Insignia NS-CAHBTOE01 Quick Setup Manual

QUICK SETUP GUIDE
Bluetooth
Over-the-ear
Headphones
NS-CAHBTOE01 / NS-CAHBTOE01-C
PACKAGE CONTENTS
• Bluetooth over-the-ear headphones
• USB charging cable
• 3.5 mm audio cable
• Quick Setup Guide
FIND YOUR USER GUIDE ONLINE!
Go to www.insigniaproducts.com, enter your model in the search
box, then press ENTER. Next to Features, click Support &
Downloads, then next to User Guide, click the language you want.
FEATURES
• Comfortable foam earpads
• Volume control
• Listen to music and talk on the phone wirelessly
• Music playback: 10 hours
• Echo cancellation and noise suppression
• Voice prompts and easy pairing
• High quality sound
Before using your new product, please read these instructions to prevent any damage.
# DESCRIPTION FUNCTION
Press + to increase the volume.
1 + Volume Up
2 (Power/Talk/ Press to turn on your stereo headphones.
Play/Pause/ If you receive a phone call, press to talk.
Pairing) button Press to pair your headphones with a
Bluetooth enabled device.
3 Press to skip to the previous track/fast
Next Track rewind.
Previous Track Press to skip to the next track/fast
forward.
Press – to decrease the volume.
4 – Volume Down
5 Indicator LED Shows current status of the headphones.
6 Microphone Allows you to talk on the telephone.
7 3.5 mm audio jack Connect one end of the included audio
cable to the headset' s audio jack and the
other end to the music devices headphone
jack
8 Micro USB port Plug the micro USB connector into this
port to charge your headphones.
BLUETOOTH BASIC INDICATION
Bluetooth function indication
ACTION OPERATION
Power on Press and hold more than two seconds
Power off Press and hold more than three seconds
Pairing mode Press and hold more than four seconds in power off mode
Play/Pause Press and release button
Press and release + / - button
Volume Up/Down
Previous Track/Next Track Press and release button
Fast Rewind/Fast Forward Press and hold button
Incoming call
Answer call Press and release when a call is incoming
Reject call Press and hold when a call is incoming
Redial Double press
Reset device list Long press button more than five seconds in power off mode
CHARGING YOUR STEREO HEADPHONES
• When the red indicator LED blinks three times every minute and the
voice prompt says "battery low", the battery is low. To charge the
battery, plug the charging cable into your computer and into the
microUSB port on your headphones. The red LED turns on to indicate
that the battery is charging and turns off when fully charged.
LED INDICATION
Blue LED lights for 1.5 seconds
Red LED lights for 1.5 seconds
Blue and red LED blinking alternately
Blue LED blinks three times every five seconds
when a call is received
Red LED flashes 10 times
USING WITH THE AUDIO CABLE
You can use your headset with non-Bluetooth enabled devices or on
airplanes (in which the use of Bluetooth may be restricted) by taking
advantage of the headset' s audio jack. Corded operation does not require
battery power for music listening. The microphone and the FullSound
digital sound enhancement will not work via the audio cable.
Note: Finish your call before connecting the audio jack, as this will switch off
battery power and cut an ongoing call.
SOUND
"power on"
"power off"
Two short beeps
Two high beeps for maximum volume
Ring tone
One long beep
Two long beeps
Two short beeps
USING YOUR STEREO HEADPHONES
Turning your stereo headphones on and off
1 Place the headphones on your head.
2 Press and hold the button more than two seconds. The LED
blinks blue (when turned on) or red (when turned off) and the
voice prompt says "Power on" or "Power off".
