PanoVu PT Series Target Capture Camera·Quick Start Guide
PanoVu PT Series
Target Capture Camera
Quick Start Guide
i

Advertisement

Table of Contents
loading

Related Manuals for HIKVISION PanoVu PT Series

Summary of Contents for HIKVISION PanoVu PT Series

  • Page 1 PanoVu PT Series Target Capture Camera·Quick Start Guide PanoVu PT Series Target Capture Camera Quick Start Guide...
  • Page 2 Manual. About this Manual This Manual is applicable to PanoVu PT Series Target Capture Camera. The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only.
  • Page 3 PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS;...
  • Page 4 PanoVu PT Series Target Capture Camera·Quick Start Guide APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES. IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS.

  • Page 5: Regulatory Information

    PanoVu PT Series Target Capture Camera·Quick Start Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 6 PanoVu PT Series Target Capture Camera·Quick Start Guide 2015/35/EU, the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU. 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.

  • Page 7: Safety Instruction

    PanoVu PT Series Target Capture Camera·Quick Start Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 8 PanoVu PT Series Target Capture Camera·Quick Start Guide  Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard.  Make sure that the plug is firmly connected to the power socket.
  • Page 9 PanoVu PT Series Target Capture Camera·Quick Start Guide  Do not touch senor modules with fingers. If cleaning is necessary, use clean cloth with a bit of ethanol and wipe it gently. If the camera will not be used for an extended period, replace the lens cap to protect the sensor from dirt.

  • Page 10: Table Of Contents

    PanoVu PT Series Target Capture Camera·Quick Start Guide Table of Contents 1 Overview ..................1 1.1 Appearance ................1 1.2 Cable Descriptions ..............1 1.3 Alarm Output................2 2 Installation ..................3 2.1 Installing the Memory Card ............4 2.2 Installing the Hold Hoop ............4 2.3 Installing the Camera ..............

  • Page 11: Overview

    PanoVu PT Series Target Capture Camera·Quick Start Guide 1 Overview 1.1 Appearance Appearance of the camera is shown in 错误!未找到引用源。. Figure 1-1 Appearance 1.2 Cable Descriptions Cable interfaces of the camera are shown in Figure 1-2. The cables are distinguished by different colors. Refer to the labels attached on the cables for identification.

  • Page 12: Alarm Output

    PanoVu PT Series Target Capture Camera·Quick Start Guide Network Cable Alarm Cable Audio Cable Power Cord (12 VDC) Figure 1-2 Cables of Camera 1.3 Alarm Output Alarm output is shown in Figure 1-3. Output DC 30V JQC-3FG Relay Power Supply...

  • Page 13: Installation

    PanoVu PT Series Target Capture Camera·Quick Start Guide 2 Installation Before you start: Check the package contents and make sure that the device in the package is in good condition and all the assembly parts are included. Notes:  Do not power up the camera until the installation is finished. To ensure the safety of personnel and equipment, all the installation steps should be done with power supply off.

  • Page 14: Installing The Memory Card

    PanoVu PT Series Target Capture Camera·Quick Start Guide 2.1 Installing the Memory Card You can install the memory card for local storage. Note: If you need to insert or pull out the memory card, make sure the power is off.
  • Page 15 PanoVu PT Series Target Capture Camera·Quick Start Guide Steps: 1. Open three hold hoops. 2. Encircle the hold hoops around the cross-bar, and tighten the hold hoops as shown in Figure 2-3. Figure 2-3 Tighten the Hold Hoops Note: You can install the camera to the hold hoop with the certain mounting bracket, such as the wall mounting bracket or the base mounting bracket, as shown in Figure 2-4.

  • Page 16: Installing The Camera

    PanoVu PT Series Target Capture Camera·Quick Start Guide 2.3 Installing the Camera 2.3.1 Wall Mounting Before you start: Make sure the camera is power-off before you install the camera. And you need to prepare the wall mounting bracket first. Notes: ...
  • Page 17 PanoVu PT Series Target Capture Camera·Quick Start Guide Figure 2-5 Fix the Base Plate 2. Fix the bracket hanger to the camera with four 1/4 UNC screws as shown in Figure 2-6. Bracket Hanger ¼ UNC Screw Figure 2-6 Fix the Bracket Hanger 3.
  • Page 18 PanoVu PT Series Target Capture Camera·Quick Start Guide M6*16 Screw M6*16 Screw Figure 2-7 Install the Camera to the Bracket 2). Route the cables through the water-proof plug, and place the cables in the bracket junction box as shown in Figure 2-8.
  • Page 19 PanoVu PT Series Target Capture Camera·Quick Start Guide 4. Connect the cables. 1). Hang the safety rope of the bracket to the safety hook on the base plate as shown in Figure 2-9. Safety Hook Safety Rope Figure 2-9 Hang the Safety Rope 2).

  • Page 20: Pendant Mounting

    PanoVu PT Series Target Capture Camera·Quick Start Guide 6. Adjust the horizontal and vertical angels. 1). Unscrew the bottom screws (do not remove), and adjust the horizontal angel. 2). Unscrew the side screws (do not remove), and adjust the vertical angel.

  • Page 21: Base Mounting

    PanoVu PT Series Target Capture Camera·Quick Start Guide Fixing Screws of Junction Box Protective Film Horizontal Fixing Screws Side Screws Figure 2-11 Pendant Mounting 2.3.3 Base Mounting Before you start: Make sure the camera is power-off before you install the camera.
  • Page 22 PanoVu PT Series Target Capture Camera·Quick Start Guide 2. Push the base mounting bracket into the space of the bracket hanger, and fix the bracket with two M6*16 screws as shown in Figure 2-13. M6*16 Screw M6*16 Screw Figure 2-13 Install the Camera to the Bracket 3.
  • Page 23 PanoVu PT Series Target Capture Camera·Quick Start Guide Note: The steps of adjusting angles are similar to the angles adjusting steps in pendant mounting. Refer to section 2.3.2 Pendant Mounting for details. Horizontal Fixing Screw Side Screws Figure 2-15 Adjust the Angles...

  • Page 24: Setting The Camera Over The Lan

    PanoVu PT Series Target Capture Camera·Quick Start Guide 3 Setting the Camera over the LAN Notes:  You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, strengthen your own protection.

  • Page 25: Activating The Camera

    PanoVu PT Series Target Capture Camera·Quick Start Guide 网络交换机 Network Camera Computer Figure 3-2 Connecting via a Switch or a Router 3.2 Activating the Camera Purpose: You are required to activate the camera first by setting a strong password for it before you can use the camera.
  • Page 26 PanoVu PT Series Target Capture Camera·Quick Start Guide Notes:  The default IP address of the camera is 192.168.1.64.  The computer and the camera should belong to the same subnet.  For the camera enables the DHCP by default, you need to use the SADP software to search the IP address.

  • Page 27: Activation Via Sadp Software

    PanoVu PT Series Target Capture Camera·Quick Start Guide 3.2.2 Activation via SADP Software SADP software is used for detecting the online device, activating the device, and resetting the password. Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts.

  • Page 28: Modifying The Ip Address

    PanoVu PT Series Target Capture Camera·Quick Start Guide 3. Create a password and input the password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including at...
  • Page 29 PanoVu PT Series Target Capture Camera·Quick Start Guide For IP address modification via client software, refer to the user manual of client software. Steps: 1. Run the SADP software. 2. Select an active device. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the Enable DHCP checkbox.

  • Page 30: Accessing Via Web Browser

    PanoVu PT Series Target Capture Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version/Vista/Win7/Server 2003/Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024 × 768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari...
  • Page 31 PanoVu PT Series Target Capture Camera·Quick Start Guide 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the network camera. Follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.
  • Page 32 PanoVu PT Series Target Capture Camera·Quick Start Guide Note: For detailed instructions of further configuration, refer to the user manual of the network camera.
  • Page 33 PanoVu PT Series Target Capture Camera·Quick Start Guide UD07405B...
