AMC2 Extensions
AMC2-16IOE / -8IOE / -16IE
en
Installation Manual

Advertisement

   Related Manuals for Bosch AMC2-16IOE

   Summary of Contents for Bosch AMC2-16IOE

  • Page 1

    AMC2 Extensions AMC2-16IOE / -8IOE / -16IE Installation Manual...

  • Page 3: Table Of Contents

    Connecting Power Supply 4.7.1 Direct Power Supply 4.7.2 Power Supply via RS-485 Interface 4.7.3 Overview - Power supply/consumption RS-485 for extension modules 4.8.1 Addressing Connecting Relay Outputs 4.10 Connecting Analog Input Devices 4.11 Tamper Protection Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |...

  • Page 4

    | Table of Contents AMC2 Extensions Operating Status Display of the AMC2 Technical Data Appendices Connecting Diagrams Index 2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH...

  • Page 5: Safety Instructions

    If the unit has been exposed to water and/or inclement weather (rain, snow, etc.). – If the unit does not operate normally when following the operating instructions. Adjust only those controls specified in the operating instructions. Improper Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |...

  • Page 6

    10. Lightning - For added protection during electrical storms external lightning conductors can be installed. This prevents power surges from damaging the unit. 11. The units should be installed in locations with restricted access. 2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH...

  • Page 7: Safety Precautions

    Ideally, use a magnetic lock. Install a normally-closed break glass or a manual pull (B) in the lock supply wiring, so that in an emergency the fail-safe lock can be immediately powered down. Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |...

  • Page 8

    0°C to 50°C. Disposal Your Bosch product is designed and manufactured with high- quality materials and components which can be recycled and reused. 2016-11 | AMC2-16IOE |...

  • Page 9: Unpacking

    If any parts are missing, inform your customer service representative or a Bosch Security Systems salesperson. The shipping carton is the safest transport container for the unit. Store it and the other packaging material for future use. If the unit has to be sent back, use the original packaging.

  • Page 10: Important Information

    Bosch Security Systems retains all rights not expressly granted. Nothing in this license constitutes a waiver of Bosch’s rights under the U.S. Copyright laws or any other federal or state law. If you have any questions concerning this license, please, write...

  • Page 11: Internet

    Tips and shortcuts may also be included in such notes. Internet If you are interested in further information on this product or information on other products, please consult our website at http://www.boschsecurity.com. Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |...

  • Page 12: Introduction

    Introduction Description 3.1.1 Extension AMC2-16IOE The extension board AMC2-16IOE can be used with an AMC2 controller. It serves additional inputs and outputs. Figure 3.1: The extension board AMC2-16IOE The AMC2 has eight analog input devices and eight relay outputs. With its analog input devices, the AMC2 verifies, for example, if a lock is closed or open.

  • Page 13: Extension Amc2-8ioe

    AMC2 Extensions Introduction | en Notice! An AMC2-16IOE provides signals only to the AMC2 to which it is connected. Signal transfer to another AMC2 is not possible. Notice! Depending on the software system up to 3 extension modules can be connected at random.

  • Page 14: Extension Amc2-16ie

    | Introduction AMC2 Extensions Notice! The AMC2-8IOE is identical in all respects to the AMC2-16IOE except in the number of inputs and outputs. Information in this manual refers to all three extensions described here, unless explicitly stated otherwise. 3.1.3...

  • Page 15: Equipment Configuration

    AMC2 Extensions Introduction | en Notice! The AMC2-16IE is identical in all respects to the AMC2-16IOE except in missing outputs. Information in this manual refers to all three extensions described here, unless explicitly stated otherwise. Equipment Configuration Figure 3.4: Overview - Interfaces...

  • Page 16: Performance Characteristics

    (dry mode) – powered by internal power supply (wet mode) – 16 analog inputs with internal power supply – Transfer rate to the extension interface: 9,6 kBit/s 2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH...

  • Page 17: System Overview

    If an external power supply is used, this should also guarantee an uninterruptable power supply (UPS). Example: Bosch power supply APS-PSU-60 (F.01U.282.970). System Overview The extension module AMC2-16IOE is connected to the Access controller AMC2. By default it is connected via RS-485. Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |...

  • Page 18

    The minimum configuration consists of: – one PC with system software, – one AMC2 controller, – one AMC power supply, – one AMC enclosure. – The maximum configuration depends on the system software, 2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH...

  • Page 19: Installing

    The AMC2-16IOE can be attached on a standard 35 mm (1.377 in.) mounting rail using a snap-in mechanism. Attach the AMC2-16IOE into the upper edge of the mounting rail [1], then push down the device and snap it onto the rail by pushing it towards the back [2].

  • Page 20: Unmounting

    To remove the AMC2-16IOE from a mounting rail, first remove all pluggable connectors. Push down the AMC2-16IOE until the lower edge snaps out of the mounting rail [1]. Pull the lower end of the AMC2-16IOE from the mounting rail [2].

  • Page 21: Opening The Case

    To open the AMC2-16IOE, first remove all pluggable connectors. The AMC2-16IOE case consists of a top cover mounted with a two-point snap-in closure on a chassis. To open the case, push down the two snap-ins with a screwdriver, then swing the cover down.

  • Page 22: Closing The Case

    Insert the hooks on the lower edge of the front cover into the lugs on lower edge of the plastic back cover [1]. Please ensure that the BOSCH logo is not upside-down. The upper edge of the front cover now aligns with the two-point snap-in closures on the upper edge of the back cover [2], and may thus be clicked gently into place.

  • Page 23: Cabling

    Cabling Notice! Risk of malfunction The cables used in the AMC2-16IOE access control system are not prone to electrical interference. However, you should avoid routing cables close to heavy load switching cables and equipment. If this is unavoidable, cross the cable at right angles every 1 to 2 m (3 to 6 ft) to reduce interference.

  • Page 24

    Critical condition! Install the power supply closer to the controller. Notice! These specifications apply to power supply, readers, relay outputs, and extension interface. Regarding inputs, specific voltage-drop values need to be taken into account. Refer to Connecting Analog Input Devices, page 2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH...

  • Page 25: Grounding And Shielding

    If the AMC2-16IOE has its own power - as in the third example in Overview - Power supply/consumption, page 29 - the shield will be connected to pin 2 of the power supply connector - see Connecting Diagrams, page 48.

  • Page 26: Grounding For Extension Interface

    Jumper connects the internal ground of the AMC2-16IOE to the ground of the RS-485 slave interface. Set Jumper A2 only at the first AMC2-16IOE of a party line - like example four in Overview - Power supply/consumption, page 29. 2016-11 | AMC2-16IOE |...

  • Page 27: Connecting Power Supply

    Refer to Connecting Diagrams, page 48 for a complete diagram. Figure 4.6: Location of the power supply connector Connect an external power supply (10 - 30 Vdc) for AMC2-16IOE at pin 1 (positive) and pin 3 (0 V) of the pluggable screw connector.

  • Page 28: Power Supply Via Rs-485 Interface

    The power can also be supplied by the AMC2-4W. In this case power pins 1 and 2 should be connected, as well as data lines on pins 3 - 6. Figure 4.7: Interface for internal power supply 2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH...

  • Page 29: Overview - Power Supply/consumption

    AMC2 Extensions Installing | en 4.7.3 Overview - Power supply/consumption Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |...

  • Page 30

    Extensions the values decrease PS + AMC2 60VA 55VA 25VA PS + 2 x 60VA 50VA 20VA Extension PS + AMC2 60VA 55VA 25VA PS + 3 x 60VA 45VA 15VA Extension 2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH...

  • Page 31

    AMC2 itself . This leaves 55VA to support external devices. 25VA of these 55VA can be used for constant load (e.g. a card reader) leaving 30VA for occasional peak usage (e.g. a door opener). Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |...

  • Page 32: Rs-485 For Extension Modules

    | Installing AMC2 Extensions RS-485 for extension modules The AMC2-16IOE is connected to the AMC2 controller using the RS-485 extension interface. This interface will also be used to connect further extension modules. Figure 4.9: Location of the RS-485 extension module bus Figure 4.10: Connection of an extension module to an AMC2...

  • Page 33: Addressing

    Table 4.2: Signals numbering Connecting Relay Outputs To operate locks or alarm systems, the AMC2-16IOE has 16 form C relay outputs. The outputs will be connected to the 3-pin pluggable screw connectors S6 - 9, S14 - 17, S24 - 27, and S32 - 35 - refer to Connecting Diagrams, page 48.

  • Page 34

    AMC2 Extensions Figure 4.11: Location of the relay output connectors Each relay output can operate in ‘wet’ mode, using the AMC2-16IOE's internal 12/24 Vdc power supply for external devices or ‘dry’ mode with potential free contacts for externally powered systems.

  • Page 35

    – inductive loads have to be short circuited using recovery diodes, see image below. These diodes (1N4004) are supplied with every AMC2-16IOE package. – If you need higher voltage for special applications you can connect external relays to the outputs. Recommended,...

  • Page 36

    Notice! Risk of damage to equipment Do not connect externally powered devices in wet mode. This can damage the AMC2-16IOE. 2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH...

  • Page 37

    Installing | en Each relay output has a separate jumper setting on the underside of the circuit board to select dry (B 1) or wet (B 2) mode. Figure 4.14: Location of relay output jumpers Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |...

  • Page 38: Connecting Analog Input Devices

    AMC2 Extensions 4.10 Connecting Analog Input Devices The AMC2-16IOE has 16 analog inputs, for example, for potential-free lock mechanisms, or to detect whether a lock is closed or open. The inputs will be connected to the 2-pin pluggable screw connectors: S2 - 5, S10 - 13, S20 - 23, and S28 - 31 - refer to Connecting Diagrams, page 48.

  • Page 39

    AMC2 Extensions Installing | en The AMC2-16IOE can also detect the wiring conditions ‘short circuit’ and ‘broken’, and hence trigger an alarm if the appropriate devices are connected. 1. Door open: R 2. Door closed: R 3. Open wire: R = ∞...

  • Page 40

    1800 1900 Table 4.3: Maximum values of cable resistance per used resistor combination in Ohm Notice! We recommend using serial resistors (R ) no higher than 5K6 in order to obtain clear measurements. 2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH...

  • Page 41: Tamper Protection

    AMC2 Extensions Installing | en 4.11 Tamper Protection To protect the AMC2-16IOE against unauthorized access and so prevent tampering with sensitive data, the AMC2-16IOE provides an additional interface to connect external tamper contacts. This interface is a potential-free 2-pin pluggable screw connector marked with T.

  • Page 42: Operating

    AMC2 Extensions Operating Status Display of the AMC2 Because the AMC2-16IOE has no display of its own, the AMC2 controller displays status information about the input and output settings of the AMC2 extension boards. The selected display mode remains set until the next time the button is pressed.

  • Page 43

    Host activity: + = online - = offline "C" = Counter of the received data packages from the host interface. RS 485 Bus connection: A = Address 1 … H = Address 8 Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |...

  • Page 44: Technical Data

    AMC: 5 VA Peripheral devices: using the PSU-60 – up to 55 VA – constant load: 25 VA Connectors Pluggable screw connectors Protection class IP30 Environment temperature 0° C to 50°C (32° F to 122°F) 2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH...

  • Page 45

    (W/H/D) 232 x 90 x 46mm (8.9 x 3.5 x 1.8 in) Weight approx. 0.4kg (0.9lb) Notice! The voltage drop from the power supply to the AMC2-16IOE affects the AMC interfaces. The total drop must not exceed 2V! Notice! To determine the environmental impact of an installation, take into account the most extreme values of all participating devices.

  • Page 46

    | Technical Data AMC2 Extensions 2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH...

  • Page 47

    AMC2 Extensions Technical Data | en Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |...

  • Page 48: Appendices

    | Appendices AMC2 Extensions Appendices Connecting Diagrams Figure 7.1: Connector blocks of the AMC2-16IOE 2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH...

  • Page 49

    AMC2 Extensions Appendices | en Figure 7.2: Connector blocks of the AMC2-8IOE Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |...

  • Page 50

    Power supply, DC positive (10V - 30V) Shield Power supply (0V) UPS (power good signal) - AC UPS (power good signal) - Battery UPS (power good signal) - DC UPS (power good signal) - Common Table 7.1: Power supply 2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH...

  • Page 51

    Power supply for external devices (10V - 30V) Power supply for external devices (0V) Shield Data RxTx+ Data RxTx- Ground (PAG) Table 7.4: Host / Extension interface Tamper Contact, in Tamper Contact, out Table 7.5: External tamper contact Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |...

  • Page 52: Index

    Dauerlast, 30 description 16 I/O-board, 12 resistor, 39 16 I-board, 14 8 I/O-board, 13 system overview, 17 extension interface, 44 tamper, 41 inputs, 15, 16, 38 unmounting, 20 interfaces extension, 44 mounting, 19 2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH...

  • Page 54

    Bosch Sicherheitssysteme GmbH Robert-Bosch-Ring 5 85630 Grasbrunn Germany www.boschsecurity.com © Bosch Sicherheitssysteme GmbH, 2016...
