Boyo VTM43FL User Manual

1 Introduc on
adjust the LCD brightness
Quick switch to the video image
2 Package
The packing box contains the following accessories. Please confirm:
● 4.3 inch frameless rear view mirror monitor
● Wire harness
● User's manual
● Wire cover
● Remote control
Please check your package box for the items listed above. Please contact
the distributor or the agent as soon as possible if there is any damage.
3 Features
● 4.3 inch LCD display screen
● 2-way video inputs
● Back-up camera display
● Automa c brightness adjustment
● 4.0 mm glass and φ 21 mm car factory OEM bracket
● Adjustable guide line
4 Specifica ons
● Screen size: 4.3 inch
● Display screen: TFT-LCD
● Aspect resolu on: 480(H)*272(V)
● Working voltage: 12V
● Working temperature: -20℃~+65℃
● Signal system: PAL/Auto/NTSC
● Brightness: about 1300cd/m2
7 Back up camera display
When the car is in reverse, the monitor will automa cally display back up
camera.
8 High reflec ve mirror
Clear back up view displayed on high reflec ve mirror.
Normal reflec ve mirror
9 Automa c brightness adjustment
When ambient light is strong,
When ambient light is weak,
the screen will automa cally
the screen will automa cally
increase the brightness and get
reduce the brightness and get
be er for watching.
be er for watching.
10 Adjustable Guide Line
10.1 About guide line
There are three lines (red, yellow, and green) to help drivers es mate the
distance from obstacles. Those three lines are displayed on the monitor
when the car is reversing. The green line is 10 feet away from the back of
the car, and the yellow line is 6.5 feet away. The red line is 3.3 feet away
from the back of the car, while the closed red line is 1.3 feet away. Please
note that there is 0.65 feet distance from the car for reference lines shown
below.
5 How to install mirror
5.1 Remove the original mirror
quick switch to rear view
Original rear view mirror
turn off the screen
Different cars have different brackets. It depends on your vehicle maker
and manufacturer.
There are many methods to remove the original rear view mirror. Howev-
er, please don't force the mirror off the bracket.
The manufacturer will not be responsible for any damage caused to your
car by inappropriate installa on of the mirror.
5.2 Install mirror monitor on the base
contrarotate the fixed
rear view mirror
10.2 What the regular guide line is
Regular guide lines are fixed although installa on sites of camera and car
size are different. The fixed guide line is not accurate enough for drivers.
There is huge difference between the regular, fixed guide lines, and real
guide lines of the car. It may cause accidents when camera is mounted on
the le or right side on the back side of the car.
10.3 How to adjust the guide line
According to the site of standard reference line, we can put reference
objects such as desks in the back side of the car. Compared with the
marked reference objects, we can adjust the sites and angles of two guide
lines are displayed on the monitor. You will get the accurate and safety
guide lines once it coincides with the reference objects.
Press se ng bu on
High reflec ve mirror
is defaulted to adjust le guide line first. Press the bu on again to switch to
adjust the right guide line.
The up
corresponding loca on of guide lines. The clockwise rota on
rota ng
operate and calibrate. A er finishing calibra on, switch the reverse gear to
save the informa on.
Note: keep the remote control 05.m-1.0m away from rear view mirror
when you use the remote to adjust the parking lines.
L
Press the bu on to choose L or R adjustable guide line.
Remote control
Adapter on the windshield
Install rear view mirror along Install rear view mirror along
this direc on. this direc on.
to enter "guide line adjustment" mode. The system
, down , le and right bu ons are to adjust the
bu ons are to adjust the angles of guide lines. It is easy to
Right posi on Wrong posi on
R
Display on the monitor
Clockwise
Up
Le
Right
Down
Move the guide line Rotate the guide line
6 How to wire
After the mirror is mounted, you need to run the cable along the roof
lining and down the pillar so you can connect to power and the rear view
camera.
3
6
5m cable
Red: camera power to reversing power
1
Rear view mirror monitor
5
Car camera extension cable
Caution!
3
and contra
An -clockwise
5
To back up camera
Video in
Red to ACC +12V
Green to back up light
Black to GND
7 8
9
Black to GND
3
5
3
Mirror monitor cable
7
9
7
9
8
Camera (not included)
please align the connectors at
each other, otherwise the
connector will be easy to break!
Connect
3
