- Page 1 AMC2 Modular Controller AMC2‑16ION Installation Manual...
- Page 3 Tamper Protection Operating Status Display of the AMC2 Configuring the Ethernet Interface Troubleshooting 5.3.1 Resetting the Software 5.3.2 Resetting the Device to Factory Default Technical Data Appendices Connecting Diagrams Index Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 4 10. Lightning - For added protection during electrical storms external lightning conductors can be installed. This prevents power surges from damaging the unit. 11. The units should be installed in locations with restricted access. 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 5 0°C to 50°C. Disposal Your Bosch product is designed and manufactured with high-quality materials and components which can be recycled and reused. This symbol means that electrical and electronic equipment, at their end-of-life, should be disposed of separately from your household waste.
- Page 6 Do not attempt to put the unit into operation if components are damaged. If any parts are missing, inform your customer service representative or a Bosch Security Systems salesperson. The shipping carton is the safest transport container for the unit. Store it and the other packaging material for future use.
- Page 7 Bosch Security Systems retains all rights not expressly granted. Nothing in this license constitutes a waiver of Bosch’s rights under the U.S. Copyright laws or any other federal or state law. If you have any questions concerning this license, please, write to:...
- Page 8 AMC2 Modular Controller Introduction Description The AMC2-16ION board provides inputs and outputs to control doors and other components independent of access control system. Figure 3.1: The IO-Controller AMC2-16ION The AMC2-4R4 standalone board (hereafter also referred as AMC2 or controller) are deployed via a dedicated OPC-Server.
- Page 9 Connector for power supply Connectors for eight analog inputs Connectors for eight relay outputs Notice! All connectors, with the exception of the RS-232 and Ethernet host interface, are pluggable screw clamp terminals. Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 10 Jumper: Equalization of potential between different systems and earth ground (shield) for the extension interface. Notice! For details on the setting of the jumpers and DIL switches listed here, please see DIL switch selector, page 26. 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 11 Tamper contact for external covers Notice! If an external power supply is used, this should also guarantee an uninterruptable power supply (UPS). Example: Bosch power supply APS-PSU-60 (F.01U.282.970). System Overview The AMC2-4R4 is deployed as an independent controller between the management host system and various peripheral devices.
- Page 12 The minimum configuration consists of: – one PC with system software, – one AMC2 controller, – one AMC power supply, – one AMC enclosure. – The maximum configuration depends on the system software, 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 13 Attach the AMC2-4R4 into the upper edge of the mounting rail [1], then push down the device and snap it onto the rail by pushing it towards the back [2]. Figure 4.1: Mounting the AMC2 on a mounting rail Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 14 Push down the AMC2-4R4 until the lower edge snaps out of the mounting rail [1]. Pull the lower end of the AMC2-4R4 from the mounting rail [2]. Figure 4.2: Unmounting the AMC2 from a mounting rail 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 15 The AMC2-4R4 case consists of a top cover mounted with a two-point snap-in closure on a chassis. To open the case, push down the two snap-ins with a screwdriver, then swing the cover down. Figure 4.3: Opening the AMC2-16ION case Bosch Access Systems GmbH Installation Manual...
- Page 16 [1]. Please ensure that the BOSCH logo is not upside-down. The upper edge of the front cover now aligns with the two-point snap-in closures on the upper edge of the back cover [2], and may thus be clicked gently into place.
- Page 17 These specifications apply to power supply, readers, relay outputs, and extension interface. Regarding inputs, specific voltage-drop values need to be taken into account. Refer to Connecting Analog Input Devices, page 32. Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 18 Settings for jumper JP2: If the ground conductor and the shield on the host are not connected and ... – no party line exists, the jumper 2 is set (= A3) 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 19 Jumper B connects the internal ground of the AMC2-4R4 to the RS-485 ground of the slave interface. Only set jumper B (B2) if the AMC2-4R4 powers all other peripheral devices directly connected to it. Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 20 4 and 7 for power good AC – pin 5 and 7 for power good Battery – pin 6 and 7 for power good DC Otherwise these pins must be short-circuited. 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 21 AMC2 device is recognized by the remote server. You can accelerate this process by running the following command: ipconfig /flushdns This makes the AMC2 device immediately available by its name. Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 22 An RS-485 host system can consist of up to eight AMC2 controllers connected using 2- or 4- wire connection. Figure 4.9: Configuration of a RS-485 host system Host RS-232 connection RS-232 / RS-485 converter RS-485 bus AMC2 controller 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 23 RS-485 host interface. The setting of the AMC2-4R4 must correspond with the settings of the RS-232 / RS-485 converter. Figure 4.10: RS-485 host interface 4.9.1 RS-485 Two Wire Connection Figure 4.11: Setting of the jumpers for RS-485 two wire connections Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 24 Figure 4.12: Settings for RS-485 four wire connection Notice! See the notices for setting the RS-232 / RS-485 converter. Notice! If a four-wire connection is used the interface must be set up as a crosslink. 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 25 As the AMC2 controller is conceptionally a PC, it is not possible to connect them directly using normal cables. Use instead a null modem or “crossover” cable. A complete connection diagram of the RS-232 host interface is shown in chapter Connecting Diagrams, page 42 Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 26 – Ethernet host connection – RS-485 host connection, provided only one AMC2 is connected on the bus Set BPA (= DIL switch 5 to OFF) in the case of an 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 27 Tab. 4.2: Signal numbering according to board address 4.12 RS-485 for extension modules The RS-485 Extension Module Bus expands the AMC2-4R4 with additional I/O modules (AMC2-8IOE, AMC2-16IE, AMC2-16IOE). Figure 4.15: Location of the RS-485 extension module bus Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 28 You can find further information about the extension boards in their installation manuals. A complete connection diagram of the RS-485 extension module bus is shown in Connecting Diagrams, page 42. Figure 4.16: Connection of an extension module to an AMC2 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 29 If you need higher voltage for special applications you have to connect external relays to the outputs. Depending on the power supply mode, it is recommended to use the following Wiegand relay types: Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 30 Notice! Risk of damage to equipment Do not connect externally powered devices in wet mode. This can damage the AMC2-4R4. 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 31 Installing | en Each relay output has a separate jumper setting on the underside of the circuit board to select dry (E1) or wet (E2) mode. Figure 4.20: Location of relay output jumpers Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 32 The following table shows the maximum values of permissible cable resistance depending on the used resistor combination. 1100 1100 1050 1050 1050 1100 1200 1200 1300 1300 1250 1300 1400 1500 1500 1500 1500 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 33 AMC2 Modular Controller Installing | en 1500 1650 1700 1800 1900 Table 4.3: Maximum values of cable resistance per used resistor combination in Ohm Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 34 | Installing AMC2 Modular Controller 4.15 Tamper Protection Figure 4.22: Location of the tamper protection contact 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 35 Status Display of the AMC2 The liquid crystal display delivers status information about the AMC2-4R4. Push the 'Dialog' button to switch between different modes. Figure 5.1: Location of the ’Dialog’ button Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 36 + = online - = offline "C" = Counter of the received data packages from the host interface. RS 485 Bus connection: A = Address 1 … H = Address 8 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 37 In rare cases reset the controller software as described in Section 5.3.1. For factory default reset refer to Section 5.3.2. If problem persists, please request after sales support. 5.3.1 Resetting the Software Figure 5.2: Resetting the AMC2 16I-16O-NET Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 38 | Operating AMC2 Modular Controller 5.3.2 Resetting the Device to Factory Default Figure 5.3: Resetting the AMC2 to delivery state 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 39 64,8 mm x 13,9 mm (2.551 x 0.547 in.) 1 line, 16 characters Power consumption AMC: 5 VA Peripheral devices: using the PSU-60 – up to 55 VA – constant load: 25 VA Connectors Pluggable screw connectors Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 40 13° C to 35° C (55° F to 95° F) Humidity Up to 95%, without condensation Housing material ABS with OC (UL 94 V-0) Dimensions (W/H/D) 232 x 90 x 63mm (8.9 x 3.5 x 2.5 in) Weight approx. 0.53kg (1.2lb) 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 41 AMC2 Modular Controller Technical Data | en Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 42 Figure 7.1: Connectors on upper PCB Shield Data RxTx+ (2-wire) Data Rx+ (4-wire) Data RxTx- (2-wire) Data Rx- (4-wire) Ground (PAG) Data Tx+ (4-wire) Data Tx- (4-wire) Tab. 7.4: RS-485 host on upper PCB 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 43 AMC2 Modular Controller Appendices | en TXD+ TXD- RXD+ not connected not connected RXD- not connected not connected Tab. 7.5: Ethernet Network socket (RJ45) Figure 7.2: Interconnect diagram of the RS-232 serial interface Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 44 | Appendices AMC2 Modular Controller Figure 7.3: Connector blocks of the AMC2-16ION Power supply, DC positive (10V - 30V) Shield Power supply (0V) UPS (power good signal) - AC UPS (power good signal) - Battery UPS (power good signal) - DC UPS (power good signal) - Common Tab. 7.6: Power supply...
- Page 45 Power supply for external devices (10V - 30V) Power supply for external devices (0V) Shield Data RxTx+ Data RxTx- Ground (PAG) Tab. 7.9: Host / Extension interface Tamper Contact, in Tamper Contact, out Tab. 7.10: External tamper contact Bosch Access Systems GmbH Installation Manual 2018-02 | AMC2-16ION |...
- Page 46 13 opening 15 outputs 11, 29, 39 power supply 16, 20 RS-232 host interface 11, 25 RS-485 host interface 9, 11, 22 shielding 18 transfer rates 11, 39 unmounting 14 2018-02 | AMC2-16ION | Installation Manual Bosch Access Systems GmbH...
- Page 48 Bosch Sicherheitssysteme GmbH Robert-Bosch-Ring 5 85630 Grasbrunn Germany www.boschsecurity.com © Bosch Sicherheitssysteme GmbH, 2018...
