Boyo VTM96M User Manual

Long press to access settings menu. Once in the settings menu:
Repeated long presses cycle through:
Brightness Contrast Saturation
Within each setting, repeated short presses will change the setting value.
Specification
Display
9.6-inch MIPI
Brightness / Contrast
600 cdm / 400:1
1280x320
Display Resolution
# of Camera Inputs 2 (AHD1 and AHD2)
Video Format CVBS, 720P, 1080P supported
1 (Reverse AHD2 Trigger)
Display Trigger
AHD1 / AHD2 (Rear View): Standard display
Display Views
AHD2 (Reverse View): In the reverse mode the portion of the camera image
shown is the low part to suit reversing operation. (Reverse trigger)
Current
350mA ( Working)
Operating Voltage
DC10 ~ 24V, Cam output: DC12V
Strap-on: Rubber Fastener
Mounting
Replacement mount: A1 types
Operating Temp. -13ºF ~ 158ºF
For technical support call 888-941-3060
Email info@VisionTechAmerica.com
Visit www.VisionTechAmerica.com
Vision Tech America, Inc.
1452 E. Valencia Dr.
Fullerton, CA 92831
Tint Guideline Reset
, 89mA ( Standby)
VTM96M
9.6 Inch Full Display Mirror Monitor
With Dual Mounting Options
(Replacement)
USER MANUAL
(Clip-On)
