CAUTION Do not refill a cassette. Do not tamper with or remove the barcode label.
The cassette's barcode information is essential for ensuring diagnostic image quality.
Compromising the cassette in any way jeopardizes the quality and reliability of the
imager.

Viewing the Status of a Supply Slot

The Status screen shows the status of each supply slot, including
media type, size, and number of sheets remaining in the cassette.
1: 8X10
2: A
3: 14X17 DV Blue
3 sheets queued
The cassette information in the Status screen does not update if:
• The top cover is open
• The receive tray is removed
•
The imager is printing
oÉÅÉáîÉ=qê~óë
The Horizon imager has three receive trays. By default, sheets are
printed to the receive tray that corresponds with the supply slot
used. For example, if a sheet was fed from a cassette in supply slot
1, then the printed sheet is output to receive tray 1.
3
NOTE: To override the default receive tray, some DICOM user applications will allow you to
select the desired receive tray. You can also choose a receive tray in the PostScript printer
settings (refer to Chapter 6), or use a Job Settings file that specifies a specific receive tray
(refer to the Horizon Imager Technical Manual).
Supply CMY
DV Blue 53
CV Paper 100
76
Status OK
Horizon Imager User's Manual 4-3
