Autofeed Technology

The Auto+50 has been designed to automatically shred up
to 50 sheets from the autofeed chamber and up to 5 sheets
through the manual feed slot. The autofeed mechanism has
been designed to handle paper fastened with staples and paper
clips and to only pull a few sheets of paper into the cutting
mechanism to minimize the risk of paper jams.

Operation

Unpack the product.
1
Plug the shredder in to a working outlet.
2
Ensure the ON/OFF switch on the back of the shredder is in
3
the "ON" position, which will illuminate the LED bulb shown
by the standby symbol (
To start shredding, move the slide switch to the Auto
4
position ( ) which sets the shredder into auto mode. You
are now ready to shred.
To load the shredder, simply lift the loading door catch (see
5
fig. 1) to open the loading door and insert documents. You
can open the door further to 90 degrees for easier access
if required. Load up to 50 sheets at a time into the feed
chamber. Do NOT fill above the 50 MAX level, this could
damage the shredder (see fig. 2).
The shredder will start the shredding cycle automatically
6
ONLY after closing the loading door (see fig 1). If there is
still paper in the autofeed tray after first attempt, open and
re-close feed door a second time.
If you only have up to 5 sheets to shred, you can use the
7
manual feed slot, provided the auto feed chamber is empty
(see fig. 3).
Bin or Loading Door Open Safety
Function
As a safety precaution, if the bin or loading door is opened
during shredding, the shredder will stop.
Rare Occasions of Jamming
In the unlikely event of the shredder jamming, the Stack
and Shred Auto+50 will stop shredding. Check that the bin
is not full then try clearing the jam using the reverse (
and continuous jam boost (
mode ( ). If this is unsuccessful follow the reverse function
instructions.
).
)
) switch then return to Auto

Reverse Function

If you want to reverse paper out while shredding, use the
1
reverse button ( ).
Reverse the paper out then turn the shredder off using the
2
ON/OFF switch at the rear of the shredder. Remove the
paper from the manual feed slot (if being used) or open the
loading door, remove the remaining stack of paper, then pull
the jammed paper free of the cutting mechanism.
To resume shredding return the slide switch to the auto
3
position ( ) and turn on the machine by using the ON/OFF
switch at the rear of the shredder.
Over Heating
If the The Auto+50 is used continuously for over 8 minutes the
shredder may overheat and the red cool down indicator will
illuminate underneath the thermometer symbol (
allow the shredder to cool down. When the shredder is ready
to be used the thermometer symbol will no longer illuminate. If
the shredder needs to cool down while shredding, no action is
needed. The shredder will automatically restart shredding paper
once it has cooled down after periods of continuous use. All you
need to do is ensure paper is loaded into the chamber and the
bin is empty when the machine is cooling down.
Credit Card Shredding
The Auto+50 can shred credit cards. Switch the shredder to
auto mode and insert the credit card between the markings in
the manual feed slot (see fig. 4). Only shred one credit card at
a time.
Rexel encourages customers to recycle shredded paper.
Please note that shredded paper cannot be recycled
if mixed with credit card shards. If recycling, please
separate shredded paper and credit cards.
Bin Full
Should the shredder stop shredding, the bin may be full. Check
first by looking through the viewing window and if full you
should empty the bin.
• Pull open the bin slowly to empty.
• Push the empty bin back into place and the machine will
resume shredding.
). Please
