CCT455/7/9 Varifocal CCTV Dome Camera INSTRUCTIONS
Varifocal Auto Iris CCD Dome Camera

Introduction

Each of the Varifocal dome has been engineered from a solid piece of
aluminium to produce a truly exceptional product.
With the domes stunning looks and great functionality you shouldn' t loose
many jobs
The beauty of this product is not just on the outside, the dome comes equipped
with a Varifocal lens that allows you to get the picture that your customer was
expecting when you are installing. It also has an auto iris lens, so when looking
at a doorway the camera will compensate for any bright sunlight.
The domes' stunning looks means that they look the part in any environment.
Installed in a shop, office, bank, school or an industrial unit the domes look and
perform great.
The Varifocal lens means that the cameras can be adjusted for a wide angle of
view or a narrow angle distance shot so they can capture the exact scene your
customer wants without you having to worry about what lens to order.
As the lens is auto-iris it can accommodate a wide range of lighting conditions improving the cameras performance in
low light whilst also coping with bright sunlight or shop lights effortlessly.
The cameras electronics have been designed around the latest semiconductor technology and circuit design to ensure
that all three variants of the camera produce an excellent picture quality to match the cameras stunning looks.

Models Covered in these instructions

CCT455 Hi-Res B&W Dome with Vari-focal Lens
CCT457 Med-Res Colour Dome with Vari-focal Lens
CCT459 Hi-Res Colour Dome with Vari-focal Lens

Camera Specifications

Camera Spec
Image Sensor
Image Output
Resolution
Min Illumination
Input Voltage Range
Power Consumption
Lens
AGC
Iris Control
Size, Dia x H

Mounting the Camera

The dome cameras are supplied with a fixing plate and drilling template that allow to fix your dome
camera (using the screws supplied) to wood or brick with wall plugs (not supplied) or to
plasterboard / suspended ceilings with bolts and fixing plate (supplied).

Powering the Camera

The dome cameras are dual voltage i.e. you can use them on a 12V DC system or a 24V AC system. The camera has
built in power supply control circuit for ease of connection; this means that you can connect to any 12VDC or 24VAC
system without worrying about polarity or voltage regulation.
The camera is provided with a screw terminal on a fly lead that allows you to connect the power supply to it.
System Q E-mail support@systemq.com or fax support 01246 222 888
Hi-Res B&W
1/3" B&W
1V 75Ω
pk-pk
600TVL min
0.03 Lux
12V DC / 24V AC
200/100 mA
4-9mm Vari-focal
Automatic
Auto Iris
110mm dia x 80mm H
SIDE A - 24/01/05
Med-Res Colour
1/3" Col. Sharp
1V 75Ω
pk-pk
380TVL min
0.5 Lux
12V DC / 24V AC
200/100 mA
4-9mm Vari-focal
Automatic
Auto Iris
110mm dia x 80mm H
Doc XCCT455
Hi-Res Colour
1/3" Col. SONY Ex View
1V 75Ω
pk-pk
480TVL min
0.25 Lux
12V DC / 24V AC
200/100 mA
4-9mm Vari-focal
Automatic
Auto Iris
110mm dia x 80mm H
