- Page 1 Instruction Manual Dogeroo, Super Dogeroo, and Mini Dogeroo Model No. 8102EX, 8103EX, 8108EX 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA Part No. 87793EX...
-
Page 2: Safety Precautions
Dogeroo, Super Dogeroo and Mini Dogeroo Model No. 8102EX, 8103EX, 8108EX SAFETY PRECAUTIONS gmpopcorn.com Page 2... -
Page 3: Installation Instructions
Remove all packing material and tape. 2. If the optional sneeze guard has been purchased, place it over the corner posts. 3. Be sure to place your Dogeroo where the revolving hot dogs will attract the most attention. -
Page 4: Electrical Requirements
Failure to wire properly will void the warranty and may result in damage to the machine. It is Gold Medal Products Company’s recommendation that this machine be plugged directly into a wall outlet. The use of extension cords is not recommended due to safety concerns, and may cause sacrificed and/or reduced performance. -
Page 5: Controls And Their Functions
Dogeroo, Super Dogeroo and Mini Dogeroo Model No. 8102EX, 8103EX, 8108EX OPERATING INSTRUCTIONS Controls and Their Functions ON/OFF SWITCH Flipping the lever of this switch to the "ON" position will energize the drive motor which rotates the rotisserie. It also lights the bulb behind the front glass and completes the circuit to the heat control. -
Page 6: Operating Procedure
6. The time required to broil the hot dogs will vary, depending upon size and temperature (35-37° F refrigerated) of the hot dogs when placed in the Dogeroo. With the heat control set on "HI" and using average size hot dogs, it will take from 10-15 minutes to have the hot dogs ready for 145°... -
Page 7: Care And Cleaning
Good sanitation practice demands that all food preparation equipment be cleaned regularly. A clean looking, well-kept machine is one of the best ways of advertising your product. The Dogeroo, Super Dogeroo, and Mini Dogeroo have been designed to disassemble quickly, without the use of special tools, for easy cleaning. - Page 8 Dogeroo, Super Dogeroo and Mini Dogeroo Model No. 8102EX, 8103EX, 8108EX Care and Cleaning – Pan and Rotisserie Removal/Reassembly Lift Power Assembly from frame. Bun Warmer Condensate Pan and Basket Water Pan Removing/Reassembly of Pans Removing/Reassembly of Power Assembly Lift the left end of the rotisserie from the end support.
-
Page 9: Troubleshooting
REPLACING BROKEN GLASS If you accidentally break a panel of glass, it can be replaced very easily. Note: Gold Medal Products Co. does NOT ship glass. Obtain replacement glass from your local hardware store and always purchase double strength type glass. -
Page 10: Maintenance Instructions
Dogeroo, Super Dogeroo and Mini Dogeroo Model No. 8102EX, 8103EX, 8108EX MAINTENANCE INSTRUCTIONS DANGER Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury or death. Read the installation, Operating, and Maintenance Instructions thoroughly before installing or servicing this equipment. -
Page 11: Ordering Spare Parts
Dogeroo, Super Dogeroo and Mini Dogeroo Model No. 8102EX, 8103EX, 8108EX ORDERING SPARE PARTS 1. Identify the needed part by checking it against the photos, illustrations, and/or parts list. 2. When ordering, please include part number, part name, and quantity needed. - Page 12 Dogeroo, Super Dogeroo and Mini Dogeroo Model No. 8102EX, 8103EX, 8108EX Cabinet Exterior – Front View 3, 4 Part Number Item Part Description Qty. 8102EX 8103EX 8108EX DOME (Bun Warmer) 87685 87723 87823 RUBBER BUMPER/FOOT 87247 87247 87247 KNOB 47120...
- Page 13 Dogeroo, Super Dogeroo and Mini Dogeroo Model No. 8102EX, 8103EX, 8108EX Cabinet Exterior – Back View 2, 3 Pivot Pin seen on Underside View of Door Part Number Item Part Description Qty. 8102EX 8103EX 8108EX DOOR ASSEMBLY 87037 87121 87884...
- Page 14 Dogeroo, Super Dogeroo and Mini Dogeroo Model No. 8102EX, 8103EX, 8108EX Power/Control Unit and Rotisserie gmpopcorn.com Page 14...
- Page 15 Dogeroo, Super Dogeroo and Mini Dogeroo Model No. 8102EX, 8103EX, 8108EX Power/Control Unit and Rotisserie – Parts List Part Number Item Part Description Qty. 8102EX 8103EX 8108EX MOTOR AND ELEMENT SUPPORT 87668 87715 87815 HEAT REFLECTOR ASSEMBLY 87671 87717 87817...
- Page 16 Dogeroo, Super Dogeroo and Mini Dogeroo Model No. 8102EX, 8103EX, 8108EX Power/Control Unit - Interior Heat Control uses (2) Phillips Screws M4X5 4, 5 Part Number Item Part Description Qty. 8102EX 8103EX 8108EX INSULATOR TUBE 87039 87039 87039 8-32 SET SCREW...
- Page 17 Dogeroo, Super Dogeroo and Mini Dogeroo Model No. 8102EX, 8103EX, 8108EX Accessories Item Part Description Qty. Part No. 1 IN. DIAL THERMOMETER 8000 9 INCH PLASTIC TONGS 87092 gmpopcorn.com Page 17...
-
Page 18: Wiring Diagram
Dogeroo, Super Dogeroo and Mini Dogeroo Model No. 8102EX, 8103EX, 8108EX WIRING DIAGRAM Model No. 8102EX, 8103EX, 8108EX gmpopcorn.com Page 18... - Page 19 © 2013 – The text, descriptions, graphics, layout, and other material in this publication are the exclusive property of Gold Medal Products Co. and shall not be used, copied, reproduced, or published in any fashion, including website display, without its express written consent.
