machine is powered on.
Page 15
