QUICK SETUP GUIDE
Bluetooth Noise-Canceling
Headphones
NS-CAHBTEBNC-S
PACKAGE CONTENTS
• Bluetooth Noise-Canceling Headphones • USB charging cable • Audio cable
• Two additional pairs of earbuds in small and large sizes • Quick Setup Guide
FIND YOUR USER GUIDE ONLINE!
Go to www.insigniaproducts.com, enter your model in the search box, then press ENTER. Next to Features, click Support & Downloads,
then next to User Guide, click the language you want.
FEATURES
• Noise cancelling
• Ambient noise monitoring
• Volume control
• Listen to music or talk on the phone wirelessly
• Music playback: 8 hours
• Echo cancellation and noise suppression
• Voice prompts and easy pairing
• High quality sound
Before using your new product, please read these instructions to prevent any damage.
# DESCRIPTION FUNCTION
BLUETOOTH AND NOISE CANCELLING BASIC INDICATION
1 Indicator LED Shows current Bluetooth status of the headphones.
ACTION
2 Micro USB port Plug the micro USB connector into this port to charge your Power on
headphones.
Power off
Pairing mode
3 Volume Up / Press to increase the volume.
Next Track Press and hold for one second to skip to the next track.
Volume Up/Down
4 (Power/Talk / Press to turn on your stereo headphones.
Incoming call
Play / Pause / If you receive a phone call, press to talk.
Pairing) button Press to pair your headphones with a Bluetooth enabled device.
Answer call
5 Volume Down / Press to decrease the volume.
Reject call
Previous Track Press and hold for one second to skip to the previous track.
Redial
Reset device list
6 Retraction buttons Press to retract the cord.
7 Earbuds Allow the headphones to fit comfortably in your ear. Noise cancelling on
8 Microphone Allows you to talk on the telephone.
Noise cancelling off
9 Indicator LED Shows current noise cancelling status of the headphones.
Monitor on
Monitor off
10 Noise cancelling Cancel low frequency noise.
11 Monitor button Press to start ambient noise monitoring.
12 Monitor microphone
Pick up the ambient low frequency noise.
OPERATION LED INDICATION SOUND
Press and hold more than two seconds Blue LED lights for 1.5 seconds "power on"
Press and hold more than three seconds Red LED lights for 1.5 seconds "power off"
Press and hold more than four seconds in power off Blue and red LED blinking alternately Two short beeps
mode
Press and release / button Two high beeps for
maximum volume
Blue LED blinks three times every five seconds
Ring tone
when a call is received
Press and release when a call is incoming One long beep
Press and hold when a call is incoming Two long beeps
Double press Two short beeps
Red LED flashes 10 times
Long press more than five seconds in power off
mode
Green LED light on
Slide the noise cancelling switch to the noise cancelling
on position
Green LED turn down
Slide the noise cancelling switch to the noise cancelling
off position
Press and release to enter the monitor mode Green LED flashes one time per three seconds
Press and release to exit the monitor mode
Green LED light on
CHARGING YOUR STEREO HEADPHONES
• When the red indicator LED blinks three times every minute and the voice prompt says "battery low", the battery is low. To charge the battery,
plug the charging cable into your computer and into the microUSB port on your headphones. The red LED turns on to indicate that the battery is
charging and turns off when fully charged.
USING YOUR STEREO HEADPHONES
Turning your stereo headphones on and off
1 Place the headphones around your neck.
2 Press and hold more than two seconds. The LED blinks blue (when turned on) or red (when turned off) and the voice prompt says "Power
on" or "Power off".
PAIRING YOUR STEREO HEADPHONES
Notes:
• Range is 33 feet (10 meters)
• Supports easy pairing
• Prompts you by saying "Your device is connected, " when connected
• Supports a battery indicator icon on an iOS device
Pairing with a cell phone or MP3 player
1 With your stereo headphones turned off, press and hold for four seconds. The blue and red LEDs blink alternately.
2 On your phone or MP3 player, select INSIGNIA NS-CAHBTEBNC-S from the list of discovered devices, then enter the password 0000
(four zeros) (if required) to pair your headphones.
For more information on pairing Bluetooth devices to your cell phone or MP3 player, see the device' s documentation.
Note: After the headphones have been successfully paired with the cell phone or MP3 player, the headphones will automatically reconnect to the phone or MP3 player.
