FIGURE 3–18.
To run the Job once and then stop, click
54.
When the Opto switch is on the right, the Job passes.
Highlight Acquire in the Step Tree (left pane).
55.
Note: You may have to click the Acquire tab in the properties window.
Adjust the following Acquire properties:
56.
–
v3.7.3, Mar 2009
Blob Enclosing Opto Switch
File List — Click C:\Vscape\Tutorials & Samples\Tutorials\HawkEye
1600T\Advanced Example Using Multiple Tools\chip01.tif, and then
Add... to display the Open dialog box. Browse for the files opto02.tif,
opto03.tif, opto04.tif, opto05.tif and opto06.tif from Windows. They are
located at:
Getting Started With Visionscape® Smart Camera
Advanced Example Using Multiple Tools
.
Blob
3-15
