Insignia NS-CAHBTEP01 Quick Setup Manual

NS-CAHBTEP01_15-1223_QSG_V0_EN.ai 12/23/2015 15:54:25PM
NS-CAHBTEP01
Bluetooth Earpods
Bluetooth Earpods
USB charging cable
Quick Setup Guide
1
RIGHT BACK
6
1 7
2
3
4
5
+
Press + to increase the volume.
1
Press + to Skip to Next Track.
MFB
Press to turn on your stereo headphones.
(Power/talk/Play/
If you receive a phone call, press to talk. Press
2
Pause/pairing)
to turm off your stereo headphones .
button
3 Indicator led Shows current status of the headphones.
-
Press - to decrease the volume.
Volume Down
4
Press - to Previous Track.
Previous Track
5 Cable clamp The Cable clamp on the collar.
Plug the micro USB connector into this port
6 Micro USB port
to charge your headphones.
7 Microphone Allows you to talk on the telephone.
Method of use
1. Place Headphone on the neck, insure the same of length of both sides.
2. Place clip on collar which could be keep the Headphone wouldn't be
drop.
3. Wear the earpods, at that time the controller will nature hang front of
right shoulder.
BT basic indication
Bluetooth Function Indication
Item Operation LED Indication
Power on Long press MFB more than 2s Blue LED on 1.5s
2
Power off Long press MFB more than 3s Red LED on 1.5s
2
Pairing Long press 2 MFB more than 4s Blue and red LED
mode on power off stage blinking alternant
Play/Pause Short press 2 MFB button /
LEFT
Volume Up
Short press 1 + / 4 - button
/
/Down
Long press +/ - button /
1 4
Incoming Blue LED blinking 3
/
call times until pick up
Short press 2 MFB when have
Answer call /
a calling
Long press MFB when have
2
Reject call /
a calling
Redial Double press MFB /
2
Reset Long press MFB button more All LED off then
2
device list than 10s in power off stage power off
Charging Indication
Charging Connected USB cable Red LED on
Full charging / Red LED off
Blue LED blinking fast
Low battery /
3 times at every 1min
Connect the charging cable to
Press and hold the
your stereo headphones
button for two/three
Micro USB port
6 , then plug
seconds . The LED blinks
the USB connector into your
blue (when turned on) or
desktop computer, notebook
red (when turned off), and
or Smartphone AC adapter.
The red LED stays on while the voice prompt says
your stereo headphones are
"Power on", or "Power off."
charging and turns off when
they are fully charged.
Tone
"power on"
"power off"
2 short beeps tone
/
2 high beeps tone
for max volume
2 low beeps tone
for min volume
/
Some ring tone
1 short beeps tone
1 long beeps tone
2 short beeps tone
/
/
/
"battery low" at
every 1 min
MFB
2
